Enabling ACT™
Modena Use, Care, and Installation Guide
FIG. E
7 8
5 6
3 4
1 2
J u m p e r 3 - 4
Max. Blower CFM
PC Board
FIG. F
ACT™ Conversion
Jumper Pins
7 8
5 6
3 4
1 2
J u m p e r 5 - 6 or 7-8
DEFAULT POSITION
Default Max. Blower CFM
7 8 7
5 6 5
3 4 3
1 2 1
J u m p e r 1 - 2
Max. Blower CFM
390
Plastic
Jumper
8
6
4
2
290
