HARDWARE INSTALLATION GUIDE
Ruckus ICX 7150 Switch
Hardware Installation Guide
53-1004928-02
13 March 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICX 7150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruckus Wireless ICX 7150

Summary of Contents for Ruckus Wireless ICX 7150

  • Page 1 HARDWARE INSTALLATION GUIDE Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02 13 March 2017...
  • Page 2 To find out which open source software is included in Brocade products, view the licensing terms applicable to the open source software, and obtain a copy of the programming source code, please visit http://www.brocade.com/support/oscd. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 3: Table Of Contents

    Mounting the compact device directly on a wall..................................37 Mounting on a wall using the wall mount brackets................................... 41 Mounting on a two-post rack..........................................46 Installing the 1U, 1.5U, and 2U Universal Kit for Four Post Racks (XBR-R000295)....................51 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 4 Interpreting nonport-side LEDs........................................88 Pinging an IP address............................................89 Tracing a route................................................89 Digital optical monitoring............................................. 89 Monitoring power and cooling........................................... 89 Ruckus ICX 7150 Switch Technical Specifications..............................91 System specifications............................................91 Ethernet..................................................91 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 5 VCCI statement..............................................103 Cautions and Danger Notices..................................... 105 Cautions................................................... 105 General cautions............................................105 Electrical cautions............................................107 Danger Notices..............................................108 General dangers............................................109 Electrical dangers............................................109 Dangers related to equipment weight....................................111 Laser dangers.............................................. 112 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 6 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 7: Preface

    Identifies command names. Identifies keywords and operands. Identifies the names of GUI elements. Identifies text to enter in the GUI. italic text Identifies emphasis. Identifies variables. Identifies document titles. Identifies CLI output. Courier font Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 8: Command Syntax Conventions

    By sending your feedback to documentation@brocade.com Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 9: Contacting Brocade Technical Support

    Brocade Supplemental Support augments your existing OEM support contract, providing direct access to Brocade expertise. For more information, contact Brocade or your OEM. • For questions regarding service levels and response times, contact your OEM/solution provider. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 10 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 11: About This Document

    • What's new in this document..................................12 Supported hardware and software This document is applicable for the various Ruckus ICX 7150 Ethernet switch models. The following tables list the device models and rack mount kits supported. TABLE 1 OS-dependent models...

  • Page 12: What's New In This Document

    TABLE 2 Rack mount kits (continued) Part number Short description Notes ICX7000-C12- Wall / under desk mount kit for ICX 7150-C12P Not included with the device. Optionally orderable. ICX7000-RMK Rack mount kit for 2-post racks Included with 24-port and 48-port ICX 7150 models.

  • Page 13: Device Overview

    • Device management options..................................17 Hardware features The Ruckus ICX 7150 offers the following hardware features and capabilities: • 12, 24, or 48 auto-negotiating 10/100/1000 Mbps full duplex RJ-45 ports that can be used for downlink. These ports reside on slot 1 of the switch and can be non-PoE, PoE class 3, or PoE+ ports.

  • Page 14: License Options

    License options The Ruckus ICX 7150 switch has all the 1-GbE RJ-45 ports enabled by default including the two 1-GbE RJ-45 uplink ports in slot 2. You can buy the device with some or all of the 1/10-GbE SFP+ uplink ports in slot 3 enabled for 1-GbE speed only. You can upgrade the 1/10-GbE SFP+ uplink ports in slot 3 from 1-GbE to 10-GbE with an upgrade license.

  • Page 15: Port-Side View

    SFP+ Port X2 status LED 15. RJ-45 console port SFP+ Port X1 status LED 16. Reset button FIGURE 2 Port-side view of ICX 7150-24 and ICX 7150-24P Type-C USB console port SFP+ port X2 status LED Port status mode selection button and LEDs 10.

