Digital Inputs / Ignition Input

The digital inputs are all low-pass filtered and transient protected. To activate the inputs, connect a
positive voltage between the input and the GND connector.
Please note: The DIN 1/IGN input is unique as it also functions as the ignition input. If the ignition
input is activated with a logically high or low (Wait For Event mode only), it will wake up the unit
when the RTCU is in low power mode. A power apply will also wakeup the unit, if it is in power-
down mode or WaitForEvent mode with power Apply and/or ignition selected for wakeup.
The power management allows the possibility to configure a wakeup on one or more digital inputs
with individually configured falling- or rising edge detection. Please consult the RTCU IDE
documentation for additional information.
16 pin I/O connector overview.
Pin Name
2 DIN 1/IGN Digital input 1 / Ignition input.
3 DIN 2
4 DIN 3
5 GND
Specification for each digital input:
Logic "High"
Logic "Low"
Bandwidth
Input impedance
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Description
Digital input 2
Digital input 3
Signal Ground
Min. Typ. Max.
8 12 40
-5 - 3
- 7 -
- 14 -
Unit
VDC Protected against transients and
VDC low-pass filtered
kHz
kΩ
