PART NAMES

FRONT
1
1 Main Unit
2 Air Outlet
OFF TIMER Button, Light (white)
3
(Press 3 sec.) Filter Reset Button, REPLACE FILTER Light (orange)
MODE Button, Light (white)
4
(Press 3 sec.) Plasmacluster Ion ON/OFF Button
HAZE Button, Light (white)
5
(Press 3 sec.) Light Control Button
MOSQUITO CATCHER Button, Light (white)
6
(Press 3 sec.) SHEET RESET Button , Light (orange)
7 POWER ON/OFF Button
8 Light Sensor
9 Odor Sensor
10 Plasmacluster Ion Light (blue)
11 Cleanliness Monitor
3 4 5
10
2
11
Cleanliness Monitor
Indicates the air purity of the room
in 3 levels with color changes.
EN-4
6
7
Blue
Orange
Red
8
9
Clean
Impure
