CE ORIGINAL MANUAL
8. Technical specifications
• Dimensions unfolded (L x W x H):
• Dimensions folded (L x W x H):
• Frame:
• Motor type:
• Motor voltage:
• Motor power:
• Sensor:
• Battery type:
• Battery specifications:
• Action radius:
• Motor support:
• Gears:
• Maximum carrying load:
• Gross weight:
• Net weight (excl. battery and seat):
• Wheelsize:
• Maximum speed:
Maintenance
We recommend the first service of your bicycle after 1000 km. After this we recommend every 2500 Km or
once per year. To extend the life of your bike, we recommend that you keep the chain and the derailleur clean
and lubricate your chain with chain oil once every 3 months.
The valves
The tires are equipped with a Blitz valve which can be inflated with a standard bicycle pump. A reducer fits on
this valve to go from a bicycle valve to a car valve.
Frame number
The frame number is located in the battery case and at the front of the frame. This is stamped in the paint just
above the front fork suspension.
165x60x108cm (20")
88x40x72cm
(20")
Aluminum
Rear wheel motor
36V
250W
Magnet rotation
Lithium-Ion polymer (heat-resistant cells)
36V 10.4Ah | 13Ah | 17.5Ah
30-120km (10.4Ah/13Ah/17.5Ah)
9 levels
Shimano 7-gears
140 kg
23,5 kg (20")
19 kg (20")
20 inch
25 km/h
15
LACROS AMBLING A200(XL)/A400(XL)
VERSION CE 1.4 EN
170x60x108cm (24")
92x40x80cm (24")
24.5 kg (24")
20 kg (24")
24 inch
25 km/h
