CIS VCC-F51U25CL Product Specification & Operational Manual

Uxga 3ccd color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-F51U25CL
Rev.900-667-31-01
English
UXGA 3CCD Color Camera
VCC-F51U25CL

Product Specification

& Operational Manual
CIS Corporation
©2010 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-F51U25CL and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-F51U25CL

Summary of Contents for CIS VCC-F51U25CL

  • Page 1: Product Specification

    VCC-F51U25CL Rev.900-667-31-01 English UXGA 3CCD Color Camera VCC-F51U25CL Product Specification & Operational Manual CIS Corporation ©2010 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Remote Interface Function ......................17 Initial Settings ........................... 18 CCD Optical Axis Accuracy ......................19 Dimensions ..........................20 Cases for Indemnity (Limited Warranty) ..................21 14. CCD Pixel Defect........................21 15. Product Support ........................21 ©2010 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    VCC-F51U25CL Rev.900-667-31-01 1. Scope of Application This is to describe VCC-F51U25CL, 3 CCD Color Camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life.
  • Page 4 The rising time of camera power supply voltage shall be less than +10V, Max 60ms.  Please avoid noises like chattering when rising. Voltage Rising Time [ ms ] In case of abnormal operation, contact the distributor from whom you purchased the product. ©2010 CIS Corporation. All rights reserved.

  • Page 5: Product Outline

    Rev.900-667-31-01 3. Product Outline VCC-F51U25CL is a camera link interfaced, 3CCD high-resolution industrial color video camera module utilizing a 1/1.8 type PS IT CCD. 2M pixels CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. Entire pixels can be read out within approx. 1/15s.

  • Page 6: Specification

    1/1,000, 1/1,500, 1/2,500, 1/5,000, 1/10,000, 1/27,000s (18) variable range Pulse Width: 1/7.5～1/9,000s (Trigger input pulse width: 2504H (max)～2H (min)) Manual Shutter: 1/15(Off)～1/27000s ・Fixed Trigger Shutter Mode ・Pulse Width Trigger Mode Trigger shutter mode (19) ©2010 CIS Corporation. All rights reserved.
  • Page 7 ※Camera functions can operate normally under operation guaranteed temperature. RH 20～80% with no condensation Humidity -25℃ ～ +60℃ Temperature Storage environment (23) Humidity RH 20～80% with no condensation ©2010 CIS Corporation. All rights reserved.

  • Page 8: Camera Output Signal Specification

    5 seconds shall be waited after turning on power to get proper camera operation. ※ +5.0V(VCC) 100Ω TTL Output HD74LV1GT32ACME (RENESA) Voh:3.8V(Min) Vol:0.55V(Max) 100Ω TTL Input HD74LV1GT14ACME (RENESAS) Vt-:0.5(Min) Vt+:1.9V(Max) 12pins circular connector at rear, GPIO Interface ©2010 CIS Corporation. All rights reserved.

  • Page 9: Ccd Spectral Response (Representative Value)

    VCC-F51U25CL Rev.900-667-31-01 4.3 . CCD Spectral Response (Representative Value) 4.3.1. CCD (ICX274AL) Spectral Response ※ Lens characteristics, IR cut filter, and luminous source characteristics are not considered. 4.3.2. Prism Spectral Transmission Characteristics ©2010 CIS Corporation. All rights reserved.

  • Page 10: Function Settings

    Address 009 MSB and address 010 LSB makes 16bit in total. Shutter speed = (1251 - (009&010))×53.33μ s+37.06μ s Max Data = 1251 Trigger Polarity 0: Positive Input 1: Negative Input Trigger Input 0: Camera Link (CC1) Input 1: 12pin Connector(11pin) Input ©2010 CIS Corporation. All rights reserved.
  • Page 11 Input 083 or 053 to save the data to EEP-ROM. Note: When setting the data with 2 Byte, High Byte shall be set first, then Low Byte to the next. ※ The camera rewrites the internal resister when receiving Low Byte. ©2010 CIS Corporation. All rights reserved.

  • Page 12: External Connector Pin Assignment

    6.2. Camera Link Connector 12226-1100-00PL (SUMITOMO 3M) RGB 24bit Output (Base Configuration) RGB 30bit/36bit (Medium Configuration) Pin No. Pin No. Xclk- Xclk+ SerTC+ SerTC- SerTFG- SerTFG+ CC1- CC1+ CC2+ CC2- CC3- CC3+ CC4+ CC4- ©2010 CIS Corporation. All rights reserved.

  • Page 13: Timing Chart

    9 10 11 12 30 31 32 33 34 35 36 37 38 39 40 LVAL Output DVAL Output FVAL Output 9H(V Sync) 19H(Back proch) 1200H (Active Line Margin) (Active Line) Total = 1252H ©2010 CIS Corporation. All rights reserved.

  • Page 14: Fixed Trigger Shutter Mode

    Exposure Time Trigger invalid ✖ (Trigger Input ) ( Exposure Time ) ✖ SP Output （Ｆ） (Exposure Signal) Exposure Time ( Register Set Value) Exposure Time （Ｂ） (Register Set Value) Video Output （Ｂ） DVAL Output ©2010 CIS Corporation. All rights reserved.

  • Page 15: Pulse Width Trigger Shutter Mode

    (Trigger Input) SP Output (Exposure Time) (Exposure Signal) （Ｂ） Exposure Time Exposure Time Exposure Time （Ｂ） (Pulse Width) ( Pulse Width ) (Pulse Width) ( Video Output ( C)) ✖ Video Output DVAL Output ©2010 CIS Corporation. All rights reserved.

  • Page 16: Partial Scan Mode Details

    25 fps・ 480 H 756 H ・ ・ ・ ・ 768 H 948 H 20 fps ・ ・ ・ ・ 1026 H 1120 H 17 fps ・ ・ ・ ・ 1224 1252 H 15 fps ©2010 CIS Corporation. All rights reserved.

  • Page 17: Remote Interface Function

    To save the data into EEPROM, please refer to Section 5., Function Settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2010 CIS Corporation. All rights reserved.

  • Page 18: Initial Settings

    0: Camera Link (CC1) Input Output Data Select 0: 24bit RGB Output Data Gamma Mode 0: Gamma OFF (1.0) Partial Scan Mode 0: Full Frame Scan Mode Partial Scan Total Line 021&022 1251: Read Only ©2010 CIS Corporation. All rights reserved.

  • Page 19: Ccd Optical Axis Accuracy

    0.6 phai to the center of lens mount. Datum Plane A Inclination of effective pixels theta to datum plane A. Theta shall be under ±0.5° *)Dimensions from datum plane A to the center of the lens mount 910-010-00-00 (Unit:mm) ©2010 CIS Corporation. All rights reserved.

  • Page 20: Dimensions

    Label Position *) C Mount screws comply with ANSI/ASME B1.1, 1-32U (2B). *) Screw length from C mount lens surface shall be under 4.5mm. And protruding portion shall be less than 4.5mm. 999-502-00-02 (Unit :mm) ©2010 CIS Corporation. All rights reserved.

  • Page 21: Cases For Indemnity (Limited Warranty)

    14. CCD Pixel Defect CCD pixel defects might be noted with time of usage of the products. Cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS is exempted from taking any responsibilities for them.
