Summary of Contents for AZZA Elise
- Page 2 Installation Instructions 1. Specifications 2. Chassis Parts 3. Control Panel Functions 4. 3.5”/2.5” HDD/SSD Installation 5. Cooling System Installation 6. ARGB Control Board 9. Front Mesh Color Change...
-
Page 3: Specifications
Specifications Model Model Name: Elise Model Number: CSAZ-140 Specifications Type: Micro ATX Mid Tower Color: Black/Black(interior) Side Panel Window: Le� side panel: slidable tempered glass panel Max CPU Cooler Height: UP to 175mm Max Video Card Length: Up to 340mm long video card... -
Page 4: Chassis Parts
Chassis Parts Metal side panel Removable dust filter Shock-proof stand Removable magnetic mesh TOP I/O & buttons Sliding tempered glass panel 2.5” SSD tray x 2 Hard disk cage 3.5” HDD/ 2.5” SSD brackets Display stand Earphone holder Front panel Removable magnetic mesh... -
Page 5: Control Panel Functions
Control Panel Functions POWER USB 3.0 (Blue) USB 3.0 (Blue) Audio... - Page 6 3.5 ˝/ 2.5˝ HDD/SSD Installation ▪Supports up to 340mm long video cards. MAX 340mm video card MAX 340mm video card 3.5″ 3.5″ 2.5″ 2.5″ ▪Multifunctional hard disk bracket support 3.5” HDD or 2.5” SSD x 1 ( ▪Multifunctional hard disk cage support 3.5”...
- Page 7 Cooling System Installation Front 120mm x3 Max Height of Radiator 280mm 140mm x2...
- Page 8 Cooling System Installation Rear 120mm x1...
-
Page 9: Cooling System Installation
Cooling System Installation 120mm x3 140mm x2 Max Length of Radiator 280mm... - Page 10 ARGB Control Board connect LED botton ※Press LED button to select different ARGB 26 modes Different ARGB modes Press ※If the ARGB control board connected to the mainboard ARGB pin header. Turn off the light Motherboard Press 3 secs control Connect MB SATA If the ARGB control board connected to the mainboard ARGB pin header,...
- Page 11 Front Mesh Color Change The front mesh is reversible with options of white & pink...
