Anritsu MU150101A Operation Manual

Anritsu MU150101A Operation Manual

2.5/2.6g eos unit
Hide thumbs

Advertisement

Quick Links

Download this manual
MU150101A
2.5/2.6G EoS Unit
Operation Manual
12th Edition
• For safety and warning information, please read this
manual before attempting to use the equipment.
• Additional safety and warning information is provided
in
the
MP1590B
Operation Manual and MP1591A Network Performance
Tester Operation Manual. Please also refer to one of
these documents before using the equipment.
• Keep this manual with the equipment.
ANRITSU CORPORATION
Document No.: M-W2425AE-12.0
Network
Performance
Tester

Advertisement

loading
Need help?

Need help?

Do you have a question about the MU150101A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anritsu MU150101A

Summary of Contents for Anritsu MU150101A

  • Page 1 MU150101A 2.5/2.6G EoS Unit Operation Manual 12th Edition • For safety and warning information, please read this manual before attempting to use the equipment. • Additional safety and warning information is provided MP1590B Network Performance Tester Operation Manual and MP1591A Network Performance Tester Operation Manual.
  • Page 2 Ensure that you clearly understand the meanings of the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this manual.
  • Page 3 Software: Software reported as faulty within a period of 6 months from the date of delivery will be corrected or replaced by Anritsu Corporation at no cost to the user. Following correction or replacement the software will remain under warranty for either the remainder of 6 months from the date of initial delivery, or for a period of 30 days, whichever is shorter.
  • Page 4 In addition, this warranty is valid only for the original equipment purchaser. It is not transferable if the equipment is resold. Anritsu Corporation shall assume no liability for injury or financial loss of the customer due to the use of or a failure to be able to use this equipment.
  • Page 5 Notice The following actions are strictly prohibited for all of the software installed in this product or otherwise provided by Anritsu: 1. Copying, except for archival purposes. 2. Transferring to a third party separately from this product.
  • Page 6 MU150101A 2.5/2.6G EoS Unit 2. Applied Directive and Standards When the MU150101A 2.5/2.6G EoS Unit is installed in the MP1590B or MP1591A, the applied directive and standards of this unit conform to those of the MP1590B or MP1591A main frame.
  • Page 7 MU150101A 2.5/2.6G EoS Unit 2. Applied Directive and Standards When the MU150101A 2.5/2.6G EoS Unit is installed in the MP1591B or MP1591A, the applied directive and standards of this unit conform to those of the MP1590B or MP1591A main frame.
  • Page 8 viii...

  • Page 9: About This Manual

    About This Manual The MP1590 family operation manuals consist of separate documents for the mainframe, module(s), control software, remote control operation, and options, as shown below. Note: The MP1590 family is a general name for the MP1590B Network Per- formance Tester, the MP1591A Network Performance Tester, and the MP1595A 40G SDH/SONET Analyzer.
  • Page 10 MU150100A 10/10.7G Unit Operation Manual Describes specifications for the MU150100A. MU150101A 2.5/2.6G EoS Unit Operation Manual Describes specifications for the MU150101A. MU150110A Multirate Unit Operation Manual Describes specifications for the MU150110A. MU150125A 10/10.7G Jitter Unit Operation Manual Describes specifications for the MU150125A.
  • Page 11 Operation Manual Describes how to operate the software for monitoring Ethernet traffic. Note: The MU150142A 40/43G Electrical Unit is not for general sale and must be special-ordered. Contact an Anritsu Service and Sales office re- garding the purchase of this product.

  • Page 12: Table Of Contents

    Table of Contents About This Manual........Chapter 1 Overview ........Product Overview ............Chapter 2 Before Use ......... Environmental Conditions at Installation Site ....Cautions on Handling Optical Fiber Cables ....Chapter 3 Names and Functions of Each Part ....... Names and Functions of each Plug-in Module Part..

  • Page 13: Chapter 1 Overview

    Chapter 1 Overview Product Overview ............1-2 1.1.1 MU150101A 2.5/2.6G EoS Unit ....1-2...

