Seneca Z Series Installation Manual

Universal analog input dual alarm threshold
Hide thumbs Also See for Z Series:
Table of Contents

Advertisement

Quick Links

Download this manual
SENECA
S
Serie Z
Serie Z
EN
EN
Installation
Installation
Installation
Installation
Manual
Manual
Manual
Manual
Contents:
Contents:
- General Specifications
- General specifications
- Technical specifications
- Technical Specifications
- Installation rules
- Installation Rules
- Electrical connections
- Electrical connections
- Input ranges
- Modbus connection rules
- Factory settings.
- DIP-switches settings
- Default conditions
- Digital inputs
- LEDs signallings
- Leds Signallings
- Purchase order codes
- Factory Settings
- Module layout
- Decommissioning and disposal
SENECA s.r.l.
Via Austria, 26 – 35127 – PADOVA – ITALY
Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287
Per manuali e software di configurazione, visitare il sito www.seneca.it
This document is property of SENECA srl. Duplication and reprodution are forbidden, if not
Contents of present documentation refers to products and technologies described in it. All technical data
contained in the document may be modified without notice. This document is subject to periodical revision.
Z113-1
Z113-1
UNIVERSAL ANALOG INPUT
UNIVERSAL ANALOG INPUT
DUAL ALARM THRESHOLD
DUAL ALARM THRESHOLD
MI003432-E
authorized
ENGLISH 1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seneca Z Series

Summary of Contents for Seneca Z Series

  • Page 1 Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287 Per manuali e software di configurazione, visitare il sito www.seneca.it This document is property of SENECA srl. Duplication and reprodution are forbidden, if not authorized Contents of present documentation refers to products and technologies described in it. All technical data contained in the document may be modified without notice.

  • Page 2: General Specifications

    3000 V to the outputs.  Possibility to set: input type, input filter, alarm output, reiection, burn-out, etc..  (See: www.seneca.it) Front panel display: power on, out of range or burn out error and alarms status.  TECHNICAL SPECIFICATIONS Universal Input...

  • Page 3: Power Supply

    Errors related to max Accuracy Thermal Linearity measuring range stability error Voltage or current input type 0.1% 0.01%/°K 0.05% <1% (1) TC input type: J, K, E, T, N 0.1% 0.01%/°K 0.2°C <1% (1) TC input type: R, S 0.1% 0.01%/°K 0.5°C <1% (1)

  • Page 4: Electrical Connections

    Electrical connections Removable 3-way screw terminals 200mls pitch MicroUSB frontal plug Dimensions / Module box Dimensions L: 100 mm; H: 112 mm; W: 17,5 mm Module box PBT, black Isolations Standards 1500 / 3000 V The module complies with the following standards: EN61000-6-4 (electromagnetic emission, industrial environment).
  • Page 5 ELECTRICAL CONNECTIONS Power supply The supply voltage must be between 10 to 40 V (Any polarity), or between 19 e 28 V.  19 – 28 V These upper limits must not be exceeded to avoid serious damage to the 50 –...

  • Page 6: Input Ranges

    Outputs 250V Two relays output with normally open contact. 250V INPUT RANGES Lower limit Upper limit Voltage (mV) 0 mV 11000 mV Current (µA) 0 µA 21000 µA Potentiometer (%) 105 % Thermocouple J (°C) -210° C 1200° C Thermocouple K (°C) -200°...

  • Page 7: Default Conditions

    DEFAULT CONDITIONS Default module setting parameters: Input type Current Input filter (acquired signal) Disabled Start / End input range 0 [mA] / 20 [mA] Reiection at mains frequency / Reiection = 50Hz / Sampling time Sampling time = 20ms Cold junction compensation ( for RTc input) Disabled Input fail detection: out of range error Disabled...

  • Page 8: Module Layout

    FRONT PANEL Z113 17,5 mm 100,0 mm Variations of standard parameters are possible by software (see www.seneca.it). For more information about a list of all register and their function please read: USER manual. DECOMMISSIONING AND DISPOSAL Disposal of Electrical & Electronic Equipment (Applicable throughout the European Union and other European countries with separate collections programs).
