Installing the Device

Assemble the camera as shown below. Then secure the camera to the metal
rod with a screw.
Locking mechanism
Note: The warranty does not cover any damage caused by improper
installation. Please follow the instructions.
Mounting the device
Note: Please check that the Wi-Fi signal is strong enough before
mounting the device.
1. Attach the positioning sticker on the desired installation location. Drill four
holes at the positions indicated on the sticker. Drilling diameter of around
6.0mm; drilling depth of around 30mm.
(1 spare screw is available in
EN-03
Connecting screw
the accessory pack)