  • Page 16: Nonport-Side View

    Nonport-side view FIGURE 3 Port-side view of ICX 7150-48, ICX 7150-48P, and ICX 7150-48PF Type-C USB console port 10. Slot 3 (SFP+ uplink or stacking) ports Port status mode selection button and LEDs 11. Slot 2 (10/100/1000 Mbps RJ-45 uplink) ports System LEDs 12.

  • Page 17: Device Management Options

    FIGURE 6 Nonport-side view of ICX 7150-48 Management console port - RJ-45 AC power supply socket FIGURE 7 Nonport-side view of ICX 7150-24P and ICX 7150-48P Fan 1 Management console port - RJ-45 (available in the front panel for ICX...
  • Page 18 User Guide NOTE Not all FastIron features are supported via the web management interface. Brocade Network Advisor (BNA) Ethernet or serial connection Brocade Network Advisor documentation set NOTE BNA must be purchased separately. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 19: Preparing For The Installation

    To protect the serial port from damage, keep the cover on the port when not in use. CAUTION Do not install the device in an environment where the operating ambient temperature might exceed 45°C (113°F). Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 20: Esd Precautions

    Compare this total with the rating limit for the circuit. The maximum ampere ratings are usually printed on the devices near the input power connectors. Lifting and weight-related precautions DANGER Use safe lifting practices when moving the product. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 21: Laser Precautions

    Refer to the Technical Specifications at the end of this guide for complete power supply specifications. Thermal • A minimum airflow of 39.1 cubic meters/hour (23 cubic ft/min.) available in the immediate vicinity of the switch Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 22: Quick Installation Checklist

    Review and verify installation requirements. Verify that the following requirements are met. Refer to Facility requirements on page 21. • General requirements • Power requirements • Environmental requirements • Clearance for standalone or rack installation Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 23: Installation And Initial Configuration

    Establishing a connection to the out-of-band management port on page 72. Verify that the device operates correctly. • Check the LEDs to verify operation of functional parts. Refer to Verifying the correct operation on page 73. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 24: Shipping Carton Contents

    Rack mounting kit containing two L-shaped mounting brackets and two sets of eight sink-head screws (included only with 24-port and 48-port models) – Wall mounting kit containing two wall-mount screws and two plastic anchors (included only with ICX 7150-C12P) – Two-post rack kit containing four rack-mounting screws and four cage nuts (included only with 24-port and 48-port models) –...

  • Page 25: Mounting The Device

    The following precautions specifically apply to mounting the device. DANGER Use safe lifting practices when moving the product. DANGER Make sure the rack housing the device is adequately secured to prevent it from becoming unstable or falling over. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 26: Mounting On A Desktop Or Flat Surface

    Complete the following steps to install the device on a desktop or other flat surface. The device you are installing might look different than the one in the following illustration. NOTE The hardware device illustrated in this procedure is only for reference and may not depict the actual device that you are installing. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 27 Mounting on a desktop or flat surface FIGURE 9 Attaching the adhesive feet on a compact device Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 28: Mounting The Compact Device With A Magnet

    Use the magnet-mount kit to mount the device on a metal wall or a metal surface, including underneath a metal desk. The magnet- mount kit is available for order separately from the device and consists of a single magnet sheet. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 29: Attaching The Magnet Sheet To The Device

    Before mounting the device using the magnet sheet, make sure the rubber feet are not installed on the device to ensure that the magnet sheet holds on to the device strongly and does not detach. If the rubber feet are already installed, remove them first before attaching the magnet sheet. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 30: Mounting The Device On A Metal Surface Or Metal Wall

    Complete the following steps to securely mount a compact device on a metal surface or metal wall: Ensure that the magnet sheet is attached to the bottom panel of the device. Refer to Attaching the magnet sheet to the device on page 29. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 31 Place the magnet sheet (with the logo side now attached to the bottom panel of the device) against the metal surface or metal wall. FIGURE 12 Mounting a compact device to a metal surface using the magnet mount Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 32: Mounting The Device Under A Metal Desk

