BODY
Power consumption shown for default 600 CFM blower configuration
ACT 390 CFM - Fan Max. 393W @ 3.3A
ACT 290 CFM - Fan Max. 365W @ 3.0A
Modena Use, Care, and Installation Guide
ZMO-M90BS
CIRCUIT DIAGRAM
MOTOR
WHITE
Wiring Diagram
VOLTS HZ MAX. AMPS
120 60
RED
YELLOW
BLUE
BROWN
GREY
WHITE
GREEN
BODY
YELLOW
LED
LED
LED
LED
5
YELLOW