  • Page 14: Product Overview

    Chapter 1 Overview 1.1 Product Overview 1.1.1 MU150101A 2.5/2.6G EoS Unit Item Specifications Tx Interface External Clock Input External clock input up to 2.6G Frequency 1.544 MHz, 2.048 MHz, 8.448 MHz, 34.368 MHz, 44.736 MHz, 139.264 MHz 51.84 MHz, 155.52 MHz, 622.08 MHz, 2488.320 MHz, 2666.057 MHz (Option 05)
  • Page 15 Product Overview Item Specifications 2 to 139/45/52/156Mbit/s 2Mbit/s, 8Mbit/s, 34Mbit/s, 139Mbit/s, Output 45Mbit/s , 52Mbit/s, 156Mbit/s Unbalanced Bitrate 2.048 Mbit/s, 8.448 Mbit/s, 34.368 Mbit/s, 44.736 Mbit/s, 139.264 Mbit/s, 51.84 Mbit/s, 155.52 Mbit/s Accuracy Refer to 3.1.1 and 3.1.2. Pulse mask 2.048 Mbit/s: ITU-T G703 table7 fig.15 8.448 Mbit/s: ITU-T G703 table8 fig.16 34.368 Mbit/s: ITU-T G703 table9 fig.17...
  • Page 16 Chapter 1 Overview Item Specifications −20 dB width 1 nm or less SMSR 30 dB or more Mean level (0,1) of logical “1” (0,0.5) Mean level (0,0) (1,0) of logical “0” Fig. 1.5-1 52M – 2.6G Pulse mask Table 1.5-1 52M – 2.6G Pulse mask table 52M/156M 622M 2.5G/2.6G...
  • Page 17 Product Overview Item Specifications Rx Interface 1.5 Mbit/s Input 1.5 Mbit/s balanced Bitrate 1.544 Mbit/s ±100 ppm Level , −6 to 2dB (DSX-655 ft or DSX-0 ft+655 ft ABAM cable) Monitor point 20, 26 dB Code AMI/B8ZS Interface BANTAM 100 Ω balanced 2 Mbit/s Input 2 Mbit/s balanced Bitrate...
  • Page 18 Chapter 1 Overview Item Specifications Optical Input 51 Mbit/s, 156 Mbit/s, 622 Mbit/s, 2.5 Gbit/s, 2.6 Gbit/s Optical input Bitrate 51.84 Mbit/s, 155.52 Mbit/s, 622.08 Mbit/s, 2488.32 Mbit/s, 2666.057 Mbit/s Frequency range ±100 ppm Wavelength 1260 to 1610 nm Level −33 to −8 dBm (51.84 Mbit/s, 155.52 Mbit/s) −29 to −8 dBm (622.08 Mbit/s, 2488.32 Mbit/s, 2666.057 Mbit/s)
  • Page 19 Product Overview Item Specifications Function OTN/SDH/SONET mode 3.1.1 PDH/DSn 3.1.1.1 Clock Internal:Accuracy:±0.1 ppm Offset: ±100 ppm (in 0.1 ppm steps) External: Refer to 1.1. Receive: synchronous with receive signal 3.1.1.2 Frame format No frame 1.544 Mbit/s, 2.048 Mbit/s, 8.448 Mbit/s, 34.368 Mbit/s, 44.736 Mbit/s, 139.264 Mbit/s Framed 1.544 Mbit/s: D4/ESF/Japan ESF...
  • Page 20 Chapter 1 Overview Item Specifications 3.1.1.3 Test pattern PRBS: 2 −1, 2 −1, 2 −1, 2 −1z, 2 −1 Invert ON/OFF −1z: Only 1.5 Mbit/s, 45 Mbit/s) Word: 16 bits Program, all0, all1, 3in24 (3in24: Only 1.5 Mbit/s) (Can set Tx/Rx independently.) 3.1.1.4 Error addition Type...
  • Page 21 Product Overview Item Specifications 3.1.1.6 Error detection Type No frame: Code, EXZ (1.5Mbit/s, 45Mbit/s), Bit 1.5 Mbit/s frame: FAS, Code, EXZ, CRC6 (ESF/Japan ESF), Bit 2 Mbit/s frame: FAS, Code, CRC4 (CRC4 On), Ebit (CRC4 On), Bit 8 Mbit/s frame: FAS, Code, Bit 34 Mbit/s frame: FAS, Code, Bit 45 Mbit/s frame: FAS, Code, EXZ (B8ZS),...
  • Page 22 Chapter 1 Overview Item Specifications 3.1.1.10 Add/Drop Add (Drop) PDH/DSn to (from) STM/OC-N. Bitrate 1.5 Mbit/s, 45 Mbit/s, 2 Mbit/s, 34 Mbit/s, 139 Mbit/s Mapping PDH/DSn Async. Mapping Error addition FAS, Bit all, B1, B2, MS-REI (M0/M1) Error addition timing Refer to 3.1.2.11.
  • Page 23 Product Overview Item Specifications 3.1.2 SDH/SONET Terms for SDH and SONET can be replaced each other. 3.1.2.1 Clock Internal:Accuracy: ±0.1 ppm (Refer to 3.1.1.1.) Offset : ±100 ppm (in 0.1 ppm steps) It is guaranteed up to ±100 ppm including devi- ation of DCS input and Offset.
