MOUNTING OF THE BIKE CARRIER ON THE ROOFBAR

Step 1
Put the bike carrier on the roofbar of the car. Make sure that the fixation-frame
(Bracket with two "arms") is right above the first (front) tube. Place the two
double slide screws from bottom to top over the tube of the roofbar and through
the holes of the fixation-frame. Put washer and plastic wing nuts on each screw
and tighten them so the bike carrier can not move on the tube anymore
Step 2
Place the double slide screw over the back tube of your roof-rack. Mount the
bottom plate against the bottom of the tube and place the screws through the
pre-mounted holes of the bottom plate. Put washer and plastic star knob on each
screw and tighten them so the bike carrier can not move on the roof-rack
anymore.
Important: Please make sure that all wing nuts have been well tightened and
the bike carrier can not move on the roofbar.
The bike carrier is now ready for use!
