We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
USE AND CARE GUIDE
JUNEDALE 52-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
To view an instructional video on how to install this product:
1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search eld.
2. Click on your product from the list of search results and click on the video link in the
"Product Overview" section.
improvement needs. Thank you for choosing Home Decorators Collection!
THANK YOU
Item #1005 805 992
Model #52188
UL Model #52-JUNE
Advertisement
Related Manuals for Home Decorators Collection JUNEDALE
Summary of Contents for Home Decorators Collection JUNEDALE
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................15 Warranty ................3 Care and Cleaning ............. 16 Pre-Installation ..............3 Troubleshooting ..............16 Installation ................6 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as flanges) during assembly or after installation. -
Page 3: Warranty
Warranty The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a lifetime after the date of purchase by the original purchaser. The supplier warrants that the light kit, excluding any glass, to be free from defects in workmanship and material at the time of shipment from the factory for a period of five years after the date of purchase by the original purchaser. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Plastic wire connecting nut Blade attachment screws...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket Light kit pan (inside canopy) Light kit fitter assembly Canopy Shade Ball/downrod assembly Blade support plate Decorative motor collar cover Receiver Fan-motor assembly Remote control Blade Extension wire Battery IMPORTANT: This product and/or components are governed by one or more of the following U.S.
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock or proper blade clearance when installing on a steep, sloped personal injury, mount to outlet box marked “Acceptable ceiling. The maximum angle allowable is 20° away from for fan support of 35 lbs (15.9 kg) or less”, and use horizontal. -
Page 7: Assembly
Assembly - Blade Installation Attaching the blade support plate □ Remove the paper backing from the adhesive film on the back side of the blade support plate (J). □ With the adhesive side of the support plate (J) facing towards the blade (F), align the three holes in the blade (F) with the three holes on the support plate (J) and firmly press the support plate (J) to the blade (F). - Page 8 Assembly - Standard Ceiling Mount Preparing for mounting □ Remove the magnetic canopy bottom cover (DD) from the canopy (B) by pulling it off. □ Loosen the two canopy screws (CC) located in the bottom of the mounting bracket (A). □...
- Page 9 Assembly - Standard Ceiling Mount (continued) Assembling the fan CAUTION: To ensure wobble-free operation and to avoid damage to the fan, the ball/downrod (C) and the setscrew (EE) must be completely tightened. NOTE: This fan is equipped with a safety tab (FF). Should the setscrew (EE) ever become loose while the fan is running in reverse, the safety tab (FF) will engage and stop the fan from falling.
- Page 10 Assembly - Hanging the Fan (continued) Hanging the fan □ Carefully lift the fan-motor assembly (E) up to the slide-on mounting bracket (A). □ Insert the ball portion of the ball/downrod assembly (C) into the socket of the slide-on mounting bracket (A). □...
- Page 11 Assembly - Hanging the Fan (continued) Wiring the receiver to the Installing the receiver household wiring WARNING: To reduce the risk of fire or electric shock, WARNING: To avoid possible electrical shock, turn remember to disconnect power. The electrical wiring the electricity off at the main fuse box before must meet all local and national electrical code wiring.
- Page 12 Assembly - Hanging the Fan (continued) Mounting the fan-motor assembly Wiring the fan to the receiver (standard mount) NOTE: The fan comes with 12 in. lead wires for use with WARNING: When using the standard ball/downrod the provided 6 in. ball downrod assembly (B). If you wish mounting, the tab in the ring at the bottom of the to use a longer downrod, you can use the extension lead mounting bracket must rest in the groove of the...
- Page 13 Assembly - Attaching the Light Kit Installing the light kit pan □ Remove one screw (HH) from the black bracket below the fan motor assembly (E), and loosen but do not remove the other two screws. □ Push the light kit pan (G) up to the fan motor assembly (E) so that the two loosened screw heads fit into the keyhole slots.
- Page 14 Assembly - Attaching the Light Kit (continued) Installing the shade WARNING: Allow the shade to cool completely before removing. CAUTION: Make sure the power is off before attaching or removing the shade. □ Place the shade (I) into the light kit pan (G) aligning the three flat areas on the top flange of the shade (I) with the three raised dimples in the light kit pan (G).
-
Page 15: Operation
Operating Your Fan and Remote Control The fan is shipped from the factory with the reversing switch positioned A. Warm weather to circulate air downward. If airflow is desired in the opposite direction, turn your fan off and wait for the blades to stop turning, then slide the reversing switch (located on the top of the motor housing) to the opposite position, and turn the fan on again. -
Page 16: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □... - Page 17 Questions, problems, missing parts? Before returning to the store, call Home Depot Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
