  • Page 1 CSAZ-804 CSAZ-804...

  • Page 2: Installation Instructions

    Installation Instructions 1. Specifications 2. Chassis Parts 3. Removing The Top Glass Panel 4. Overview 5. Supported Motherboards 6. Power Supply Installation 7. Video Card Installation 8. Water Radiator Installation 9. 2.5"SSD / 3.5"HDD Installation 10.PCI-E Cable 11. Fan Installation 12.
  • Page 3 Model Model Name: PYRAMID 804 Name: CSAZ-804 Specifications Type: ATX Tower Color: 1.5~2.0mm SPCC+ 2.5mm Aluminum 4 sides of top panel are tempered glass Side Panel Window: Max. CPU Cooler Height: UP to 80mm Max. GPU Dimensions: L=300 mm / W=132 mm / H=47 mm (Horizontal)

  • Page 4: Chassis Parts

    Chassis parts TOP tempered glass panel cover Horizontal PCIe slot Pyramid structure I/O Ports: USB 3.0 x 2 , Type C, HD Audio Fan bracket Spring bolt screw of top panel cover 12cm ARGB Fan Fan Cable management Cover Adiustable Video Card Holder 2.5"SSD brackets X1 Power supply rack 3.5"HDD /2.5"SSD Spring Bolt Tray X1...
  • Page 5 Removing The Top Glass Panel Lift to remove top panel Loosen the four screws * Product photos are for reference only.
  • Page 6 Overview * Product photos are for reference only.
  • Page 7 Supported Motherboards Maximum: <305 x280mm SSI-CEB Minimum : ATX Motherboard * Product photos are for reference only.

  • Page 8: Power Supply Installation

    Power Supply Installation * Product photos are for reference only.
  • Page 9 Video Card Installation ■Tighten the screws to secure the video card. * Product photos are for reference only.

  • Page 10: Bottom View

    Water Radiator Installation Bottom View ■ Secure the screws of the water radiator. * Product photos are for reference only.
  • Page 11 Water Radiator Installation ■ Supports up to 120mm fans x 3 / 240 / 360mm water radiator * Product photos are for reference only.
  • Page 12 2.5"SSD / 3.5"HDD Installation (‫)ן‬ (‫)װ‬ (I) 2.5" SSD spring bolt tray: Supports up to 2.5" SSD x 2 (II) 3.5" HDD spring bolt tray: Supports 3.5 HDD x 1 (also compatible with a 2.5" SSD) STEP: * Product photos are for reference only.
  • Page 13 PCI-E Cable 150 mm PCI-E 3.0 Cable(Support EATX、ATX Motherboard) To fix potential compatibility issues with PCI-e Gen 4.0, please connect your graphics card directly to the motherboard, enter the BIOS, and change the PCI-e x16 mode to 3.0 before using the RGB PCI-e cable.

  • Page 14: Fan Installation

    Fan Installation ■ Fasten the fan screws ■ Secure the fan to the top of the Pyramid. ■ Manage the fan cables by hiding them.
  • Page 15 Digital RGB Fan Installation For Motherboard The addressable RGB fans can connect directly to the 5V addressable RGB headers of compatible motherboards, such as those from MSI™, ASUS™, Gigabyte™ and AsRock™. Please note: Only 5V addressable headers from compatible motherboards are supported. Please do NOT connect the fan to a 12V non-addressable header.
  • Page 16 Complete * Product photos are for reference only.
