- Page 1 Little Sultan of Tone Building instructions V1.0...
- Page 2 Table of contents Components ............................3 General guideline for components ......................4 General building tips ..........................4 Modifications ............................5 Off board wiring ............................. 5 Troubleshooting ............................. 6 Schematic ............................... 7...
- Page 3 Components Value Comment Value Comment IC1 JRC4580D Socketed 100p Ceramic 100n Electrolyte 35V 220k C10 100u Electrolyte C11 100u Electrolyte R10 6k8 MA856 R11 1M MA856 R12 47k MA856 R13 47k MA856 1S1588 VR1 B100k Gain 1S1588 VR2 B25k Tone 1N5817 VR3 A100k Volume...
- Page 4 General guideline for components Capacitors: All values under 1nF should be ceramic disks. From 1nF up to 1uF should be MKT (foil/metal film capacitors) and over 1uF use electrolyte caps (or tantalum) 16V+ rated and watch out for polarity! ...
- Page 5 Modifications You can experiment with different diodes for D1-D6. MA856 and 1S1588 are very hard to find and there are a lot of fakes sold from China. An alternative for MA856 is BA282 for 1S1588 there are 1N4001, BAT41, BAT46, but also think outside the box with 1n4148, 1n914 etc.
- Page 6 The LED requires a resistor (R led in the diagram) depending on the type of LED you are using. An ultra-bright red or blue LED requires a 1k5 resistor, Green requires 680R. If you want to be more exact then go here: http://www.muzique.com/schem/led.htm Dipswitch settings Switch A (right switch) is CLEAN in the OFF setting and OD in the ON setting.
- Page 7 Schematic...
