Probes
Probes
When powered-up, the PosiTector automatically
determines which probe is attached and does a
self-check.
To disconnect a probe from a body, slide the plastic
probe connector horizontally (in the direction of the
arrow) away from the body. Reverse these steps to
attach a different probe. It is not necessary to power-
down the Gage when switching probes.
The PosiTector body accepts a wide variety of probe types
including magnetic, eddy current, and ultrasonic coating thickness,
surface profile, hardness, salt contamination and ultrasonic wall
thickness probes.
PosiTector DPM probes:
PosiTector DPM / DPM IR
Integral Surface Temperature Sensor
Air Temperature &
Relative Humidity
K-Type
Connector
Surface
Temperature / IR
Sensor
PosiTector DPM A Anemometer
Integral Surface Temperature Sensor
Air Temperature &
Relative Humidity
Wind
Velocity
Surface
Temperature
GlobalTestSupply
www.
PosiTector DPM S
Magnetic Surface Temperature Sensor
Surface
Temperature
Probe also accepts other K-Type
thermocouple sensors (optional)
PosiTector DPM D
Cabled probe with NPT threads
1/2" NPT
Threads
Air Temperature &
Relative Humidity
Sintered Metal Tip
(protects sensor)
3