    Complete the following steps to securely mount a compact device under a metal desktop: Ensure that the magnet sheet is attached to the bottom panel of the device. Refer to Attaching the magnet sheet to the device on page 29. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 33 Place the bottom panel of the device with the magnet sheet attached under the metal desk, against the side of the device. Ensure that the front panel (port side) of the device is facing downward. FIGURE 14 Mounting a compact device underneath a metal desktop using the magnet mount Magnet Metal desk Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 34: Mounting The Compact Device Under A Fixed Surface

    Use the following items to mount the device under a fixed surface such as under a desk, or under a shelf. • #2 Phillips screwdriver • Hammer • Drill • Mounting anchors • Wall / under desk mount kit (ICX7000-C12-WMK - short brackets) or two-post rack mount kit (ICX7000-C12-RMK - long brackets) Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 35 When mounting the device under a fixed surface, under a desk, or under a shelf, use the long brackets to provide adequate ventilation and not exceed the operating temperature. CAUTION Do not install the device in an environment where the operating ambient temperature might exceed 35°C (95°F). Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 36 Using a Phillips screwdriver, attach the mounting brackets to the diagonally opposite sides of the device using two #6-32 sink- head screws on each side. FIGURE 16 Mounting a compact device under a fixed surface with short brackets (ICX7000-C12-WMK) Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 37: Mounting The Compact Device Directly On A Wall

    • Wall mount anchors • Wall mount screws • Wall Mount Holes Location template • Tape NOTE When mounting the device on a wall, mount the device with the port side down. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 38 Using the Wall Mount Holes Location template as a guide, drill two holes in the wall where you want to mount the device. Hammer the wall-mount anchors into the two holes. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 39 FIGURE 18 Preparing to wall mount the device Drilled holes in wall Wall-mount anchors Wall-mount screws 4.0-4.5 mm space between screw head and wall Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 40 FIGURE 19 Wall mounting a compact device - View of rear panel Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 41: Mounting On A Wall Using The Wall Mount Brackets

    Mount the devices that have fans such that there is enough space for ventilation on the air-intake and air-exhaust sides to maintain the ambient operating temperature. DANGER This equipment is suitable for mounting on concrete or other noncombustible surfaces only. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 42 The hardware device illustrated in this procedure is only for reference and may not depict the actual device that you are installing. Complete the following steps to mount the device to a wall. Attach the four adhesive feet to the bottom of the device. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 43 Using a Phillips screwdriver, attach the wall mount brackets to the sides of the device using four #6-32 sink-head screws on each side. FIGURE 21 Attaching the wall mount brackets to a 24-port device Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 44 FIGURE 22 Attaching the wall mount brackets to a 48-port device Drill two holes on the wall where you want to mount the device. Hammer two wall mount anchors into the holes on the wall. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 45 Use the two wall mount screws to fasten the device to the wall mount anchors. FIGURE 23 Wall mounting a 24-port device with port-side up Drilled holes Wall mount screws Wall mount anchors Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 46: Mounting On A Two-Post Rack

    Mounting on a two-post rack The devices use stationary mounting when mounted in a rack. DANGER Make sure the rack housing the device is adequately secured to prevent it from becoming unstable or falling over. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 47 You need a #2 Phillips screwdriver for rack mount installation. NOTE The ICX 7150-C12P compact device requires the ICX7000-C12-RMK rack mount kit which is optionally orderable. Complete the following steps to mount devices in a rack. Remove the rack mounting kit from the shipping carton. The kit contains two L-shaped mounting brackets and six sink-head screws.
  • Page 48 Mounting on a two-post rack Using a Phillips screwdriver, attach the mounting brackets to the sides of the device using six sink-head screws. FIGURE 25 Attaching the mounting brackets for a compact device Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 49 Remove the two-post rack kit from the shipping carton. The kit contains four rack-mounting screws and four cage nuts. Insert the cage nuts in the two-post rack where you want to mount the device. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 50 Mounting on a two-post rack Using a Phillips screwdriver, mount the device in a two-post rack using four rack-mounting screws. FIGURE 27 Installing a compact device in a two-post rack Rack-mounting screws Cage nuts Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 51: Installing The 1U, 1.5U, And 2U Universal Kit For Four Post Racks (Xbr-R000295)

