- Page 1 CK171000TX Hendrik Cocktail Table Trunk For assistance with assembly, contact: Southern Enterprises Inc. Customer Service: 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#: Page | 1...
- Page 2 Hendrik Cocktail Table Trunk Parts List Please review all parts and hardware before disposing of any packaging. Before beginning assembly, separate each type of hardware. Carefully study the diagrams below and check that you have all parts indicated. Call Customer Service if missing hardware. Using the incorrect hardware will cause damage.
- Page 3 Quantity Quantity Quantity of 2 of 2 Front Knobs-A Front Knobs-B Hinges Quantity Quantity Quantity f 16 Screws Ø 1/8” x 1/2”L Side Handles Bolts Ø 5/32” x 1/2”L Quantity Quantity of 3 of 8 Adhesive Pads Cotton Mats Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth.
- Page 4 Hendrik Cocktail Table Trunk Assembly Instructions Start screwing with fingers to help align Cam Bolts. Screw Cam Bolts (A) into holes on Front Panel (4) and Back Panel (5). Attach Front Panel (4) and Back Panel (5) to Bottom Panel (6) by inserting Cam Bolts (A) into corresponding holes.
- Page 5 Screw Cam Bolts (A) and insert Wood Dowels (C) into holes on Left Side Panel (2). Attach Left Side Panel (2) to assembled unit by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes. Insert Cam Locks (B) into holes on Bottom Panel (6), Front Panel (4) and Back Panel (5).
- Page 6 Start with finger to help align Bolts. Attach Side Knobs (K) to Side Panels (2/3) using Bolts (L). Tighten Bolts with Phillips screwdriver. Place Adhesive Pads (M) on top corners of Front Panel (4) as shown. Close Top (1) and let it drop down slowly. Figure 5 Now your Hendrik Cocktail Table Trunk is ready to use!
- Page 7 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
