Trotec TTK 99 HEPA Operating Manual page 10

Continuous operation
Regardless of the humidity level, the device dehumidifies
continuously in continuous operation mode. The
illuminated.
In continuous operation mode, the fan speed remains at a low
level (LED I is illuminated) and cannot be adjusted.
The relative room humidity cannot be set.
The current humidity value is indicated on the segment
display (27).
Info
For continuous operation a condensation drain hose
can be connected in order to continuously drain the
accumulating condensate.
Laundry drying function
With activated laundry drying function, the device continuously
dehumidifies at high power, regardless of the humidity level.
The LED (18) is illuminated.
The fan speed remains at the high level (LED II is illuminated)
and cannot be adjusted.
The relative room humidity cannot be set.
The current humidity value is indicated on the segment
display (27).
Ventilation
In ventilation mode, the device cleans the air without
dehumidification.
In ventilation and dehumidification mode you can choose
between the low and high fan speed.
The current humidity value is indicated on the segment
display (27).
1. Press the Speed button (24).
ð If the fan speed is set to a low level, the LED (23) is
illuminated.
ð If the fan speed is set to a high level, the LED (25,) is
illuminated.
Setting the timer
Note
The device must not be left unattended in a freely
accessible room with an activated timer.
By pressing the Timer (30) button you can activate the timer.
The timer has two modes of operation:
• Automatic switch-on upon expiry of a preset number of
hours
• Automatic switch-off upon expiry of a preset number of
hours
The function can be set in addition in all operating modes. The
number of hours can be set in hourly increments (1 h to
max. 24 h).
When the timer function is active, the Timer LED (29) is
illuminated.
10
Automatic switch-on
ü The device is switched off.
1. Repeatedly press the Timer button (30) until the desired
LED (17) is
number of hours until automatic switch-on is indicated on
the segment display (27).
ð The set number of hours flashes on the segment
display (27).
ð After approx. 5 seconds, the set number of hours is
saved and the segment display goes out.
ð The device switches on after the predefined time.
ð The Timer LED (29) is illuminated.
Notes regarding automatic switch-on:
• Manually switching the device on disables the automatic
switch-on function.
• If you select 0 hours, the timer will be off.
Automatic switch-off
ü The device is switched on.
1. Repeatedly press the Timer button (30) until the desired
number of hours until automatic switch-off is indicated on
the segment display (27).
ð The set number of hours flashes on the segment
display (27).
ð After approx. 5 seconds, the set number of hours is
saved and the segment display indicates the humidity
level again.
ð The device switches off after the predefined time.
ð The Timer LED (29) is illuminated.
Notes regarding automatic switch-off:
• Manually switching the device off disables the automatic
switch-off function.
• If you select 0 hours, the timer will be off.
Memory function
If you switch the device back on again, the settings selected for
the operating mode, the relative humidity level and fan speed
are saved. If a timer has been set, it will not be saved.
The device memorises the settings even during short power
failures. In this case, the device automatically switches back on.
The previous settings are saved except for the timer.
Auto stop function
Once the condensation tank is full, the device will stop
automatically. The
condensation tank as described in section Emptying the
condensation tank.
dehumidifier TTK 99 HEPA
LED (26) is illuminated. Empty the
EN