    Use the following instructions to install a 1U, 1.5U, or 2U device in a 19-in. (48.3 cm) EIA rack using the 1U, 1.5U, and 2U Universal Kit for Four Post Racks (XBR-R000295). Any updates to these instructions will be added to the hardware installation guide for your product. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 52: Time And Items Required

    Use the screws specified in the procedure. Using longer screws can damage the device. Parts list The following parts are provided with the 1U, 1.5U, and 2U Universal Kit for Four Post Racks Installation (XBR-R000295). Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 53: Flush-Front Mounting The Device In The Rack

    Use the screws specified in the procedure. Using longer screws can damage the device. Flush-front mounting the device in the rack CAUTION The device must be turned off and disconnected from the fabric during this procedure. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 54: Attaching The Front Brackets

    Use the upper and lower screw holes, leaving the center holes empty. Repeat Step 1 Step 2 to attach the left front bracket to the left side of the device. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 55: Attaching The Extension Brackets To The Device

    Use the upper and lower screw holes, leaving the center holes empty. Repeat Step 1 Step 2 to attach the left extension bracket to the left side of the device. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 56: Installing The Device In The Rack

    Attach the left front bracket to the left front rack post using two 10-32 x 5/8-in. panhead screws and two retainer nuts. Use the upper and lower holes in the bracket. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 57: Attaching The Rear Brackets To The Extensions

    Attach the brackets using four 6-32 x 1/4-in. panhead screws. Repeat Step 2 Step 3 to attach the left rear bracket to the left extension. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 58 Adjust the brackets to the rack depth and tighten all the 6-32 x 1/4-in. screws to a torque of 9 in-lb (10 cm-kg). FIGURE 33 Attaching the rear brackets to the extensions Rear brackets Screws, 6-32 x 1/4-in., panhead Phillips FIGURE 34 Attaching the medium or long rear brackets to the extensions Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 59: Attaching The Rear Brackets To The Rack Posts

    Tighten all the 10-32 x 5/8-in. screws to a torque of 25 in-lb (29 cm-kg). FIGURE 35 Attaching the rear brackets to the rack posts Screws, 10-32 x 5/8-in., panhead Phillips Retainer nuts, 10-32 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 60: Flush-Rear (Recessed) Mounting The Device In The Rack

    Use the upper and lower screw holes, leaving the center holes empty. Repeat Step 1 Step 2 to attach the left rear bracket to the left side of the device. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 61: Attaching The Extensions To The Front Of The Device

    Position the right extension along the side of the device as shown in Figure Attach the bracket using four 8-32 x 5/16-in. flathead screws. Repeat Step 1 Step 2 to attach the left front extension to the left side of the device. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 62: Installing The Device In The Rack

    Attach the left front bracket to the left rear rack post using two 10-32 x 5/8-in. panhead screws and two retainer nuts. Use the upper and lower holes in the bracket. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 63: Attaching The Rear Brackets To The Extensions At The Front Of The Device

    Attach the brackets using four 6-32 x 1/4-in. screws. Repeat Step 2 Step 3 to attach the left rear bracket to the left extension. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 64 Adjust the brackets to the rack depth and tighten all the 6-32 x 1/4-in. screws to a torque of 9 in-lb (10 cm-kg). FIGURE 39 Attaching the rear brackets to the extensions at the front of the device Rear brackets, short Screws, 6-32 x 1/4-in., panhead Phillips Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 65: Attaching The Rear Brackets To The Front Rack Posts

