Ruckus Wireless VideoFlex 2825 User Manual

Wireless multimedia router
Hide thumbs Also See for VideoFlex 2825:
Table of Contents

Advertisement

Quick Links

Download this manual
VF2825
VideoFlex 2825 Wireless Multimedia Router
Part number: 8000001
March 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VideoFlex 2825 and is the answer not in the manual?

Questions and answers

Related Manuals for Ruckus Wireless VideoFlex 2825

Summary of Contents for Ruckus Wireless VideoFlex 2825

  • Page 1 VF2825 VideoFlex 2825 Wireless Multimedia Router Part number: 8000001 March 2006...
  • Page 2 In the interest of improving internal design, operational function, and/or reliability, Ruckus Wireless, Inc. reserves the right to make changes to the products described in this document without notice. Ruckus Wireless, Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.

  • Page 3: Table Of Contents

    VideoFlex 2825 Wireless Multimedia Router ........
  • Page 4 Management ..............VideoFlex 2825 Wireless Multimedia Router...

  • Page 5: Who Should Use This Guide

    Who Should Use this Guide Preface This VideoFlex 2825 Wireless Multimedia Router User’s Guide will help you understand the VideoFlex 2825 Wireless Multimedia Router—how to install it, and configure it using the Ruckus Wireless Web Interface. Who Should Use this Guide This User’s Guide assumes that the reader has basic to intermediate computer and Internet skills.

  • Page 6: System Requirements

    System Requirements System Requirements The VideoFlex 2825 Wireless Multimedia Router is compatible with most contemporary personal computers and operating systems that are configured for Internet and wireless networking. The VF2825 is accessed and configured via a Web browser interface. Any of the following Web browsers are supported: •...

  • Page 7: Chapter 1 Introduction

    VF2825 is a device that enables wireless multimedia networking for video, voice and data, without replacing existing routers, network adapters and media receivers. A typical installation consists of a Ruckus Wireless, Inc. VideoFlex 2825 Wireless Multimedia Router connected to a DSL router or cable modem. The VF2825 sends wireless signals to an adapter that is connected to a set top box.

  • Page 8: Mediaflex

    MediaFlex™ MediaFlex™ MediaFlex™ is Ruckus Wireless, Inc.’s family of purpose-built, multimedia WiFi appliances that enable reliable wireless distribution of entertainment-quality, real-time media applications throughout the home. Media applications require consistent and uninterrupted bandwidth; however most wireless LANs (WLANs) cannot provide consistent service because of the variable nature of the wireless medium.

  • Page 9: Key Features

    • Forward compatible with the emerging 802.11n WLAN standard. Key Features The key features of the VideoFlex 2825 Wireless Multimedia Router are as follows: • SmartCast • Heuristic classification of video and voice traffic •...
  • Page 10 Key Features • SSH and Telnet • Dual BSSID for Service Provider and Home User profiles (Virtual AP) • WPA2-Personal • Authentication based on pre-shared key • Encryption based on AES VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 11: Chapter 2 Installation And Setup

    VideoFlex 2825 Wireless Multimedia Router........

  • Page 12: Packing List

    1. VideoFlex 2825 Wireless Multimedia Router 2. AC power adapter (Input DC 5-18V 1-2A) 3. Category 5 (CAT5) Ethernet Cable 4. VideoFlex 2825 Wireless Multimedia Router Quick Setup Guide VideoFlex 2825 Wireless Multimedia Router Front View Figure 2— “Front View of theVideoFlex 2825 Wireless Multimedia Router”...

  • Page 13: Led Status Lights

    Bad Air Quality: A briefly flashing Green LED (on for 0.03 Flashing second and off for 1 second) indicates that video streaming is not possible in the current environment. The brief flash also indicates that the device is still functioning. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 14: Rear View

    Insert the end of a paper clip or pin into the hole and hold it in for at least 8 seconds. Over the Air Auto Provisioning Button (not active for current release). VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 15: Placement Guidelines

    2. Double-click the icon for the Local Area Connection designated for your home network, then click the Properties button at the bottom of the screen. (This is not the same icon as your home wireless network.) 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 16: Connecting A Pc To The Vf2825

    3. Connect your PC or laptop to the Ethernet port on the VF2825 using the supplied Ethernet cable. 4. On your PC, open a browser window. Enter the address http://192.168.0.1 5. When the login screen appears, enter the username and leave the password field blank. Then click admin Logon. VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 17: Accessing The Web Interface

    Chapter 3, “Using the Ruckus Wireless Web Interface 1. To access the Ruckus Wireless Web Interface, launch a Web browser and enter the VF2825’s IP address. If this is the first time the access point is being configured, enter the default IP address: http://192.168.0.1 2.
  • Page 18 Accessing the Web Interface VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 19: Chapter 3 Using The Ruckus Wireless Web Interface

    Ruckus Wireless Web Interface Menus ........

  • Page 20: Wireless Settings Worksheet

    The WEP key values are not case-sensitive. Key 1 ______________________________________________ Key 2 ______________________________________________ Key 3 ______________________________________________ Key 4 ______________________________________________ If using WPA-PSK, write down the passphrase. The WPA-PSK passphrase is case-sensitive. WPA Passphrase: ________________________________ VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 21: Vf2825 Settings Worksheet

    Table 6—VF2825 Default and User Settings Worksheet Item Default Setting Your Setting User Name admin _______________________________ Password <none> _______________________________ IP Address 192.168.0.1 _______________________________ Subnet Mask 255.255.255.0 _______________________________ SSID V54-WXYZ _______________________________ Wireless Mode 802.11g&b _______________________________ Security Disabled _______________________________ 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 22: Ruckus Wireless Web Interface Menus

    Ruckus Wireless Web Interface Menus Ruckus Wireless Web Interface Menus The Ruckus Wireless Web Interface menus are located on the left-hand navigation pane. To select a particular menu, simply click on the menu link. Common Buttons The Ruckus Wireless Web Interface screens contain the following menu buttons (Table Table 7—Wireless Web Interface Menu Buttons...