  • Page 24 Chapter 1 Overview Item Specifications 3.1.2.4 Mixed payload Can be set for dummy values of TUG3 or TUG2 of STM-1 in the measured channel. Mapping SONET: The arbitrary combination of STS1SPE and VT6/VT2/VT1.5 mapping is possible. SDH: The arbitrary combination of VC3 and VC2/VC12/VC11 mapping is possible.
  • Page 25 Product Overview Item Specifications 3.1.2.8 Tandem connection Selects On/Off for Z5/N1 and Z6/N2. High order Z5/N1, Low order Z5/N1 TC-REI TC-APId,TC-RDI,ODI TC-REI, OEI: 1 or 0 TC-APId: 76 frames can be set. (ASCII) Low order Z6/N2 BIP-2 "1" TC-REI IncomingAIS TC-APId,TC-RDI,ODI b3, b4: 1 or 0 TC-REI, OEI: 1 or 0...
  • Page 26 Chapter 1 Overview Item Specifications 3.1.2.10 Payload offset Offset payload of measured channel. (Only Async mapping) ±100 ppm/in 0.1 ppm steps 3.1.2.11 Error addition SONET: FAS, Bit all, B1, B2, B3, BIP-2, REI-L (M0/M1), REI-P/V, HP/LP-IEC, N2 BIP-2, HP/LP-TC-REI, HP/LP-OEI, Bit info SDH: FAS, Bit all, B1, B2, B3, BIP-2, MS-REI (M0/M1), HP/LP-REI, HP/LP-IEC, N2 BIP-2, HP/LP-TC-REI,...
  • Page 27 Product Overview Item Specifications 3.1.2.13 Error detection SONET: Frame, B1, B2, B3, BIP-2, REI-L (M0/M1), HP/LP-REI, HP/LP-IEC, N2 BIP-2, HP/LP-TC-REI, HP/LP-OEI, Bit SDH: Frame, B1, B2, B3, BIP-2, MS-REI (M0/M1), HP/LP-REI, HP/LP-IEC, N2 BIP-2, HP/LP-TC-REI, HP/LP-OEI, Bit (Bit is for Out-of-service only) Count: 0 to 999999, 1.0E06 to 9.9E15, >9.9E15 Measurement range Ratio: 1.0E−15 to 9.9E−01, 1.0E−00, <1.0E−15...
  • Page 28 Chapter 1 Overview Item Specifications 3.1.2.15 Measurement condition Measurement ON/OFF Detection: No optical input Removal: Proper optical input Detection: Abnormal A1, A2 in 1-15 frames (5 frames) Removal: Normal A1, A2 in 1-15 frames (2 frames) Detection: OOF state persists for 1-5 ms/in 0.1 ms steps (3 ms) Removal: In-Frame state persists for 1-5 ms/in 0.1 ms steps (3 ms)
  • Page 29 Product Overview Item Specifications LOP-V/TU-LOP Detection: Abnormal H1, H2/V1, V2 in 1-15 frames (8 frames) Removal: Normal H1, H2/V1, V2 in 1-15 frames (3 frames) UNEQ-V/LP-UNEQ Detection: 00 (h) of C2 or b5-b7 = 000 of V5 in 1-15 frames (5 frames) Removal: Excluding above in 1-15 frames (5 frames) RDI-V/LP-RDI Detection: b5 = 1 of V5 in 1-15 frames (10 frames)
  • Page 30 Chapter 1 Overview Item Specifications LP-IAIS Detection: b4 “1” of Z6/N2 in 1-15 frames (5 frames) Removal: Excluding above in 1-15 frames (5 frames) LP-TC-RDI Detection: TC-RDI = 1 of Z5/N1 or Z6/N2 in 1-15 frames (5 frames) Removal: Excluding above in 1-15 frames (5 frames) LP-ODI Detection: ODI = 1 in 1-15 frames (5 frames) Removal: Excluding above in 1-15 frames (5 frames)
  • Page 31 Product Overview Item Specifications 3.1.2.17 Monitor K1/K2 byte Monitored in plain language or in units of bit. Pointer STS/AU pointer value (Main CH or ALL CH) VT/TU pointer value (Main CH) Pointer Inc/Dec (Cursor function) Resolution: 1 s, 1, 15, 60 min TOH/SOH, Payload (Channel), VC4/3/2/1POH OH byte K1/K2, G1, S1, C2, Z7/K4 (Monitored in plain language)
  • Page 32 Chapter 1 Overview Item Specifications 3.1.2.20 OH Sequence Capture K1/K2, Z4/K3, Z7/K4, STS/AU-PTR, VT/TU-PTR 64 sequences repeat/8000 frames Size (Displays frame/ms and time for each captured data) SONET: Trigger B1, B2, B3, BIP-2, REI-L/P/V, AIS-L/P/V, LOP-P/V, RDI-P/V, LOM-V, RFI-V, Match/Mismatch, change, External, manual SDH: B1, B2, B3, BIP-2, MS/HP/LP-REI, MS/AU/TU-AIS, AU/TU-LOP, HP/LP-RDI, TU-LOM, LP-RFI,...
