CE ORIGINAL MANUAL LACROS AMBLING A200(XL)/A400(XL)
VERSION CE 1.4 EN

1. Unfolding the bicycle

Magnetic lock

Push the wheels apart to release them from their
magnetic lock.
A = Metal locking plate
B = Magnet
C = Direction in which you can lock
D = Locked position

Unfolding the frame

To unfold the frame, slide the wheels apart until the frame
is in a straight position. It is easy to stand on the left side
of the bike.

Secure the frame clamp

Secure the frame clamp (A + B) (on the right side of the frame) by
first securing the latch with the frame and then locking the clamp
by pushing the clamp against the frame. Then press the plastic
locking cap over the frame clamp.

Unfold and secure the steering wheel

Unfold the handlebars (A) and secure it with the
handlebar clamp (B). Make sure that the pin engages
properly in the handlebar clamp.
Secure the handlebar clamp by rotating the locking
ring towards the handlebar clamp (located around
the steering column near the handlebar clamp).

Unfold the pedals

Unfold the pedals by pulling the pedal to its horizontal position. The pedal will automatically return to its
correct position.
5
