CE ORIGINAL MANUAL LACROS AMBLING A200(XL)/A400(XL)
VERSION CE 1.4 EN

2. Folding the bicycle

Folding the pedals

Fold the kickstand of the bicycle. Fold the pedals by pushing the entire
pedal in the direction of the bicycle and then fold it up or down.
Note: Position the pedals horizontally with the left pedal forward, so
that it will not get in the way when the frame is folded.

Handlebar clamp

Release the steering, first by rotating the locking ring (A)
away from the clamp. Open the clamp (B) so you can
fold down the steering.

Frame clamp

Release the lock from the middle clamp. After the locking cap has been
released, the clamp (A + B) must be pulled outwards so that it comes
loose. The frame is now open and ready to fold.
Note: Do not use excessive force to release the clamp.

Folding the Frame

Stand to the left of the bike and fold the front wheel towards
the rear wheel so that the wheels are connected. Under the
bottom bracket there is a triangular support on which the
bicycle can rest when folded.

Securing the wheels

Secure the folded condition of the bicycle by pushing the wheels
together so that the magnets (A + B + D) connect each other (C).
It is advisable to provide the handlebar and frame with
protection during transport by means of for example a blanket.
6