  • Page 33 Product Overview Item Specifications 3.1.2.23 Through Bit rate 52 Mbit/s, 156 Mbit/s, 622 Mbit/s, 2.5 Gbit/s Mode Transparent, OH overwrite OH overwrite TOH/SOH, DCC1-3, DCC4-12, J0, S1, K1/K2, A1/A2, TOH/SOH1 byte (DCC can be added from DCC input.) Error Addition Transparent: Bit all, FAS, B1, B2, MS-REI SOH Overwrite: Bit all, B1, B2 DCC Overwrite: Bit all, B1, B2...
  • Page 34 Chapter 1 Overview Item Specifications 3.1.3 (Option05) Internal:Accuracy:±0.1 ppm (Refer to 3.1.1.1.) 3.1.3.1 Clock Offset: ±100 ppm (in 0.1 ppm steps) External: Refer to 1.1. Receive: synchronous with receive signal 3.1.3.2 Frame format No frame 2666.057 Mbit/s Framed OTN: OTU1 3.1.3.3 Mapping OTU1...
  • Page 35 Product Overview Item Specifications 3.1.3.9 Error Addition FAS, BIP-8 (SM, PM, TCM1-6), BEI (SM, PM, TCM1-6), Bit all, Bit Timing Single, Burst, Rate, All, Alternate, Random (Bit all only) Error position BIP-8 can be set Error position. (Cannot set Timing Rate when setting Error position) 3.1.3.10 Alarm addition LOF, LOM, BDI (SM, PM, TCM1-6), AIS (OTU, ODU),...
  • Page 36 Chapter 1 Overview Item Specifications Detection: Abnormal sequence of MFAS in 1-15 frames (5 frames) Removal: Normal sequence of MFAS in 1-15 frames (5 frames) OTU-AIS Detection: The number of “1” per 8192 bits at input is above or equal to 256, and bit error in PRBS11 per 8192 bits is less than 256 in 3 consecutive.
  • Page 37 Product Overview Item Specifications PM-TIM Detection: Unexpected pattern in 7 frames Removal: Expected pattern in 3 frames TCi-TIM Detection: Unexpected pattern in 7 frames Removal: Expected pattern in 3 frames ODU-PLM Detection: Unexpected pattern in 1-15 frames (3 frames) Removal: Expected pattern in 1-15 frames (3 frames) TCi-LTC Detection: TCMi3 (bits 6-8) = 000 in 1-15 frames (7 frames)
  • Page 38 Chapter 1 Overview Item Specifications 3.1.3.17 OH Test OH Change OTU/ODU/OPU 1 byte, FAS, APS/PCC, TCM1-6, SM, GCC0-2, EXP (Except MFAS, Paritybytes, JC and NJC) Timing A-pattern: 1 to 256 frames, B-pattern: 1 to 256 frames OH BERT Alternative A = 1 to 8000times, B = 1 to 8000 times GCC0-2, OH 1 byte (Except MFAS, Paritybytes, JC and NJC) Test pattern...
  • Page 39 Product Overview Item Specifications OH 1byte Overwrite: SM-BIP-8, PM-BIP-8, TCM-BIP-8, Bit all Alarm addition timing Refer to 3.1.3.10. Jitter Through Jitter is possible 3.1.3.19 Delay measurement Measurement period 0.5, 1, 2, 5, 10 s Measurement range 0.1 to 999 µs, 1.0 to 999.9 ms, 1.0 to 10.0 s, >Timeout Accuracy ±5 µs 3.1.3.20...
  • Page 40 Chapter 1 Overview Item Specifications M.2100 Measurement range E1-E4, DS1-DS3, STM (When STM/STS rate, above Frame mapping) In-service/Out of service Parameter Tx ES, SES Rx ES, SES, US 0 to 999999, 1.0E06 to 9.9E15, >9.9E15 Object Same as G.826 M.2101 Measurement range STM/STS In-service/Out of service...
  • Page 41 Product Overview Item Specifications M.2120 Measurement range ES, SES result of M2100, M2101 Threshold Tr1 (15 min)/Tr2 (24 hour), RTr1 (15 min) according to filter setting Tr1-ES, SES/TR2-ES-SES/RTr1-ES, ES Count Threshold Have limit of S1, S3 (15 min), S2 (24 hour) for parame- ter.
  • Page 42 Chapter 1 Overview Item Specifications GR.820 Measurement range DS1-DS3 (DS3: M13/CP-bit parity, DS1: SF/ESF) In-service/Out of service (Same measurement) Parameter ES, CV, SES, LOSS, AISS, UAS (Parity, C-bit parity: **P, **CP), TEST 0 to 999999, 1.0E06 to 9.9E15, >9.9E15 Select Line/Path Near-End/Far-End Threshold TEST Threshold 1 to 15 min./1 to 24 hour...
