Pinout
The following pinout is valid on the target side:
Signal Signal
Direction Description
O JTAG
I JTAG
O JTAG
O Nexus Event
Input
I/O Reset
I Reference
Voltage
Not Connected
Signal Pin
TDI 1
TDO 3
TCK 5
nEVTI(EVTI0) 7
nRESET 9
Vref 11
NC 13
14-pin MPC5xxx & SPC5 target pinout
Pin Signal
2 GND
4 GND
6 GND
8 PORST
10 TMS
12 GND
14 JCOMP
Signal Signal
Description Direction
Ground
Ground
Ground
Power On IO
Reset
JTAG O
Ground
JTAG TRST O
(optional)
