To connect the cables
1. Connect the instrument to the power supply by plugging the
1/4-inch metal connector into the DC input on the right side of the
StakMax instrument.
Figure 2-7 Connecting the power cord to the instrument.
2. Connect the power supply and the power cable by inserting one
end of the cord into the power supply. See
StakMax Plate Handling System User Guide
®
Figure 2-8.