  • Page 43 Product Overview Item Specifications Rx: Specified for only Rx of MU150101A and MU150125A Measurement mode of MU150125A: Tx Jitter OFF, Rx 2UI Range 3.1.3.23 Jitter tolerance f 6 f 7 Jitter Frequency (Hz) Bit Rate Mbit/s UIpp UIpp UIpp 51.84 20k 400k 155.52...
  • Page 44 Chapter 1 Overview Item Specifications EoS Mode 3.2.1 Clock Internal:Accuracy: ±0.1 ppm (Refer to 3.1.1.1.) Offset: ±100 ppm (in 0.1 ppm steps) Receive: Synchronous with receive signal 3.2.2 Frame format 155.52 Mbit/s, 622.08 Mbit/s, 2488.32 Mbit/s No frame SDH: STM1, STM4, STM16 SONET: OC3,OC12, OC48 Framed payload...
  • Page 45 Product Overview Item Specifications 3.2.9 Alarm addition Contiguous Concatenation SONET: LOS, LOF, AIS-L, RDI-L, AIS-P, LOP-P, RDI-P, UNEQ-P, PLM-P SDH: LOS, LOF, MS-AIS, MS-RDI, AU-AIS, AU-LOP, HP-RDI, HP-UNEQ, HP-SLM Virtual Concatenation SONET: LOS, LOF, RS-TIM, AIS-L, RDI-L, AIS-P, LOP-P, RDI-P, TIM-P, UNEQ-P, PLM-P,...
  • Page 46 Chapter 1 Overview Item Specifications 1st MFI, 2nd MFI, CRC8 (LCAS ON) At AU4-VC3-Xv, Error is added as follows: SONET: LP-B3, LP-REI, 1st MFI, 2nd MFI, CRC8 (LCAS ON) SDH: LP-B3, LP-REI, 1st MFI, 2nd MFI, CRC8 (LCAS ON) At VC12-Xv, VC11-Xv, Alarm is added as follows: SONET: BIP2, REI-V, MFI, CRC3(LCAS ON) SDH: BIP2, LP-REI, MFI, CRC3(LCAS ON)
  • Page 47 Product Overview Item Specifications −1, 2 −1, 2 −1, All0, All1, Copy, Idle Copy is invalid for STS3c-Xc/VC4-Xc. All Dummy CH are same Payload. Can set all bytes (Except B3) Path trace: J1 (CRC7, Path trace On/Off) All Dummy CH are same POH. Pointer NDF: Same as Measurement CH Same as Measurement CH...
  • Page 48 Chapter 1 Overview Item Specifications VCAT Member setting Settings are possible by providing any Ch position as VCG member. Order of Ch can be set freely. For AU4-VC3-Xv, VC12-Xv, and VC-11Xv, Ch position and Ch order can be arbitrarily set across AU-Ch. POH setting Can set Member of POH.
  • Page 49 Product Overview Item Specifications Tx Delay Monitor (Present Value): Ch, MF, Pointer (AU, TU), ∆t, Group Delay Rx Delay Monitor: Ch, SQ, MF, Pointer (AU, TU), ∆t, Group Delay, State (Earliest, Latest) NDF, SS: NDF and SS values in common in all members can be set.
  • Page 50 Chapter 1 Overview Item Specifications 3.2.13 LCAS (Option13) LCAS: On/Off Sequence generator Number of Sequence: 64 Command (Title): ADD, Remove, Tmp. Remove, User Timing: Seq. Gap, Send time (1 to 8,000 multi frames) For the targets of a command, some of CH designation in VCG members are possible for each command.
  • Page 51 Product Overview Item Specifications Source side Detail/State: PLCT, TLCT, XMT, XPT, XAT, Rs-Ack (Rx), UMST Detail: Ch, State, SQ, Ctrl, MST (Rx), Differential Delay State: Ch setting of VCG member, State of VCG member (CTRL value) Sink side Detail/State: PLCR, TLCR, MND, SQNC, XMR, XPR, XAR, Rs-Ack (Tx) Detail: Ch, State, SQ, Ctrl, Differential Delay,...
  • Page 52 Chapter 1 Overview Item Specifications Path Monitor Error/alarm occurrence state, State for each VCG member (Need Option11 or Op- are displayed. tion12) Overview: CH, HP (AU), AU PJC, LP (TU), TU PJC, VCAT, VCAT/LCAS (LCAS ON), LCAS/Stat e(LCAS ON:OK, FAIL, IDLE, Unknown) VCG Ch Detail monitor: HP (AU): AIS, LOP, RDI, UNEQ, SLM, B3, REI AU PJC: NDF, +PJC, −PJC...
