CIS VCC-GC20U11PCL Product Specification & Operational Manual

Camera link i/f 29mm cubic uxga high-speed b/w cmos pocl camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-GC20U11PCL
Rev.900-733-33
English
Camera link I/F
29mm cubic UXGA
High-Speed B/W CMOS PoCL Camera
VCC-GC20U11PCL
Product Specification
& Operational Manual
CIS Corporation
©2015 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-GC20U11PCL and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-GC20U11PCL

Summary of Contents for CIS VCC-GC20U11PCL

  • Page 1 VCC-GC20U11PCL Rev.900-733-33 English Camera link I/F 29mm cubic UXGA High-Speed B/W CMOS PoCL Camera VCC-GC20U11PCL Product Specification & Operational Manual CIS Corporation ©2015 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Remote Interface Function ........................... 18 Initial Settings ..............................19 CMOS Optical Axis Accuracy ..........................20 Dimensions ................................. 21 Cases for Indemnity (Limited Warranty) ........................ 22 Sensor Pixel Defect .............................. 22 Product Support ..............................22 ©2015 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    VCC-GC20U11PCL Rev.900-733-33 Scope of Application This is to describe VCC-GC20U11PCL, high-speed B/W CMOS Camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life.
  • Page 4 The rising time of camera power supply voltage shall be less than +10V, Max 60ms.  Please avoid noises like chattering when rising. Voltage Rising Time [ ms ] In case of abnormal operation, contact the distributor from whom you purchased the product. ©2015 CIS Corporation. All rights reserved.

  • Page 5: Notes On Partial Scan Mode Operation

    VCC-GC20U11PCL is an industrial B/W high-speed digital video camera module utilizing a global shutter type, 2/3 type 2M pixels CMOS sensor. Interface of VCC-GC20U11PCL complies with power over camera link (Base Configuration) with its resolution 2.2M pixels. Entire pixels can be read out within approx.

  • Page 6: Specification

    (18) Shutter speed OFF(1/70),1/500s,1/750s,1/1000s,1/1500s,1/2000s,1/2500s,1/4000s,1/5000s,1/10000s, variable range 1/15000s, 1/20,000s, 1/25,000s, 1/30,000s, 1/40,000s, 1/50,000s ・Fixed Trigger Shutter Mode (19) Trigger shutter mode ・Pulse Width Trigger Shutter Mode (Exposure time is set with the pulse width of trigger signal.) ©2015 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    Setup Level (5) Video output signal :Under ±04h for both vertical and horizontal. Digital 8bit Dark Shading (Conditions: Gain 0dB) 5 seconds shall be waited after turning on power to get proper camera operation. ©2015 CIS Corporation. All rights reserved.

  • Page 8: Cmos Spectral Response (Representative Value)

    VCC-GC20U11PCL Rev.900-733-33 CMOS Spectral Response (Representative value) 5.3. ※Lens characteristics and illuminant characteristics are not considered. Video Output Format 5.4. UXGA 70fps Mode: 2Tap Interleaved DA DB DA DB From Camera (2 Tap Output) ©2015 CIS Corporation. All rights reserved.

  • Page 9: Camera Link Port Data Bit Assignment (Base Configuration)

    Not in use DB:bit2 Port C3 Not in use DB:bit3 Port C4 Not in use DB:bit4 Port C5 Not in use DB:bit5 Port C6 Not in use DB:bit6 Port C7 Not in use DB:bit7 ©2015 CIS Corporation. All rights reserved.

  • Page 10: Function Settings

    ※ The setting will be 1 line when 0 is set. Manual Shutter Control 009&010 Exposure Time = The set value × 1line Time [s] 1line Time [s] = ((output pixels/2tap)+5)×1/79.99MHz At full frame scan, output pixels = 2050 1line Time ≒ 12.88μ s ©2015 CIS Corporation. All rights reserved.
  • Page 11 (output pixels = 640 + horizontal partial scan output pixels value x 10 9600bps 19200bps Remote Communication 38400bps Baud Rate Setting 57600bps 115200bps 5～255: 9600bps Data Save Input 083 to save address 000 ～ 031 to EEP-ROM. ©2015 CIS Corporation. All rights reserved.

  • Page 12: External Connector Pin Assignment

    26pins Mini Camera Link Connector 12226-1100-00 PL (SUMITOMO 3M) 7.1. Pin No. Pin No. DC +12V Xclk- Xclk+ SerTC+ SerTC- SerTFG- SerTFG+ CC1- (Trigger IN-) CC1+ (Trigger IN+) CC2+ CC2- CC3- CC3+ CC4+ CC4- DC +12V ©2015 CIS Corporation. All rights reserved.

  • Page 13: Timing Chart

    · · · · · · · 1085 1086 1087 1088 DVAL Output · · · · · · · FVAL Output 10 H 1088 H ※Video output signal delays by 2H from Exposure Time. ©2015 CIS Corporation. All rights reserved.

  • Page 14: Fixed Trigger Shutter Mode

    DVAL Output ・ ・ ・ ・ ・ FVAL Output 1088 H 10 H Trigger Input Exposure Time Exposure Time Delay(Fixed) (nHD 330ns ×12.88μ s ) ※Video output signal delays by 2H from Exposure Time. ©2015 CIS Corporation. All rights reserved.

  • Page 15: Pulse Width Trigger Shutter Mode

    1087 1088 DVAL Output ・ ・ ・ ・ ・ FVAL Output 1088 H 10 H Trigger Input Delay(Fixed) Delay(Fixed) 330ns 270ns Exposure Time Exposure Time ※Video output signal delays by 2H from Exposure Time. ©2015 CIS Corporation. All rights reserved.

  • Page 16: Partial Scan Mode

    S = 1318(Invalid) S = 1308 (with limitation) Horizontal partial scan Horizontal partial scan Starting position set value Starting position set value N = 740 (Horizontal partial scan when 10 is set as output pixels ) ©2015 CIS Corporation. All rights reserved.

  • Page 17: Vertical Partial Scan

    The set manual shutter lines ≦ Vertical partial scan output lines If the condition above is not met, shutter lines to be set will be the same number as vertical partial scan output lines. ©2015 CIS Corporation. All rights reserved.

  • Page 18: Remote Interface Function

    Note: Once the data was saved into EEPROM, it may not be reset to t he initial settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2015 CIS Corporation. All rights reserved.

  • Page 19: Initial Settings

    Manual Gain Control 0: 0dB Manual Shutter Control 009&010 1088: 1/70s Trigger Polarity 0: Positive Input Output Data Selection 0: 8bit Output Data Trigger Input Signals 2: OFF Camera Internal H Sync ON/OFF Baud Rate 0:9600bps ©2015 CIS Corporation. All rights reserved.

  • Page 20: Cmos Optical Axis Accuracy

    Inclination of effective pixels, Theta,?, to datum plane shall be ?? ±0.5° The center of effective pixels shall be within f 0.6 to the center of C lens mount (*) Dimensions from datum plane to the center of the lens mount 910-006-01-01 (Unit:mm) ©2015 CIS Corporation. All rights reserved.

  • Page 21: Dimensions

    VCC-GC20U11PCL Rev.900-733-33 Dimensions ©2015 CIS Corporation. All rights reserved.

  • Page 22: Cases For Indemnity (Limited Warranty)

    Sensor Pixel Defect Sensor pixel defects might be noted with time of usage of the products. Cause of the Sensor pixel defects is the characteristic phenomenon of CMOS itself and CIS is exempted from taking any responsibilities for them. Product Support When defects or malfunction of our products occur, and if you would like us to investigate on the cause and repair, please contact your distributors you purchased from to consult and coordinate.
