- Page 1 VCC-G20S20B Rev.900-740-33 English Analog I/F 29mm Cubic SXGA B/W Analog Camera VCC-G20S20B Product Specification & Operational Manual CIS Corporation ©2014 CIS Corporation. All rights reserved.
-
Page 2: Table Of Contents
7.2.4. 1/4 Partial Scan Mode ........................17 8. CCD Optical Axis Accuracy ........................18 9. Dimensions ............................19 10. Cases for Indemnity (Limited Warranty) ....................20 11. CCD Pixel Defect ..........................20 12. Product Support ..........................20 ©2014 CIS Corporation. All rights reserved. -
Page 3: Scope Of Application
VCC-G20S20B Rev.900-740-33 1. Scope of Application This is to describe VCC-G20S20B analog B/W CCD Camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life. -
Page 4: Product Outline
Rev.900-740-33 3. Product Outline VCC-G20S20B is a high-resolution industrial B/W analog camera module utilizing a 1/2” inch PS IT CCD. 1.45M pixels CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. Only 29mm cubic in size (excluding projection), light weight 50g, and speed makes it a best match for use in embedded systems. -
Page 5: Specification
Approx. 45 g Lens mount C mount (Refer to overall dimension drawing) Optical axis accuracy Refer to drawing for CCD Optical Axis Accuracy (Clause 8) Over 0～12dB (guaranteed range) Gain variable range Gamma 1 (fixed) ©2014 CIS Corporation. All rights reserved. - Page 6 X, ±Y, and ±Z, total 6 directions. (without package) Operation guaranteed: -5℃～+45℃ Temperature Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity -25℃ ～ +60℃ Temperature Storage environment RH 20～80% with no condensation Humidity ©2014 CIS Corporation. All rights reserved.
-
Page 7: Camera Output Signal Specification
47pF VS output 1.0V (p-p), Sync. Negative, 75Ω unbalanced, DC connect White clip level: 840 ± 70 mVp-p Video signals Setup level: 25 ± 15 mVp-p (Gain 0dB) SYNC level: 290 ± 50 mVp-p ©2014 CIS Corporation. All rights reserved. -
Page 8: Ccd Spectral Response (Representative Value)
● SCAN EN ◇ Scan Enable (No.9 pin of the circular connector valid/invalid) ● IN/OUT ◇ HD/VD signals input/output settings (No.6 and 7 pins of the circular connector) ● indicates initial setting position. ● ©2014 CIS Corporation. All rights reserved. - Page 9 Partial Scan mode ○ ○ ○ ○ HD/VD Input ○ HD ○ HD ○ ○ HD/VD Output × ○ ○ ○ ※1 When using the camera at Restart-Reset mode, shutter speed settings shall be OFF. ©2014 CIS Corporation. All rights reserved.
- Page 10 Restart-reset mode corresponds to all scanning modes. External VD Exposure Time External HD Read Out Signal Exposure Time Video Output 18 H 1040H At Full Frame Scan WEN Output 1 V min ©2014 CIS Corporation. All rights reserved.
- Page 11 Conditions: Trigger input pulse width shall be 4μs～250ms, Positive Logic Trigger Input Trigger Pulse Width ： 4μ s～250ms. Read Out Signal Exposure Time Trigger Pulse Width Internal HD or External HD Internal VD Output 1～2 Video Output Video Active Period 1040 WEN Output ©2014 CIS Corporation. All rights reserved.
- Page 12 Trigger Input Discharge Read OUT Exposure Time ±0.035μ s ±0.035μ s Exposure = Trigger Width + 5μ s Exposure Time ©2014 CIS Corporation. All rights reserved.
- Page 13 1/2, 1/4 Partial Scan mode Changing the settings of 75ohm HD/VD input impedance HD/VD input impedance 10kΩ HD/VD input impedance 75Ω Changing HD/VD input and output SW10 HD/VD output HD/VD input Indicates initial setting position ©2014 CIS Corporation. All rights reserved.
-
Page 14: External Connector Pin Assignment
VCC-G20S20B Rev.900-740-33 6. External Connector Pin Assignment 12 pins Circular Connector SNH-10-12 (RPCB) (SAMWOO) Pin No. Power In DC+12V Video Out HD In/Out VD In/Out Scan In WEN Out Trig In ©2014 CIS Corporation. All rights reserved. -
Page 15: Timing Chart
1V = 1068H Camera VD Output Black Transmit Black Effective Pixels Black 1040 Exposure Time Read Out Signal Discharge Signal Video Output Vertical Blanking Video Output Active Period 28 H 1040 H WEN Output ©2014 CIS Corporation. All rights reserved. -
Page 16: Binning Scan Mode
7.2.3. 1/2 Partial Scan Mode 1V = 534H Camera HD Camera VD High Speed Transmit Period High Speed Transmit Period VΦ Pulse Read Out Signal Discharge Signal Exposure Time WEN Output Video Output Active Period 465H Video Output ©2014 CIS Corporation. All rights reserved. -
Page 17: 1/4 Partial Scan Mode
1V = 267H Camera HD Camera VD High Speed Transmit Period High Speed Transmit Period VΦ Pulse Read Out Signal Discharge Signal Exposure Time WEN Output 46 H Video Output Active Period 169 H Video Output ©2014 CIS Corporation. All rights reserved. -
Page 18: Ccd Optical Axis Accuracy
?? ±0.5° The center of effective pixels shall be within f 0.6 to the center of lens mount. (*) Dimension from datum plane to the center of lens mount. 910-005-00-00 (Unit: mm) ©2014 CIS Corporation. All rights reserved. -
Page 19: Dimensions
VCC-G20S20B Rev.900-740-33 9. Dimensions ©2014 CIS Corporation. All rights reserved. -
Page 20: Cases For Indemnity (Limited Warranty)
On very rare occasions, however, CCD pixel defects might be noted with time of usage of the products. Cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS is exempted from taking any responsibilities for them.
