Zephyr Tidal II AK7400AS Use, Care And Installation Manual page 35

ZEPHYRONLINE.COM
Body
Single Blower
Dual Blower
Tidal II Use, Care, and Installation Guide
AK7448AS Wiring Diagram
Black
White
LED LED LED
MOTOR-2
BODY
Black
Body
ANT
WIFI
LED
WIFI
K
MOTOR-1
Wiring Diagram
Motor
A. Wi-Fi connection wire
B. LED PCB wire
C. Power wire for expansion PCB
D. Power wire for expansion PCB
E. Blower connection wire
F. Blower connection wire
G. Control connection wire
H. Dual blower PCB to switch wire
I. Power lead
J. Dual blower connection wire
K. Blower connection wire
35