    41. Use the upper and lower holes in the bracket. Attach the left rear bracket to the left front rack post using two 10-32 x 5/8-in. screws and two retainer nuts. Use the upper and lower holes in the bracket. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 66 Tighten all the 10-32 x 5/8-in. screws to a torque of 25 in-lb (29 cm-kg). FIGURE 41 Attaching the rear brackets to the front rack posts Screws, 10-32 x 5/8-in., panhead Phillips Retainer nuts, 10-32 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 67: Initial Setup And Verification

    Power is supplied to the device as soon as the first power supply is connected and turned on. If the power indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 68: Establishing A First-Time Connection To The Console Port

    If the workstation is unable to automatically discover and configure the newly found USB device, you can manually download the necessary device drivers for Windows, MacOS, and Linux from the following website: http:// www.silabs.com/products/development-tools/software/usb-to-uart-bridge-vcp-drivers#mac Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 69 CONFIG: The configuration level. This level allows you to configure the system IP address and configure switching and routing features. To access the CONFIG mode, you must already be logged in to the privileged EXEC level. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 70: Recovering From A Lost Password

    While the system is booting, before the initial system prompt appears, enter b to enter the boot monitor mode. Enter no password. (You cannot abbreviate this command.) Enter boot. This command causes the device to bypass the system password check. After the console prompt reappears, assign a new password. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 71: Configuring An Ip Address For The Device

    The messages that appear in the log are labeled with the chassis name, which makes tracking the errors much easier. Specify an easily understandable and meaningful host name and chassis name. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 72: Setting The Date And Time

    At this point, the device can be accessed remotely using the CLI or Brocade Network Advisor. Ensure that the device is not being modified from any other connections. The Ethernet management port also supports auto-MDI and auto- MDIX. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 73: Getting In-Band Access

    2001:DB8:e0ff:7837::3 newrun.cfg This command example copies the running configuration to a TFTP server with the IPv6 address of 2001:DB8:e0ff:7837::3 and names the file on the TFTP server newrun.cfg. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 74 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 75: Installing Transceivers And Cables

    Most Brocade switches come with a transceiver extraction tool and holster. The extraction tool is designed to remove transceivers from modules where the space is limited. FIGURE 42 Optical transceiver extraction tool Precautions specific to transceivers and cables DANGER The procedures in this manual are for qualified service personnel. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 76: Managing Cables

    The 802.3ab standard (automatic MDI or MDIX detection) calls for automatic negotiation of the connection between two 1000Base-T ports. In this case, a straight-through cable may work just as well as a crossover cable. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 77 Media Dependent Interface Crossover (auto-MDIX) detection. Auto-MDI or auto-MDIX is enabled on all 10/100 and 1000 Mbps copper ports by default. For each port, you can disable auto-MDI or auto-MDIX, designate the port as an MDI port, or designate the port as an MDIX port. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 78: Cleaning The Fiber-Optic Connectors

    Put on the ESD wrist strap and ground yourself by attaching the clip end to a metal surface (such as an equipment rack) to act as ground. Remove the new transceiver from the protective packaging. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 79: Cabling A Fiber-Optic Transceiver

    Gently insert the cable connector (a tab on each connector should face upward) into the transceiver connector until the tabs lock into place. Observe the link and active LEDs to determine if the network connections are functioning properly. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 80: Replacing A Fiber-Optic Transceiver

    The bail latch may be attached to either the top or the bottom of the SFP transceiver. Grasp the bail latch and pull the transceiver out of the port. FIGURE 47 Removing the fiber-optic module Store the transceiver in a safe, static-free place or in an anti-static bag. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 81 Replacing a fiber-optic transceiver If you are installing a new module or replacing a module, install the new module in the port. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 82 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 83: Monitoring The Device