  • Page 23: Configuring The Vf2825

    "Connecting to the VF2825" on page 2. Choose Configuration->Device. The window Figure 5 appears. Figure 5—Device Configuration 3. Enter your configuration changes in the appropriate fields. 4. Click Update Settings to save your settings. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...
  • Page 24 LEDs at the top of the unit briefly go out— indicating the system is rebooting. 5. Choose Configuration->Local Network. The window of appears. Figure 6—Local Network Configuration VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 25: Customizing The System Configuration

    IP Address The IP address of the VF2825. This IP address is used only when you need to access the Ruckus Wireless Web Interface to change configuration or view information about the VF2825. Subnet Mask The subnet mask of the VF2825.

  • Page 26: Configuring The Wireless Interface

    "Wireless Network Settings Worksheet" on page 20 • "VF2825 Default and User Settings Worksheet" on page 1. After connecting to the MF2501 Adapter, choose Configuration->Wireless. The window ofFigure 7 appears. Figure 7—Wireless Interface Configuration VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...
  • Page 27 This button provides access to the advanced wireless settings. Advanced wireless settings are for advanced configuration or testing purposes only. Changing the advanced settings may negatively affect the operation of the VF2825 and is not recommended. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 28: Configuring Wpa Psk

    If you configure the VF2825 with WPA-PSK, the other devices in the network will not connect unless they, too are set to WPA-PSK, and are configured with the same passphrase. VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 29: Configuring Wpa Psk

    WPA-PSK, and are configured with the same passphrase. 1. Click the Configuration -> Wireless link in the left-hand navigation pane (Figure 2. Select WPA-PSK in the Security drop-down menu. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...
  • Page 30 Using Auto allows devices that cannot use AES to use TKIP. 3. In the Configuration ->Security (WPA-PSK) menu, enter a passphrase and enter it again in the Confirm field. 4. Click the Update Settings button to save your settings. VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 31: Viewing Status Information

    The local name for the device (for example, PC) connected to the VF2825. Uptime The system uptime since last reboot, displayed in HH:MM:SS (hours, minutes, seconds). H/W Version The hardware revision. S/W Version The firmware version that is currently operating. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 32: Internet Status

    The Internet Status window shows the values and status of the various parameters that were configured in the Configuration section. A graphical representation of the connection is shown. You can also renew and release DHCP. If you enable auto update, the information will be continuously updated. VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 33: Local Network Status

    It shows the status of the DHCP server, with the starting and ending IP addresses of devices on the network. For each connected device, its IP and MAC Address are given, along with the type of connection (wired or wireless) and the expiration date and time of the lease. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 34: Wireless Status

    The SSID (Service Set Identifier) is the name of the wireless network. BSSID The BSSID is the MAC address of the VF2825. Wireless Mode The wireless mode, such as 2.4 GHz 54Mbps (802.11b/g) Channel The wireless channel number and operating frequency in MHz. VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...
  • Page 35 Table 9— “Wireless Interface Configuration” on page Connected Devices Shows the IP Address, MAC Address and SSID for all connected devices. A home user sees only home connected devices; a service provider sees all 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 36: Administration Information

    Good Packets Represents the total good transmit TX packet – record the cumulative number of packets sent since the previous period. This counter continues to increase, until the device is clear. VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 37: Updating The Firmware

    CAUTION:—If you have recently made configuration changes to the VF2825, make sure to reboot the system (see “Rebooting the System” on page 39) first so that your changes are preserved. Then update the firmware. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 38: Performing A Web Download

    1. Point your browser to the Web site where the VF2825’s firmware is stored, and download the firmware image to a folder on your hard drive. Note the location of the downloaded image. 2. In the Ruckus Wireless Web Interface, click the Maintenance->Upgrade menu. Table 14 describes the Updating the Firmware parameters.

  • Page 39: Rebooting The System

    The Reset to Factory Settings button restarts the system with the factory default configurations. All previous configurations will be lost. 1. To reboot for either type, click Maintenance->Reboot Now from any window. The window of Figure 14 appears. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 40: Taking A System Support Snapshot

    The Support menu enables you to take a system snapshot for further analysis and troubleshooting. The system snapshot can be sent and saved to a TFTP or FTP server for analysis by a technical support engineer. 1. To view the support menu, choose Maintenance->Support from any window. VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...
  • Page 41 TFTP or FTP server. You can set the address support.txt for the TFTP or FTP server in the Firmware Update menu. 6. Click the Upload link at the bottom of the page to upload to the specified server. 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...
  • Page 42 Taking a System Support Snapshot VideoFlex 2825 Wireless Multimedia Router 8000001, March 2006...

  • Page 43: Appendix A: Technical Specifications

    Operating Humidity: 15% - 95% non condensing Electromagnetic Emissions Meets requirements of FCC Part 15 Class B Performance and Supported Configurations 15-20 Mbps sustainable throughout a typical 2500 ft Target UDP throughput (300 m ) home 8000001, March 2006 VideoFlex 2825 Wireless Multimedia Router...

  • Page 44: Traffic Management And Qos

    Classes of service Voice, Video, Best Effort and Background Number of hardware queues Number of software queues Management Configuration and monitoring interface Ruckus Wireless Web User Interface (WebUI) Username: admin Login Password: <blank> Auto configuration Not available in this release...