  • Page 53 Product Overview Item Specifications • At LEX, Alarm and Error are added as follows: PPP: Aborted Frame, PPP Size or FCS Error Ethernet/IP: Ethernet Size or FCS Error, IPv4 Header Checksum Error, Checksum Error, UDP Checksum Error • At LAPS(X.86), Alarm and Error are added as follows: PPP: Aborted Frame, LAPS FCS Error Ethernet/IP: Ethernet Size or FCS Error, IPv4 Header...
  • Page 54 Chapter 1 Overview Item Specifications Protocol: Can be set 16 bits (default 0021) When negotiation is on the value is fixed (Cisco 0800h) FCS: Auto Default 3.2.14.2 Frame mapped GFP (Option06) Setting Scramble/Descramble: On/off (Can be set Core Header or Payload Area independently) FCS: 32 bits Receive Conditions...
  • Page 55 Product Overview Item Specifications Client management Type: frame Signal Loss/Sync Loss/User1/User2 Header: PFI, EXI, UPI, Payload Size: 8 to 1024 bytes (4 multiples) Insert method Mode: Single/Repeat Interval: 10 to 2560 ms/10 ms Interim Frame: Idle/Stream 3.2.14.3 LAPS (Option06) Setting Scramble/Descramble: On only Minimum Flag Length: 1 byte/2 bytes FCS: 32 bits...
  • Page 56 Chapter 1 Overview Item Specifications Frame PPP-LEX Data Packet Address (0Xff) Control (0x03) Protocol Type (0x0041) flag MAC Type (0x01) EtherMAC Frame without FCS Address/Control/Protocol Type: User-defined flag/PAD: User-defined FCS: Auto 3.2.15 Packet setting (Option06 or 07) 3.2.15.1 Packet Length Fixed GFP: 8,12,16 to 65535 bytes PPP/LEX/LAPS: 8 to 65535 bytes...
  • Page 57 Product Overview Item Specifications 3.2.15.5 Error Addition FCS Error, Undersize, Oversize, Fragments Error, Oversize & FCS Error, Aborted Frame, cHEC error / correctable cHEC error tHEC error / correctable tHEC error eHEC error / correctable eHEC error FCS error LAPS(X.86) FCS error, Aborted Sequence FCS error, Fragments error Undersize error, Oversize error, Oversize &...
  • Page 58 Chapter 1 Overview Item Specifications 3.2.16.2 at 2488.320 Mbit/s Fixed 0 ns to 2 min (in 13.4 ns steps) PPP/LEX/LAPS 3.3 ns to 2 min (in 3.3 ns steps) Random 53.5 ns to 2 min (Packet length ≥ 64 bytes) 3.2.16.3 at 2488.320 Mbit/s 53.5 ns to 2 min (in 13.4 ns steps)
  • Page 59 Product Overview Item Specifications Differential Delay Monitor Group Delay (ms), Path Trace Table: CH, SQ, MF, Pointer, ∆t (ms), State (Earliest, Latest) Sort: CH, SQ, delta t (ms) Chart: ∆t Sort: CH, SQ, ∆t (ms) Zoom, Bitmap file output, Metafile output. 3.2.18 Counter Can select VCG or Provision for measurement area when...
  • Page 60 Chapter 1 Overview Item Specifications Alarm seconds: 0.000000000 to 0.999999999 1 to 999999999999999, Over Flow Alarm counts: 0 to 999999999999999, Over Flow For VCAT-LOM, seconds display only. Justification AU/TU, STS/VT NDF, +PJC, −PJC, Consecutive, ppm Count: 0 to 999999999999999, Over Flow Rate: 0.0, 1.0E−15 to 1.0E−00, Under Flow PPM: −1000 ppm to +1000 ppm/in 0.1 ppm steps 3.2.18.5...
  • Page 61 Product Overview Item Specifications 3.2.18.7 (Option06) Transmitted Frame (frames and fps) Received Frame (frames and fps) Transmitted Byte Transmitted Byte After Stuffing Transmitted Bit Rate (% and bit/s) Received Byte Received Byte Before Destuffing Received Bit Rate (% and bit/s) Transmitted Rate (%) Received Rate (%) FCS error,...
  • Page 62 Chapter 1 Overview Item Specifications 3.2.18.9 Other (Option06 or 07) Transmitted IPv4 Packet (packets and pps) Received IPv4 Packet (packets and pps) IPv4 Header Checksum Error Received UDP Packet (packets and pps) Received TCP Packet (packets and pps) TCP Checksum Error UDP Checksum Error Capture Trigger Capture Filter Frame...