    After you install the network cables, you can observe certain LEDs to determine if the network connections are functioning properly. The tables in this section outline the state of each LED, the status of the hardware, and any recommended action. FIGURE 48 Port-side LEDs of ICX 7150-C12P Port status mode selection button (not enabled currently) 10.
  • Page 84 RJ-45 port 13 status LED 19. OOB RJ-45 port RX LED 10. RJ-45 port 13 RX/TX activity LED NOTE ICX 7150-24P has an additional PoE status mode LED (however not enabled currently) . Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 85: System Leds

    Interpreting port-side LEDs FIGURE 50 Port-side LEDs of ICX 7150-48, ICX 7150-48P and ICX 7150-48PF Port status mode selection button (not enabled currently) 11. RJ-45 port 11 RX/TX activity LED Port link status mode LED (not enabled currently) 12. RJ-45 uplink port C1 status LED Port speed status mode LED (not enabled currently) 13.
  • Page 86 Power cycle the device to try and clear the condition. • If the condition persists, contact Technical Support. Cloud management status LED Refer to the following table to interpret the cloud management status LED. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 87: Rj-45 Ethernet Port Status Led In Default Mode

    Verify that the port has not been disabled through a configuration change. You can use the CLI. If you have configured an IP address on the device, you also can use the Web management interface or Brocade Network Advisor. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 88: Sfp+ Port Status Led Default Mode

    Flashing amber The port is transmitting and receiving user packets at 1 None. Gbps. Interpreting nonport-side LEDs There are no LEDs found on the nonport-side view of the Ruckus ICX 7150 devices. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 89: Pinging An Ip Address

    If the switch reaches the high limit temperature, the fans operate at high speed until the switch reaches the low limit temperature specified in the table, at which Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 90 Sensor B Temperature Readings: Current temperature : 55.0 deg-C Sensor A Temperature Readings: Current temperature : 50.0 deg-C Warning level..: 71.0 deg-C Shutdown level..: 105.0 deg-C Boot Prom MAC : 748e.f8ea.0360 Manageme Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 91: Ruckus Icx 7150 Switch Technical Specifications

    System component Description Ethernet ports ICX 7150-C12P: Twelve RJ-45 GbE with 802.3at PoE+, two RJ-45 GbE uplink, two SFP+ 10-GbE uplink/ stacking ICX 7150-24: Twenty-four RJ-45 GbE, two RJ-45 GbE uplink, four SFP+ 10-GbE uplink/stacking Ruckus ICX 7150 Switch Hardware Installation Guide...

  • Page 92: Leds

    LEDs System component Description ICX 7150-24P: Twenty-four RJ-45 GbE with 802.3at PoE+, two RJ-45 GbE uplink, four SFP+ 10-GbE uplink/ stacking ICX 7150-48: Fourty-eight RJ-45 GbE, two RJ-45 GbE uplink, four SFP+ 10-GbE uplink/stacking ICX 7150-48P: Fourty-eight RJ-45 GbE with 802.3at PoE+, two RJ-45 GbE uplink, four SFP+ 10-GbE uplink/stacking ICX 7150-48PF: Fourty-eight RJ-45 GbE with 802.3at PoE+, two RJ-45 GbE uplink, four SFP+ 10-GbE...

  • Page 93: Weight And Physical Dimensions

    (Typical) For the ICX 7150-C12P, the maximum operating temperature is 40°C when under fully loaded PoE conditions or when installed using the long bracket (ICX7000-C12-RMK) under a fixed surface. The maximum operating temperature is 35°C when installed using the short bracket (ICX7000-C12-WMK) under a fixed surface.

  • Page 94: Power Supply Specifications (Per Psu)

    (fanless mode is not supported) Power supply specifications (per PSU) All the Ruckus ICX 7150 power supply units (PSUs) are fixed and internal to the device. All the PSUs use a C14 inlet and connect to standard AC power. Device...

