- Page 1 Meat Mixers Models MM-IT-0040-ETL, 0080-ETL, 0120-ETL, 0180-ETL Items 48055, 48056, 48057, 48058 Instruction Manual Revised - 03/19/2024 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model MM-IT-0050-ETL / Model MM-IT-0080-ETL Model MM-IT-0120-ETL / Model MM-IT-0180-ETL Section Page General Information -------------------------------------------------------------------------- 3 - 4 Safety and Warranty -------------------------------------------------------------------------- 4 - 7 Technical Specifications ------------------------------------------------------------------------ 8 Installation ---------------------------------------------------------------------------------------- 8 - 9 Operation -------------------------------------------------------------------------------------- 10 - 11 Maintenance --------------------------------------------------------------------------------- 11 - 14 Troubleshooting... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 Safety and Warranty • Incorrect installation. • Incorrect use of the appliance by untrained staff. • Used not respecting the standards and laws in force of the country. • Lack of or insufficient and incorrect maintenance. • Use of non-original spare parts and non-specific parts for the various models. •...
- Page 6 Safety and Warranty • Do not repair the appliance without prior authorization. • Always respect the procedures for maintenance and technical assistance. PROTECTIONS AND SAFETY FEATURES ATTENTION Before using the appliance make sure the safety protections are in their correct position and intact. Check they function correctly before starting work (at the beginning of a new work shift).
- Page 7 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
-
Page 8: Technical Specifications
Technical Specifications Model MM-IT-0050-ETL MM-IT-0080-ETL MM-IT-0120-ETL MM-IT-0180-ETL Tank Capacity 88 L / 23.2 Gal 110 L / 29.1 Gal 162 L / 42.8 Gal 250 L / 66 Gal Mixing Capacity 110.2 lbs. / 50 kgs. 176.4 lbs. / 80 kgs. 264.6 lbs. -
Page 9: Installation
Installation and allows easy access when servicing or repairing it. Provide suitable lighting around the appliance for the worker using the meat mixer. INSTALLING To move the package use a fork-lift truck or similar means. The appliance is in a carton box and packed on a pallet. -
Page 10: Operation
Operation CONTROLS AND INDICATORS LIST OF CONTROLS AND INDICATORS (FIG. 4.1.1) 1. Drive push-button (continuous). In stainless steel. Press to start the blade. 2. Stop push-button. Press to stop the propeller transmission motor. 3. Direction selector. Set the lever to FWD for forward or REV for reverse. TURNING THE APPLIANCE ON AND OFF CHECKING CONNECTION TO ELECTRICITY SUPPLY (FIG. -
Page 11: Maintenance
Operation RULES ATTENTION! Only authorized staff can use the appliance. Before use the worker must make sure that all the protections are in place and work correctly. If this is not the case, turn the appliance off and contact the maintenance team. - Page 12 Maintenance • Grip the mixing blades one at a time “5” Fig. 6.3.4 and pull outwards to remove. The surface is now smooth and easy to clean Fig. 6.3.6, clean the mixer thoroughly and if necessary disinfect. • With a sponge soaked with water and a neutral (pH 7) and non-toxic degreaser (food grade) clean and remove any food product left on the mixer and on the mixing blades.
- Page 13 Maintenance CHECKS CARRIED OUT ON OUR PREMISES The purchased appliance has undergone several factory tests. These tests are: BEFORE SETTING TO WORK: • Check operative tension in the appliance which must correspond to the customer’s requirements. • Check that there are all the warning plates and notices and the ID plate gives all the correct information and serial number.
- Page 14 Maintenance THE END OF THE WORK SHIFT: • Carefully clean the appliance removing any traces of food. • Remove, clean and mount rotor and blades. CLEANING THE APPLIANCE At the end of the work shift the appliance must be carefully cleaned and disinfected. •...