  • Page 63 Product Overview Item Specifications Frame arrival time (Option06 or 07) 3.2.19 variation Offset Packet/s, Interval time (Maximum 3 min. Depend on res- olution) 1 µs, 10 µs, 100 µs, 1 ms, 10 ms, 100 ms, 1 s Time interval (Variation ±30 µs, 300 µs, 3000 µs, 30 ms, 300 ms, 3000 ms, 30 s) Frame count/Arrival time Graph display...
  • Page 64 Chapter 1 Overview Item Specifications Version (4 bits):6 Traffic class (8 bits): 0 – uncharacterized traffic 1 –"filler" traffic 2 – unattended data transfer 3 – reserved 4 – attended bulk transfer 5 – reserved 6 – interactive traffic 7 – internet control traffic Flow label (20 bits): User-defined (initial all0) Payload length (16 bits): Auto Next header (8 bits): User-defined (initial 59)
  • Page 65 Product Overview Item Specifications Total Length: Auto Identification (4 bytes): User-defined Flag: User-defined (initial 010 (bin)) Bit0: User-defined Bit 1: (DF) 0 = May Fragment, 1 = Don’t Fragment Bit 2: (MF)0 = Last Fragment, 1 = More Fragment Fragment offset: User-defined (initial 0) Time to Live: User-defined (initial 64) Protocol: User-defined (initial 0) Auto setting when select TCP or UDP.
  • Page 66 Chapter 1 Overview Item Specifications 3.2.22.5 UDP[RFC0768] Source port Destination port Length Checksum Source Port(16 bits): User-defined Destination Port(16 bits): User-defined Length (16 bits): Auto Checksum (16 bits): Auto 3.2.22.6 IGMP[RFC2236] Type Max Response time Checksum Group Address Type (4 bits): 11- Membership query 12- Version1 Membership report 16- Version2 Membership report 17- Leave group...
  • Page 67 Product Overview Item Specifications 16- Information Reply 17- Address Mask Request 18- Address Mask Reply Code (8 bits): User-defined Checksum (16 bits):Auto Data: (For Echo Request / Response), Identifier (16 bits): User-defined Sequence Number (16 bits): User-defined 3.2.22.8 MPLS[RFC3031] Label [RFC3032] Label (20 bits): User-defined 0: IPv4 explicit null label...
  • Page 68 Chapter 1 Overview Item Specifications 3.2.22.9 Version1 Command Version must be zero Address Family Identifier must be zero IP address must be zero must be zero Metric Version2 Command Version must be zero Address Family Identifier Route Tag IP Address Subnet musk Next hop Metric...
  • Page 69 Product Overview Item Specifications 3.2.22.10 DHCP Hardware type Hardware Op code Hops address length Transaction ID Seconds Flags Client IP address Your IP address Server IP address Relay Agent IP address Client hardware address (16bytes) Server Host Name (64bytes) Boot File Name (128bytes) Options(0 to 64bytes) Op code (8 bits): User-defined 1: Boot request...
  • Page 70 Chapter 1 Overview Item Specifications 3.2.22.11 Test frame Type Padding Length Test Pattern Time Stamp Flag Padding: all0, ID (32 bits): F6F62828 Length: (16 bits) Test pattern length Test Pattern: PRBS9 (Single) Source port ID (End of test pattern), Destination port ID (End of test pattern) TCP/UDP Check SUM Compensation Pattern SN (16 bits): Sequence number (Auto) Time Stamp (48 bits): 10ns resolution...
  • Page 71 Product Overview Item Specifications ICMPv6, IGAP, IGMP, IPCP, IPv4, IPv6, IPv6CP, IPX, IS-IS, LAPS(X.86), LCP, LDP, LEX, LLC, MAC Control Frame, MAPOS, MPLS, MPLSCP, OSPFv2, PPP, PPP-LEX, RIP, RSVP, SNAP, TCP, UDP, VLAN, Ethernet OAM, Test Frame Capture frame can be forwarded to Transmit stream 3.2.26 Traffic monitor (Option06 or 07)
  • Page 72 Chapter 1 Outline 1-60.

