The distance between the base plate and the wall should be at least 50mm to
allow for a safety turning distance. Any gap of less than 50mm will result in
an obstruction to the camera's movement.
Waterproofing kit
The camera has a power supply port and a LAN port. Waterproofing
must be done on both these ports.
1. Wrap the power supply port with the waterproofing tape as shown
below.
2. Wrap the LAN port with the waterproofing tape or a waterproofing
sleeve.
The LAN port can be wrapped with the waterproofing tape in the same way
as the power supply port.
For instructions on the use of a waterproofing sleeve, visit the IMiLab
WeChat account.
Using a waterproofing sleeve
on the LAN port
Using the waterproofing tape
on the power supply port
Wrapping with
the waterproofing tape
