Page 2: Installation Instructions
Installation Instructions 1. Specifications 2. Chassis Parts 3. Removing The Top Glass Panel 4. Overview 5. Supported Motherboards 6. Power Supply Installation 7. Video Card Installation 8. Water Radiator Installation 9. 2.5"SSD / 3.5"HDD Installation 10. Fan Installation 11. Digital RGB Fan Installation For Motherboard... -
Page 3: Specifications
Specifications Model Model Name: PYRAMID 804 Name: CSAZ-804 Specifications ATX Tower Type: Color: 1.5~2.0mm SPCC+ 2.5mm Aluminum Side Panel Window: 4 sides of top panel are tempered glass Max CPU Cooler Height: UP to 80mm Max Video Card Length Up to 300mm long video card... -
Page 4: Chassis Parts
Chassis parts TOP tempered glass panel cover Horizontal PCIe slot Pyramid structure I/O Ports: USB 3.0 x 2 , Type C, HD Audio Fan bracket Spring bolt screw of top panel cover 12cm ARGB Fan Fan Cable management Cover Adiustable Video Card Holder 2.5"SSD brackets X1 Power supply rack 3.5"HDD /2.5"SSD Spring Bolt Tray X1... - Page 5 Removing The Top Glass Panel Lift to remove top panel Loosen the four screws * Product photos are for reference only.
- Page 6 Overview * Product photos are for reference only.
- Page 7 Supported Motherboards Maximum: ATX Motherboard * Product photos are for reference only.
-
Page 8: Power Supply Installation
Power Supply Installation * Product photos are for reference only. - Page 9 Video Card Installation ■Tighten the screws to secure the video card. * Product photos are for reference only.
-
Page 10: Bottom View
Water Radiator Installation Bottom View ■ Secure the screws of the water radiator. * Product photos are for reference only. - Page 11 Water Radiator Installation ■ Supports up to 120mm fans x 3 / 240 / 360mm water radiator * Product photos are for reference only.
- Page 12 2.5"SSD / 3.5"HDD Installation ()ן ()װ (I) 2.5" SSD spring bolt tray: Supports up to 2.5" SSD x 2 (II) 3.5" HDD spring bolt tray: Supports 3.5 HDD x 1 (also compatible with a 2.5" SSD) STEP: * Product photos are for reference only.
-
Page 13: Fan Installation
Fan Installation ■ Fasten the fan screws ■ Secure the fan to the top of the Pyramid. ■ Manage the fan cables by hiding them. - Page 14 Digital RGB Fan Installation For Motherboard The addressable RGB fans can connect directly to the 5V addressable RGB headers of compatible motherboards, such as those from MSI™, ASUS™, Gigabyte™ and AsRock™. Please note: Only 5V addressable headers from compatible motherboards are supported. Please do NOT connect the fan to a 12V non-addressable header.
- Page 15 Complete * Product photos are for reference only.
