- Page 1 CK494300TX Cheswick Console For assistance with assembly, contact: Assembly Instructions Southern Enterprises, Inc. Customer Service: 1-800-633-5096 service@seidal.com www.seidal.com PO：13865 Page | 1...
-
Page 2: Parts List
Cheswick Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. - Page 3 Cheswick Console Assembly Instructions Attach Leg (B) intoTop Panel (A) by hand as shown. Figure 1 Attach Bottom Frame (C) with Leg (B), secure with Feet (E) by hand as shown. Figure 2 Page | 3...
- Page 4 Secure the Bottom Frame (C) with Feet (E) using L Bracket (2), Bolt (1), Spring Washer (3) and Flat Washer (4). Tighten bolt with Allen Wrench (5) Figure 3 Turn the assembled unit over. Figure 4 Page | 4...
- Page 5 Place the Glass (D) intoTop Panel (A). Figure 5 Now the console is ready to use. Figure 6 Page | 5...
-
Page 6: Parts Replacement Form
For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
