- Page 1 QUICK START GUIDE Ruckus ICX Switch Quick Start Guide Supporting the Ruckus ICX 7150, ICX 7250, ICX 7450, and ICX 7650 families of Ethernet switches Part Number: 53-1004910-03 Publication Date: 26 June 2019...
-
Page 2: Export Restrictions
Trademarks ARRIS, the ARRIS logo, Ruckus, Ruckus Wireless, Ruckus Networks, Ruckus logo, the Big Dog design, BeamFlex, ChannelFly, EdgeIron, FastIron, HyperEdge, ICX, IronPoint, OPENG, SmartCell, Unleashed, Xclaim, ZoneFlex are trademarks of ARRIS International plc and/or its affiliates. Wi-Fi Alliance, Wi-Fi, the Wi-Fi logo, the Wi-Fi CERTIFIED logo, Wi-Fi Protected Access (WPA), ™... -
Page 3: Table Of Contents
Contents Overview....................................... 4 Connecting to the Console.................................. 4 Telnet or SSH........................................ 4 Serial..........................................4 Introduction to the CLI..................................5 Accessing the CLI......................................5 Saving the Configuration.................................... 7 Securing the Web, Serial, and Telnet Interfaces..........................7 Adding a Static IP Address with the CLI.............................8 Accessing the Web GUI .................................. -
Page 4: Overview
Overview Direct management of Ruckus ICX switches can be performed using either a command line interface (CLI) or a web graphical user interface (GUI). By default, only the CLI is enabled. This guide explains how to access the CLI, enable the web GUI, and secure all configuration access methods. -
Page 5: Introduction To The Cli
Introduction to the CLI Accessing the CLI To connect a PC to the serial interface, a DB9M-to-USB adapter is required; this adapter can be obtained from an online electronics supplier. FIGURE 1 DB9M-to-USB Adapter Once a serial connection to the switch has been made, a terminal emulation program can be used to access the CLI. Refer to Accessing the CLI on page 5. - Page 6 Introduction to the CLI Accessing the CLI FIGURE 3 PuTTY SSH Settings The SSH settings are required for the ICX7150-24F, ICX7150-C08P, and ICX7150-C10ZP switches. FIGURE 4 PuTTY Serial Settings In the PuTTY serial settings, xx is the number of the COM port, for example, COM5. NOTE The ICX7150-24F, ICX7150-C08P, and ICX7150-C10ZP switches ship from the factory with the following default credentials (these are the same as a Ruckus AP):...
-
Page 7: Saving The Configuration
Securing the Web, Serial, and Telnet Interfaces Global Configuration Mode Global configuration mode is the highest level and allows the user to make configuration changes. device> device> enable device# configure terminal device(config)# NOTE The configure terminal command can be shortened to conf t. From any prompt, the available commands can be listed by entering a question mark (?). -
Page 8: Adding A Static Ip Address With The Cli
Adding a Static IP Address with the CLI Make sure that the username and password are secure and easy to remember. Once set, access to the CLI and web interface will be possible only when the password has been correctly entered. IMPORTANT For security reasons, Ruckus ICX switches do not provide any remote backdoor access or reset mechanisms for the CLI or web passwords. -
Page 9: Accessing The Web Gui
Accessing the Web GUI Deleting the Default Username and Password Accessing the Web GUI You can now access the web interface of the switch. Enter the IP address of the switch into the address bar using either HTTP or HTTPS; for example, https://192.168.2.79/. Creating Additional Web Interface Users The first task is creating usernames and passwords to secure access to the switch. -
Page 10: Saving Configuration Changes
Saving Configuration Changes Saving Configuration Changes Changes made to the configuration are not automatically saved during a session. An option to save changes is provided when logging out of the web interface. To save the configuration manually, use the Save to Flash option on the Command menu. FIGURE 7 Save to Flash Option Documentation All documentation for Ruckus ICX switches can be found on the support page for each product at... -
Page 11: Lifetime Warranty Hardware Replacement
Additional Information Lifetime Warranty Hardware Replacement Lifetime Warranty Hardware Replacement All Ruckus ICX switches include a lifetime hardware replacement warranty. Full details are available at https:// support.ruckuswireless.com/programs-warranty_registration. Ruckus ICX Switch Quick Start Guide Part Number: 53-1004910-03... - Page 12 © 2019 ARRIS Enterprises LLC. All rights reserved. Ruckus Wireless, Inc., a wholly owned subsidiary of ARRIS International plc. 350 West Java Dr., Sunnyvale, CA 94089 USA www.ruckuswireless.com...
