TROUBLESHOOTING

Before calling for service, please review the Troubleshooting chart below, since the problem may not be the main
unit malfunction.
SYMPTOM
Odors and smoke are not removed.
The Cleanliness Monitor illuminates
blue even when the air is impure.
The Cleanliness Monitor illuminates
orange or red even when the air is
clean.
A clicking or ticking sound is heard
from the main unit.
The discharged air has an odor.
The main unit does not operate prop-
erly when cigarette smoke is in the air.
The Cleanliness Monitor is turned off.
The Cleanliness Monitor lights change
color frequently.
The SLEEP lamp is flashing.
AUTO RESTART
ON
(default)
(with the main unit OFF)
(simultaneously for
more than 3 sec.)
• Is filter still in the plastic bag? Please take it out. (Page 6)
• Replace the filters if they appear to be heavily soiled. (Page 12)
• The air could be impure at the time the main unit was plugged in.
Unplug the main unit, wait one minute, and plug the main unit in
again.
• Sensor operation is affected if the dust sensor openings are dirty or
clogged. Gently clean the dust sensor openings. (Page 10).
• Clicking or ticking sounds may be audible when the main unit is
generating ions.
• Check to see if the filters are heavily soiled.
• Clean or replace the filters.
• Is the main unit installed in a location that is difficult for the sensor to
detect cigarette smoke?
• Is the dust sensor opening blocked or clogged?
(In this case, clean the opening.) (Page 10)
• Check to see if the Lights OFF Mode selected.
Press
• Check to see if the SLEEP mode is selected.
The Cleanliness Monitor/ Plasmacluster Ion Light are turned off
automatically after the SLEEP mode is selected.
• The Cleanliness Monitor lights automatically change colors as
impurities are detected by the dust sensor and the odor sensor.
• Fan motor error. Turn the power OFF.
Wait one minute, and then turn the power ON.
• Even when the plug is unplugged or the breaker is thrown during the
operation, the operation resumes at the previous operation mode and
settings if the power recovers.
If the , , , Lights light up
for 8 seconds, the setting is completed.
EN-14
REMEDY (not a malfunction)
for 3 seconds to light On. (Page 10)
OFF
(with the main unit OFF)
(simultaneously for
more than 3 sec.)
