Obs Streaming; Obs Setting - RGBlink Mini Quick Start Manual

OBS Streaming

OBS Setting

mini is compatible with many third party steaming softwares, we recommend OBS, which is available to
download on
https://obsproject.com/download.
version.
1.Click"+"icon
2.choose video capture device
3.Click video capture device to
open up setting page
4.Choose :RGBlink USB 3.0
Capture
5.Choose Video Format YUY2
If there is no video format
YUY 2 after setting above, check
the USB 3.0port connection. Make
sure it is linked to USB 3.0port on
PC by USB 3.0 cable. (USB 3.0
cable or port is standard in blue
while USB 2.0 is in black)
If the captured video is showing mosaic, change the video format to YUY2.
Audio Setting
When there is no audio playing first check the video source see if the it is set in default value and
then check the audio setting on OBS.
