  • Page 2 Installation Instructions 1. Specifications 2. Chassis Parts 3. Control Panel Functions 4. Removable Side Panel/ Bottom Dust Filter 5. Video Card Holder Instructions 6. 3.5″ HDD/2.5″ SSD Installation 7. Cooling System Installation 8. Parallel Connection ("daisy-chaining")
  • Page 3: Specifications

    Specifications Model Model Name: ZIRCON 7000 Model Number: CSAZ-7000 Specifications Type: ATX Full Tower Color: Black/Black(interior), White/White(interior) Side Panel Window: Tempered glass on both sides Max CPU Cooler Height: UP to 165mm Max Video Card Length: Up to 390mm long video card (Horizontal/ Vertical)
  • Page 4: Chassis Parts

    Chassis Parts Iron front panel Pump bracket LED lens 3.5"HDD/2.5" SDD brackets x2 The back panel of the front 3.5"HDD/2.5" SDD spring bolt tray x2 Left side tempered glass panel Removable magnetic dustproof net Right side tempered glass panel Slide-out dust filter Cable management cover Black fan x2 Adjustable video card holder...
  • Page 5 Control Panel Functions USB Type C port...
  • Page 6: Removing The Side Panel

    Removing the side panel S l i d e Step1 Step2 S l i d e Removing the bottom dust filter...
  • Page 7 Adjusting the video card holder Step1 ▪Remove the screws from the front cable management bar. Step2 ▪Video card holder can be adjusted with the thumb screws.
  • Page 8: Cable Management Bar

    3.5" HDD /2.5" SSD Installation ▪CABLE MANAGEMENT BAR. ▪Supports up to 390mm long video cards ▪Video card holder adjustment ▪PUMP BRACKET- compatible with a 2.5" SSD, or a 3.5" HDD. ▪CABLE MANAGEMENT COVER. ▪Two trays support 3.5″ HDD or 2.5″ SDD. ▪Two multifunctional brackets support 3.5″...
  • Page 9: Cooling System Installation

    Cooling System Installation 120mm x3...
  • Page 10 Parallel Connection ("daisy-chaining") 3-pin RGB header Motherboard 3-pin RGB connector Front panel CAUTION The addressable RGB fan has a 3-pin connector (4 holes). Please ensure that you are connecting the 3-pin connector on the fan to the 3-pin RGB header on the motherboard or RF Remote connector. Do not plug it into the 4-pin header, as the incompatible voltage will fry the fan.
