- Page 1 CK622400TX- Espresso CK612400TX- Black For assistance with assembly contact: Nailhead Cocktail Table Trunk Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#12972 Max Top Load 80 lbs. Max Load Inside the Trunk 100 lbs.
- Page 2 CK622400TX- Espresso/ CK612400TX- Black Nailhead Cocktail Table Trunk Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
- Page 3 8 PCS 8 PCS 1 PC Cam Bolt Cam Lock ϕ6.8 x 36mm ϕ15 x 12mm Wrench 8 PCS 8 PCS 35 PCS ϕ8 x 30mm ϕ ¼” x 2 ¾” ϕ 3.5 x 16mm Dowel Bolt Screw 1 PC 1 PC 1 PC Left-Support...
- Page 4 CK622400TX- Espresso/ CK612400TX- Black Nailhead Cocktail Table Trunk Assembly Instructions Please do not over-tighten cam bolts, please stop when you feel them tighten. Attach handle (O) to the top (A) using screws (M) and tighten with Phillips screwdriver as shown.
- Page 5 Attach handle (Q) to left side panel (D) and right side panel (G) using screws (M) and tighten with Phillips screwdriver as shown. Screw small cam bolts (H) into back panel (C) as shown. Insert dowels (K) into left side panel (D) and right side panel (G) as shown.
- Page 6 Turn the trunk base upside down and attach legs (F) to the bottom of trunk using screws (L) as shown. Attach hinge (T) to back panel (C) and top panel (A) by using screws (M) as shown and tighten all screw with Phillips screwdriver. Attach left support (N) and right support (R) to the top (A) and trunk base using screws (M) and tighten with Phillips screwdriver as...
- Page 7 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