  • Page 95: Power Consumption (Idle Configuration)

    Fans always running. Power consumption (typical configuration) Typical: 10% traffic rate on all ports with 64-byte packet size and random payload at room temperature. All ports fully configured. Fans at nominal speed. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 96: Power Consumption (Maximum Configuration)

    1.59 A 0.80 A 12 1-GbE and 2 10- GbE ports are linked 157.21 W 153.39 W UP ONLY. 536.57 BTU/hr 523.53 BTU/hr 100% traffic. 100% PoE Load @ Class 3 (15.4 W/port) Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 97: Data Port Specifications (Ethernet)

    3048.90 BTU/hr 10% traffic. 100% PoE Load @ Class 3 (15.4 W/port) Data port specifications (Ethernet) NOTE The ICX 7150 10-GbE ports provide both active and passive cable support. Model Port type Number of ports Description ICX 7150-C12P GbE (copper)

  • Page 98: Serial Port Specifications (Pinout Rj-45)

    DDR4 SDRAM (not ECC capable) 1 GB Regulatory compliance (EMC) • FCC Part 15, Subpart B • EN 55024 • EM 55032 (CE Mark) (Class A) • ICES-003 • VCCI • EN 300 386 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 99: Regulatory Compliance (Safety)

    • 30/2011/TT-BCT - Vietnam circular. • SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China). Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 100 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 101: Regulatory Statements

    Refer to the latest revision of the China ROHS document (P/N 53‐1000428‐xx) which ships with the product. BSMI statement (Taiwan) Warning: This is Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 102: Canadian Requirements

    This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations, ICES-003 Class A. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. China CCC statement Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 103: Europe And Australia (Cispr 32 Class A Warning)

    This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 104 Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 105: Cautions And Danger Notices

    Vérifiez que rien ne restreint la circulation d'air devant, derrière et sur les côtés du dispositif et qu'elle peut se faire librement. PRECAUCIÓN Asegúrese de que el flujo de aire en las inmediaciones de las partes anterior, laterales y posterior del instrumento no esté restringido. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 106 No instale el dispositivo sobre una superficie con el panel superior mirando hacia abajo. Instale el dispositivo solamente sobre una superficie metálica vertical con el panel frontal de los puertos de usuario orientado hacia abajo. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 107: Electrical Cautions

    La electricidad estática puede dañar el chasis y otros dispositivos electrónicos. A fin de impedir que se produzcan daños, conserve los dispositivos susceptibles de dañarse con la electricidad estática dentro de los paquetes protectores hasta que esté listo para instalarlos. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 108: Danger Notices

    Un énoncé de danger indique des conditions ou des situations potentiellement mortelles ou extrêmement dangereuses. Des étiquettes de sécurité sont posées directement sur le produit et vous avertissent de ces conditions ou situations. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 109: General Dangers

    Assurez-vous que les circuits de la source d'alimentation soient équipés de mise à la terre. PELIGRO Asegúrese que los circuitos de la fuente de energia cuenten con una conexión a tierra apropriada. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...
  • Page 110 Das eingeschaltete Gerät darf nicht geöffnet werden, da andernfalls das Risiko eines Stromschlags mit Hochspannung besteht. DANGER Afin d'éviter tout choc électrique, n'ouvrez pas l'appareil lorsqu'il est sous tension. PELIGRO Para evitar una descarga de alto voltaje, no abra el dispositivo mientras esté encendido. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 111: Dangers Related To Equipment Weight

    PELIGRO Monte los instrumentos que instale en un bastidor lo más bajos posible. Ponga el instrumento más pesado en la parte inferior y los instrumentos progresivamente más livianos más arriba. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

  • Page 112: Laser Dangers

    60825 y EN60825, y con los estándares de rendimiento Clase 1 de FDA definidos en el subcapítulo I de 21 CFR. Los productos ópticos que no cumplan con estos estándares pueden emitir luz dañina para los ojos. Ruckus ICX 7150 Switch Hardware Installation Guide 53-1004928-02...

Table of Contents

Save PDF
