  • Page 2: Installation Instructions

    Installation Instructions 1. Specifications 2. Chassis Parts 3. Control Panel Functions 4. Removing Panels / SSD Tray 5. Power Supply / 2.5" SSD Installation 6. Mounting Stand 7. Cooling System Installation 8. AZZA Hurricane II Digital RGB Fan Installation For Motherboard...

  • Page 3: Specifications

    High-quality tempered glass side window allows for clear visuals Tempered Glass Side Window to innercomponents 1x120mm or 1x140mm fan port on the front (1x140mm AZZA Hurricane II Digital RGB fan included) Available Fan Ports 1x80mm fan port in the rear (1x80mm black fan included) Dual-chamber design.

  • Page 4: Chassis Parts

    Chassis Parts Magnetic tempered glass front panel Slidable tempered glass panel x2 Stand SSD tray PCIe slot cover x3 M3x8 screw x3 Hand screw x4 M3x6 screw x2 AZZA Hurricane II 140mm fan x1 80mm fan x1...
  • Page 5 Control Panel Functions Power SW button USB3.0(Blue) Audio...
  • Page 6 Removing The Front Panels Removing The Side & Top Panel p a n e l S i d e T o p p a n e...
  • Page 7 Removing The SSD Tray The Power Supply Installation...

  • Page 8: Ssd Installation

    2.5" SSD Installation SSD x2 ITX motherboard Supports a 80mm fan in the rear(installed) Supports the Video card with 3 slots...

  • Page 9: Mounting Stand

    Mounting Stand (M3x10mm) x3 Suggestion: When installing the stand on the chassis, we suggest you prepare a soft pad or cardboard on the flat table, then, upside down the chassis to easily mount the stand with chassis by M3 screws.
  • Page 10 Cooling System Installation Rear Front 80mm x1 120mm x1 or 140mm x1 ▪Install the fan between the chassis and glass panel.
  • Page 11 AZZA Hurricane II Digital RGB Fan Installation For Motherboard WARNING! The addressable RGB fans can connect directly to the 5V addressable headers of compatible motherboards,such as those from MSI™, ASUS™ Gigabyte™ and ASROCK™. Please note: Only 5V addressable header from compatible motherboards are supported;...
