6) Enter a 6 digit serial number.
Each physical APT hardware unit is factory programmed with a unique 8
digit serial number. In order to simulate a set of 'real' hardware the Config
utility allows an 8 digit serial number to be associated with each
simulated unit. It is good practice when creating simulated
configurations for software development purposes to use the same serial
numbers as any real hardware units that will be used. Although serial
numbers are 8 digits (as displayed in the 'Load Configuration Details'
window, the first two digits are added automatically and identify the type
The prefixed digits relating to the MFF Filter Flipper are:
37xxxxxx - MFF Series Motorized Filter Flipper
7) Click the 'Add' button.
8) Repeat items (1) to (7) as required. (A unit can be removed from the configuration
by selecting it in the 'Loaded Configuration Details' window and cl icking the
'Remove' button or by right clicking it and selecting the 'Remove' option from the
pop up window).
9) Enter a name into the 'Configuration Names' field.
10) Click 'Save'.
11) Click 'Set As Current' to use the configuration.
MFF101 and MFF102 Motorized Filter Flippers
Note
of control unit.
23
