Oscillator
If an oscillator is used, its output should be connected to XTAL_P on the chip through a series inductor (a 20 nH
inductor can be used initially). XTAL_N can be floating. Make sure that the oscillator output is stable and its
accuracy is within ±10 ppm. It is recommended that the circuit design for the oscillator is compatible with the
3
crystal. In case of defects in the circuit design, you can still use the crystal. The circuit for the oscillator is shown
in Figure 7.
VDD33
R1
10K(NC)
R3 499
Notice:
Defects in the manufacturing of crystal and oscillators (for example, large frequency deviation of more than ±10 ppm,
unstable performance within operating temperature range, etc) may lead to the malfunction of ESP32-S3, resulting in a
decrease of the RF performance.
C10
0.1uF
GND

2.4.2 RTC (optional)

42
ESP32-S3 supports an external 32.768 kHz crystal or an external signal (e.g., an oscillator) to act as the RTC
41
40
sleep clock. Figure
39
38
37
36
35 R16 0
SPID
34
R15 0
SPIQ
33 R10 0
32
31
R14 0
30 R13 0
29
C14
C13
0.1uF 1uF
GND GND
Notice:
• Please note the requirements for the 32.768 kHz crystal.
– Equivalent series resistance (ESR) ⩽ 70 kΩ.
– Load capacitance at both ends should be configured according to the crystal's specification.
• The parallel resistor R is used for biasing the crystal circuit (5 MΩ < R ⩽ 10 MΩ). In general, you do not need to
populate the resistor.
• If the RTC source is not required, then the pins for the external 32.768 kHz crystal can be used as other GPIOs.
