CIS VISION:analog VCC-G20S20A Product Specification & Operational Manual

29mm cubic sxga b/w analog camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-G20S20A
Rev.900-651-33-00
English
29mm Cubic SXGA
B/W Analog Camera
VCC-G20S20A
Product Specification
& Operational Manual
CIS Corporation
©2010 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISION:analog VCC-G20S20A and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VISION:analog VCC-G20S20A

Summary of Contents for CIS VISION:analog VCC-G20S20A

  • Page 1 VCC-G20S20A Rev.900-651-33-00 English 29mm Cubic SXGA B/W Analog Camera VCC-G20S20A Product Specification & Operational Manual CIS Corporation ©2010 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    7.4.3. Pulse Width Trigger Shutter Mode 2 (SYNC Non-Reset) ..............17 8. CCD Optical Axis Accuracy ........................18 9. Dimensions ............................19 10. Cases for Indemnity (Limited Warranty) ....................20 11. CCD Pixel Defect ..........................21 12. Product Support ..........................21 ©2010 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    The voltage ripple of camera power DC +12V±10% shall be within ±50mV. Improper power supply voltage may cause noises on the video signals. In case of abnormal operation, contact the distributor from whom you purchased the product. ©2010 CIS Corporation. All rights reserved.

  • Page 4: Product Outline

    Scanning system is switchable by the input level to 9pins circular connector at rear. □ Only 29mm cubic in size (excluding projection) □ As an optional function, γ=0.45, HD/VD 75Ωimpedance can be set as the factory initial setting. □ Please ask us for the details. ©2010 CIS Corporation. All rights reserved.

  • Page 5: Specification

    1 (fixed) Shutter speed Fixed Switch: OFF (1/15), 1/100, 1/250, 1/500, 1/1,000, 1/2,000, 1/5,000, variable range 1/10,000s Pulse Width: 10μs ～ 250ms ・Fixed trigger shutter mode ・Pulse width trigger shutter mode Trigger shutter mode ©2010 CIS Corporation. All rights reserved.
  • Page 6 (100G) for X, Y, Z direction. (without package) Temperature Operation guaranteed: -5℃～+45℃ Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity Temperature -25℃ ～ +60℃ Storage environment RH 20～80% with no condensation Humidity ©2010 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    VS output 1.0V (p-p), Sync. Negative, 75Ω unbalanced, DC connect White clip level: 840 ± 70 mVp-p Setup level: 25 ± 15 mVp-p (Gain 0dB) SYNC level: 290 ± 50 mVp-p VS DC level: 0 ± 100 mV ©2010 CIS Corporation. All rights reserved.

  • Page 8: Ccd Spectral Response (Representative Value)

    HD/VD signals input/output settings (No.6 and 7 pins of the circular connector) ● indicates initial setting position. ● Other Optional Functions (Ex-factory setting) ◇ HD/VD75Ωimpedance ◇ γ= 0.45 compensation Please ask us for the details. ©2010 CIS Corporation. All rights reserved.
  • Page 9 ○ Partial Scan mode ○ ○ ○ ○ HD/VD Input ○ ○ ○ ○ HD/VD Output × ○ ○ ○ ○1 When using the camera at Restart-Reset mode, shutter speed settings shall be OFF. ©2010 CIS Corporation. All rights reserved.
  • Page 10 HD external input is valid but VD external input invalid. Exposure time = Trigger pulse width (μs) + 5μs typical Conditions: Trigger input pulse width shall be 4μs～250ms, Positive Logic The shortest trigger cycle = 1 frame + 5H ©2010 CIS Corporation. All rights reserved.
  • Page 11 Caution 3: Please refer to the timing chart below for the actual time when exposure starts after trigger is input, and the actual time when exposure completes at pulse width trigger shutter mode. Trigger Input Discharge Read OUT Exposure Time ±0.035μs ±0.035μs Exposure = Trigger Width + 5μs Exposure Time ©2010 CIS Corporation. All rights reserved.
  • Page 12 Full Frame Scan mode Binning Scan mode Partial Scan mode Changing the gain settings 0dB fixed Manual gain (MGC volume of rear panel) Changing HD/VD input and output SW10 HD/VD output HD/VD input Indicates initial setting position ©2010 CIS Corporation. All rights reserved.

  • Page 13: External Connector Pin Assignment

    VCC-G20S20A Rev.900-651-33-00 6. External Connector Pin Assignment 12 pins Circular Connector SNH-10-12 (RPCB) (SAMWOO) Pin No. Power In DC+12V Video Out HD In/Out VD In/Out Scan In WEN Out Trig In ©2010 CIS Corporation. All rights reserved.

  • Page 14: Timing Chart

    1V = 1068H Camera VD Output Black Transmit Black Effective Pixels Black 1040 Exposure Time Read Out Signal Discharge Signal Video Output Vertical Blanking Video Output Active Period 28 H 1040 H WEN Output ©2010 CIS Corporation. All rights reserved.

  • Page 15: Binning Mode

    7.2.3. 1/2 Partial Scan Mode 1V = 534H Camera HD Camera VD High Speed Transmit Period High Speed Transmit Period VΦ Pulse Read Out Signal Discharge Signal Exposure Time WEN Output Video Output Active Period 465H Video Output ©2010 CIS Corporation. All rights reserved.

  • Page 16: 1/4 Partial Scan Mode

    Video Output Active Period 169 H Video Output 7.3. Restart-Reset Mode (Long Exposure) Timing External VD Exposure Time External HD Read Out Signal Exposure Time Video Output 18 H 1040H At Full Frame Scan WEN Output 1 V min ©2010 CIS Corporation. All rights reserved.

  • Page 17: Trigger Shutter Mode Timing

    Trigger Input Trigger Pulse Width： 4μs～250ms. Read Out Signal Exposure Time Only Trigger Pulse Width. External HD External VD Input (Single Pulse) Wait Time 100ms (Max) 150μs Video Output Video Active Period 1040 WEN Output ©2010 CIS Corporation. All rights reserved.

  • Page 18: Ccd Optical Axis Accuracy

    ?? ±0.5° The center of effective pixels shall be within f 0.6 to the center of lens mount. (*) Dimension from datum plane to the center of lens mount. 910-005-00-00 (Unit: mm) ©2010 CIS Corporation. All rights reserved.

  • Page 19: Dimensions

    (M2 Size) Position *) C Mount screws comply with ANSI/ASME B1.1, 1-32UN(2B). *) Screw length from C mount lens surface shall be under 6mm. And protruding portion shall be less than 10mm. 999-492-00-00 (Unit :mm) ©2010 CIS Corporation. All rights reserved.

  • Page 20: Cases For Indemnity (Limited Warranty)

    In case damage or losses are caused by repair or modification conducted by the customer or any unauthorized third party (such as an unauthorized service representative). Expenses we bear on this product shall be limited to the individual price of the product. ©2010 CIS Corporation. All rights reserved.

  • Page 21: Ccd Pixel Defect

    On very rare occasions, however, CCD pixel defects might be noted with time of usage of the products. Cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS is exempted from taking any responsibilities for them.
