Espressif ESP32­-S3 Series Hardware Design Manuallines page 4

List of Illustrations
List of Tables
1 Description of ESP32-S3 Power-up and Reset Timing Parameters
2 Pin-to-Pin Mapping Between Chip and SiP Flash/PSRAM
3 JTAG Signal Source Selection
4 Strapping Pins
5 Parameter Descriptions of Setup and Hold Times for the Strapping Pin
List of Figures
1 ESP32-S3 Schematic
2 Schematic for the Digital Power Supply Pins
3 Schematic for the Analog Power Supply Pins
4 ESP32-S3 Power-up and Reset Timing
5 Schematic for the External Flash and RAM (PSRAM)
6 Schematic for the Crystal
7 Schematic for the Oscillator
8 Schematic for the External Crystal (RTC)
9 Schematic for RF Matching
10 Setup and Hold Times for the Strapping Pin
11 ESP32-S3 PCB Layout
12 Placement of ESP32-S3 Modules on Base Board (antenna feed point on the right)
13 Placement of ESP32-S3 Modules on Base Board (antenna feed point on the left)
14 Keepout Zone for ESP32-S3 Module's Antenna on the Base Board
15 ESP32-S3 Power Traces in a Four-layer PCB Design
16 ESP32-S3 Analog Power Traces in a Four-layer PCB Design
17 ESP32-S3 Crystal Oscillator Layout
18 ESP32-S3 RF Layout in a Four-layer PCB Design
19 ESP32-S3 PCB Stack up Design
20 ESP32-S3 Stub in a Four-layer PCB Design
21 ESP32-S3 Flash Layout
22 A Typical Touch Sensor Application
23 Electrode Pattern Requirements
24 Sensor Track Routing Requirements
25 Shield Electrode and Protective Sensor
Espressif Systems 4
Submit Documentation Feedback
ESP32-S3 Series Hardware Design Guidelines v1.0