  • Page 73: Chapter 2 Before Use

    Chapter 2 Before Use This chapter provides information that the user should understood before using the module. It also covers precautions for securing safety and avoiding malfunctioning of the device in use. Read through this chapter before using the module. Environmental Conditions at Installation Site .....

  • Page 74: Environmental Conditions At Installation Site

    Chapter 2 Before Use 2.1 Environmental Conditions at Installation Site MU150101A operate normally within a temperature range of 0 to 40C. Avoid using them under the following conditions to prevent malfunction- ing:  In places of direct sunlight  In dusty places ...

  • Page 75: Cautions On Handling Optical Fiber Cables

    Cautions on Handling Optical Fiber Cables 2.2 Cautions on Handling Optical Fiber Cables Optical fiber cables may degrade in performance or be damaged if han- dled improperly. Note the following points when handling them. CAUTION Do not pull the cable when removing the connector.
  • Page 76 Chapter 2 Before Use CAUTION Do not excessively pull on or twist an optical fiber cable. Also, do not hang anything by using a cable. Doing so may break the optical fiber inside the cable. CAUTION Be careful not to hit the end of an optical connector against anything hard such as the floor or a desk by dropping the optical fiber cable.

  • Page 77: Chapter 3 Names And Functions Of Each Part

    Chapter 3 Names and Functions of Each Part This chapter describes names and functions of each part of units in- stalled to the MP1590B or MP1591A. Names and Functions of each Plug-in Module Part 3.1.1 MU150101A ..........

  • Page 78: Names And Functions Of Each Plug-In Module Part

    Chapter 3 Names and Functions of Each Part 3.1 Names and Functions of each Plug-in Module Part 3.1.1 MU150101A Fig. 3.1.1-1 MU150101A Functions and Operation Methods 1.5 M Out Output connector for 1.5 M signal. Bit rate 1.544 Mbit/s Connector BANTAM(100 Ω)
  • Page 79 Names and Functions of each Plug-in Module Part Functions and Operation Methods Ext Clock 1.5 M to Input connector of external clock for In(* 2.6 GHz 1.5 to 2666 M signals Input 1.544 MHz, 2.048 MHz, frequency 8.448 MHz, 34.368 MHz, 44.736 MHz, 51.84 MHz, 139.264 MHz, 155.52 MHz, 622.08 MHz, 2488.32 MHz,...
  • Page 80 Chapter 3 Names and Functions of Each Part Functions and Operation Methods Optical In Input connector for optical signals. Bit rate 51.84 Mbit/s, 155.52 Mbit/s, 622.08 Mbit/s, 2488.32 Mbit/s, 2666.057 Mbit/s (* Code Optical 1310 nm, 1550 nm receiving wavelength band Level −8 to −33 dBm...
