Omcan MS-IT-0300-A Instruction Manual page 20

Parts Breakdown
Model MS-IT-0300-A
Item No. Description
36533 Sharpener - Assy for 13654
60813 Wheel Shaft (CE) Assy for 13654
17279 Ring EL.Benzing 5 for 13654
17280 Ring EL Benzing 5 for 13654
Ring EL.Benzing 6 Stainless Steel for
36536
13654
19606 Ring 17 for 13654
36541 Ring EL.Seeger INT.35 for 13654
60767 Ring EL.Seeger INT.32 for 13654
19174 Ring for 13654
17289 Pulley Ring for 13654
36543 Pulley Cover Ring for 13654
60814 Ring for Sharpener Handle for 13654
36551 Shock Absorber Rod for 13654
36553 Rod.Carriage for 13654
17294 Rod for 13654
19506 Carriage Rod for 13654
60760 Base for 13654
60773 Belt Housing for 13654
36555 Belt Bracket for 13654
19510 Hangover Bracket for 13654
60807 Sharpener Lever Hub for 13654
19618 Bushing 8x10x8 for 13654
17303 Bushing DU 12x14x15 for 13654
17305 Bushing DU 18x20x15 for 13654
19630 Bushing Fastener for 13654
36558 Ext.Bushing for 13654
19631 Bushing for 13654
36561 Fastener Nut 18x62 for 13654
60762 Carriage Screw for 13654
36562 Knife Fastener Bushing for 13654
17312 Bushing 22x25x20 for 13654
Bushing Supporto Plate lg.21mm for
36565
13654
36568 DU Bushing 6x8x6 for 13654
60795 Nut for 13654
60832 Grinding Stone Shaft Housing for 13654
36569 Fixing Lever Bushing for 13654
60780 All Sharpener Cover for 13654
60764 Carriage for 13654
36594 Cord Assy for 13654
36596 Cavo Ass.Motor Lama (Fast.) for 13654
13654
Position Item No. Description
A1027 19633 Hinge Motor for 13654
A3103 17316 Pin 8.5mm for 13654
A5403 17317 Pin.11 for 13654
A5404 36601 Rivet 1.9x5 for 13654
A5404X 36602 Driving Belt 330x10 for 13654
A5446 36603 V Belt for 13654
A5470 17320 Bolt for 13654
A5472 36608 Capacitor 8 MF 400V for 13654
A5475 16913 Capacitor 14 MF 400V for 13654
A5905 60771 Motor Front Plate for 13654
A5910 60766 Motor Cover 510-85 for 13654
A5914 19530 Safety Guard for 13654
B1270 36619 Belt Cover for 13654
B1317 60772 Side Plate for 13654
B1330A 36625 Cover Lato Carriage for 13654
B1360 17329 Pusher Cover Red (Rubber) for 13654
B1861 17330 Pusher Cover Green (Rubber) for 13654
B1870 60823 Sharpening Assembly Base for 13654
B5032 36629 Bearing 2Z-6003 17x35x10 for 13654
B5033 16920 Bear.2Z-6203 17x40x12 for 13654
B5091 19540 Bearing 12x32x10 for 13654
B6009 17335 Bear.2RS-6203 17x40x12 for 13654
B6052 36630 Bearing 5x16x6.5 for 13654
B6057 16926 Bearing 2RS-6000 (10x26x8) for 13654
B6104B 19638 Nut M4 for 13654
B6144 16928 Nut U5589 M6 for 13654
B6155 36636 Nut U5589 M6 Stainless Steel for 13654
B617701 19639 Nut M8 for 13654
B6185 36637 Nut U5589 M8 Stainless Steel for 13654
B6192 36641 Nut for Grinder Cover Pivot for 13654
B6211 36643 Nut U5588 M5 for 13654
B621415 36644 U5588 M5 Stainless Steel Nut for 13654
B6224 19644 Nut M6 for 13654
B6227 36647 Nut U5588 M8 for 13654
B6228 60825 Special Nut M16x1 for 13654
B6239 19645 Nut M10 for 13654
C1618 36658 EL.Box Spacer for 13654
C181923 36659 Hand Grip-Knob Spacer for 13654
Spacer Supp.Resistenza LG.28mm for
C3229 36660
13654
Carriage Shock Absorber Spacer for
C3261 36661
13654
Position Item No.
C3633 36663
C4601 36666
C4602 36667
C4640 36670
C4813 36671
C4814 36672
C5001 36674
C5806A 36675
C5812 17342
C6444 17344
C6452 36678
C6537 60763
C6583 36684
C6778 17349
C6784 36689
C6792 36691
C679201 36692
C6845 36695
C8006 36696
C8007 AI232
C8015 17356
C8022 17357
C8035 36705
C8067 36708
D0102 18220
D0133 17363
D0133X 60828
D0135 36713
D0135X 36714
D015517 36715
D0160 36717
D016015 36718
D0163 17368
D0165 17369
D0166 17372
D0167 31213
D5715 60775
D575081 19602
D5760 13597
D5762 36731
20
Description Position
Locknut Pacer for 13654 D577016
Spacer Eccentrico for 13654 D5771
Spacer Ant.Anello Paralama for 13654 D5772
Sharpener Support Spacer for 13654 D5777
Unhook Spring Spacer for 13654 D5806
Spacer of Carriage Springs for 13654 D5819
Spacer Basamento for 13654 D5851
Cam Carriage for 13654 E1409A
Cam 15mm for 13654 E1420
Cam Motor for 13654 E1457
Excentric Supp. Knife Ring Prot. for
E1465
13654
Carriage Felt for 13654 F1610
Clasp for Carriage 18x30x8 for 13654 F3019
Handle Flange for 13654 F6090
Stainless Steel Locknut M8 for 13654 G5027
Ring for Bushing for 13654 G5053
Ring for Cam for 13654 G5054
Ring Support Cap for 13654 G5055
Blade Guard Nut for 13654 G5058
P.C.Board for 13654 I166309
Fastener Handle for 13654 I1926
Deflector Screw for 13654 I1942
Adjustment Knob for 13654 I1970A
Assy Index Knob for 13654 I1990A
Knob Handling for 13654 I203576
End Grip Handle for 13654 I2040
Sharpener Body Handle for 13654 I2049
Handle for Carriage for 13654 I2055
Blade Cover Handling for 13654 I2058
Blade Cover Knob for 13654 I2066
Knob Assy for 13654 I2098
Knife Cover Assy Knob for 13654 I2099
Hall Effect Switch 2P for 13654 I3646
Switch 4x20 for 13654 I3647
Switch On/Off for 13654 I3670
Safety Switch for 13654 I3686
Start/Stop Pushbutton for 13654 I3704
Switch for 13654 I3705
Blade 40x3x245x17 for 13654 L0612
Lamp 220V. for 13654 L1010