-
Page 15: Troubleshooting
Troubleshooting Problems Causes Remedies The appliance does not start. The on/off switch is in position 0”. Switch the switch to position “1”. The grille is raised. Lower the grille. The microswitch mounted on the Contact the aftersales office. mixing drum does not work. Either the electric motor or the Contact the aftersales office. - Page 16 Figure Drawings...
- Page 17 Figure Drawings...
-
Page 18: Parts Breakdown
Parts Breakdown Model MM-IT-0050-ETL 48055... - Page 19 Parts Breakdown Model MM-IT-0050-ETL 48055 Item No. Description Position Item No. Description Position Item No. Description Position Magnetic Sensor Head UL TA for Self-Lock Nut ES Din 982 M6 High Dist. Plast 18x6,4x3 Micro for AH077 62668 AN183 48055 for 48055 48055 62643 Flat Washer Din 125 D 6 for 48055...
- Page 20 Parts Breakdown Model MM-IT-0050-ETL 48055 Item No. Description Position Item No. Description Position Item No. Description Position 62638 Staffa Blocco Riduttori for 48055 AP730 Motor Carter for 48055 AP734 Sheet Int 2 Puls for 48055 Transc. Pin Femm L = 220 M and 62639 Ridut.
- Page 21 Parts Breakdown Model MM-IT-0080-ETL 48056...
- Page 22 Parts Breakdown Model MM-IT-0080-ETL 48056 Item No. Description Position Item No. Description Position Item No. Description Position Magnetic Sensor Head UL TA for Self-Lock Nut ES Din 982 M 6 High AH077 62668 AG289 Dist. Rid-Corona SP47 for 48056 48056 for 48056 Bush Flang.
- Page 23 Parts Breakdown Model MM-IT-0080-ETL 48056 Item No. Description Position Item No. Description Position Item No. Description Position 62639 Ridut. CM50 71 B14 I50 for 48056 AP730 Motor Carter for 48056 AP734 Sheet Int 2 Puls for 48056 Transc. Pin Femm L = 220 M and 61585 Shaft Support SX for 48056 AP731...
- Page 24 Parts Breakdown Model MM-IT-0120-ETL 48057...
- Page 25 Parts Breakdown Model MM-IT-0120-ETL 48057 Item No. Description Position Item No. Description Position Item No. Description Position Magnetic Sensor Head UL TA for Self-Lock Nut ES Din 982 M 6 High Dist. 19.1x30x2 Black PE x Puls. AH077 62668 AN675 48057 for 48057 Stop for 48057...
- Page 26 Parts Breakdown Model MM-IT-0120-ETL 48057 Item No. Description Position Item No. Description Position Item No. Description Position Transc. Pin Femm L = 220 M and 61600 Base DX Rid. for 48057 61595 AP740 Motor Carter Band for 48057 120 for 48057 Transc.
- Page 27 Parts Breakdown Model MM-IT-0180-ETL 48058...
- Page 28 Parts Breakdown Model MM-IT-0180-ETL 48058 Item No. Description Position Item No. Description Position Item No. Description Position Magnetic Sensor Head UL TA for Self-Locking Nut ES Din 982 M 4 AH077 66634 61610 Zinc Washer M8x30 H4 for 48058 48058 High for 48058 Self-Lock Nut ES Din 982 M 6 High Nylon Washer D8.4 D25 H2 for...
- Page 29 Parts Breakdown Model MM-IT-0180-ETL 48058 Item No. Description Position Item No. Description Position Item No. Description Position 61585 Shaft Support SX for 48058 AE734 Flange Motorid for 48058 AE736 Union Tube Bases for 48058 AP733 Sheet 2 Puls. for 48058 61606 Bracket Lock Gear for 48058 AE737...
-
Page 30: Electrical Schematics
Electrical Schematics Model MM-IT-0050-ETL 48055 Model MM-IT-0080-ETL 48056... - Page 31 Electrical Schematics Model MM-IT-0120-ETL 48057 Model MM-IT-0180-ETL 48058...
-
Page 32: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... - Page 33 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 34 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
-
Page 35: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 36 à plus de 6500 produits provenant du monde entier. Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones...
