- Page 1 IMILAB C20 Home Security Camera User Manual Read this manual carefully before use, and retain it for future reference.
-
Page 2: Product Overview
MicroSD Slot Reset (Can be Hole Reset revealed by pushing the lens upward) Front View Loudspeaker Micro-USB Charging port Rear View Package Contents: IMILAB C20 x 1, power cable x 1, wall mounting accessories pack x 1, user manual x 1... -
Page 3: Installation
Mounted IMILAB C20 on a Wall: 1. Drill two holes on the wall by using the base of the IMILAB C20 as a template. It is recommended that you mark the locations of the hole with a pencil before drilling. - Page 4 3. Make sure to position the base unit so that the arrow is pointing up. Secure the base unit in place by tightening the screws into the plastic anchors. 4. Matching the grooves on the bottom of the camera unit with the raised area on the base unit. Press down until the two surfaces are flush, then turn the camera unit in either direction to lock it in position.
-
Page 5: Product Instructions
1. If the indicator light is flashing orange, that means the device is activated successfully. Else, please reset the device. 2. Once the IMILAB C20 is turned on, please do not attempt to rotate its head by force. If the camera position is incorrect, adjustments can be made through the app. -
Page 6: Indicator Light
Flashing orange slowly: system upgrade in progress Installing a MicroSD Card Make sure that the power to IMILAB C20 is already disconnected. Adjust the camera lens upward until the MicroSD slot is revealed, then insert the MicroSD card into the slot (the side with contact points must be facing down). -
Page 7: Add Device
Add Device Open IMILAB Home app, tap “+” on the upper right. Tap”[-]”and scan the QR code under the device by your phone, then you can follow the steps to add your device. Open IMILAB Home app, tap “+” on the upper right. Tap”IMILAB C20”and then you can follow the steps to add your device. -
Page 8: Specifications
Specifications Name: IMILAB C20 Expandable Memory: MicroSD card (up to 64 GB) Model: CMSXJ36A Dimensions: 109 mm x 75 mm x 72.6 mm Net Weight: 259 g Operating Temperature: -10 °C to 40 °C Lens Angle: 105° Compatible With: Android 5.0 or iOS 9.0 or above Resolution: 1920 x 1080 Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4GHz... -
Page 9: Fcc Statement
FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 10: Weee Information
Please contact the installer or local authorities for more information about the location as well as terms and conditions of such collection points. EU Declaration of Conformity Hereby, Shanghai Imilab Technology Co., Ltd. declares that the radio equipment type is in compliance with Directive 2014/53/EU. IMILAB C20 Manufacturer: Shanghai Imilab Technology Co., Ltd.
