CIS VCC-G20U20A Product Specification & Operation Manual

29mm cubic uxga analog b/w camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-G20U20A
Rev.900-618-35-00
English
29mm Cubic UXGA
Analog B/W Camera
VCC-G20U20A

Product Specification

& Operation Manual
CIS Corporation
©2014 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-G20U20A and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-G20U20A

Summary of Contents for CIS VCC-G20U20A

  • Page 1: Product Specification

    VCC-G20U20A Rev.900-618-35-00 English 29mm Cubic UXGA Analog B/W Camera VCC-G20U20A Product Specification & Operation Manual CIS Corporation ©2014 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    7.4.3. Pulse Width Trigger Shutter Mode 2 (SYNC Non-Reset) ............18 8. CCD Optical Axis Accuracy ....................... 19 Dimensions ............エラー! ブックマークが定義されていません。 Cases for Indemnity (Limited Warranty) .................. 21 11. CCD Pixel Defect ........................21 12. Product Support ........................21 ©2014 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    VCC-G20U20A Rev.900-618-35-00 1. Scope of Application This is to describe VCC-G20U20A UXGA analog B/W CCD camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Notice The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life.

  • Page 4: Product Outline

    In case of abnormal operation, contact the distributor from whom you purchased the product. 3. Product Outline VCC-G20U20A is a high-resolution industrial B/W analog camera module utilizing a 1/1.8-inch PS IT CCD. 2M pixels CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. Only 29mm cubic in size (excluding projection), light weight 45g, and speed makes it a best match for use in embedded systems.

  • Page 5: Specification

    1 (fixed) Shutter speed Fixed Switch: OFF (1/15), 1/120, 1/300, 1/600, 1/1,250, 1/2,500, 1/5,000, variable range 1/10,000s Pulse Width: 10μs ～ 250ms ・Fixed trigger shutter mode ・Pulse width trigger shutter mode Trigger shutter mode ©2014 CIS Corporation. All rights reserved.
  • Page 6 ±X, ±Y, and ±Z direction. (without package) Temperature Operation guaranteed: -5℃～+45℃ Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity Temperature -25℃ ～ +60℃ Storage environment RH 20～80% with no condensation Humidity ©2014 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    VS output 1.0V (p-p), Sync. Negative, 75Ω unbalanced, DC connect White clip level: 840 ± 70 mVp-p Setup level: 25 ± 15 mVp-p (Gain 0dB) SYNC level: 290 ± 50 mVp-p VS DC level: 0 ± 100 mV ©2014 CIS Corporation. All rights reserved.

  • Page 8: Ccd Spectral Response (Representative Value)

    ◇ HD/VD signals input/output settings (No.6 and 7 pins of the circular connector) IN/OUT ● indicates initial setting position. ● Other Optional Functions (optional settings as the factory settings) ◇ HD/VD75Ωimpedance ◇ AGC Gain ◇ γ= 0.45 Please ask for the details. ©2014 CIS Corporation. All rights reserved.
  • Page 9 Partial Scan mode ○ ○ ○ ○ HD/VD Input ○ HD ○ HD ○ ○ HD/VD Output × ○ ○ ○ ※1 When using the camera at Restart-Reset mode, shutter speed settings shall be OFF. ©2014 CIS Corporation. All rights reserved.
  • Page 10 HD external input is valid but VD external input invalid. Exposure time = Trigger pulse width (μs) + 4.7μs typical Conditions: Trigger input pulse width shall be 4μs～250ms, Positive Logic The shortest trigger cycle = 1 frame + 5H ©2014 CIS Corporation. All rights reserved.

  • Page 11: Exposure Time

    Trigger Input Discharge Read OUT Exposure Time 3.85 8.55 ±0.028μ s ±0.028μ s Exposure Time Exposure = Trigger Width + 4.7μ s ©2014 CIS Corporation. All rights reserved.
  • Page 12 Low level (0.5V Max) Full Frame Scan Mode Binning Mode Partial Scan Mode Gain settings 0dB Fixed Manual gain (MGC volume at rear) HD/VD input and output settings SW10 HD/VD output HD/VD input Indicates initial setting position ©2014 CIS Corporation. All rights reserved.

  • Page 13: External Connector Pin Assignment

    VCC-G20U20A Rev.900-618-35-00 6. External Connector Pin Assignment 12pins Circular Connector SNH-10-12(RPCB) (SAMWOO) Pin No. Power IN +12V Video Out HD In/Out VD In/Out SCAN In WEN Out Trigger In ©2014 CIS Corporation. All rights reserved.

  • Page 14: Timing Chart

    7.2.1. Full Frame Scan Mode 1V = 1252H Camera VD Output Black Transmit Black Effective Pixels 1236 Read Out Signal Exposure Time Discharge Signal Video Output Vertical Blanking Video Output Active Period 32 H 1220 H WEN Output ©2014 CIS Corporation. All rights reserved.

  • Page 15: Binning Mode

    1V = 626H Camera VD High Speed Transmit Period High Speed Transmit Period Vφ Pulse Read Out Signal Discharge Signal Exposure Time Vertical Blankinng 49H Video Output Active Period 550H Video Output WEN Output ©2014 CIS Corporation. All rights reserved.

  • Page 16: 1/4 Partial Scan Mode

    Video Output WEN Output 7.3. Restart Rest Mode (Long Time Exposure) Timing External VD Exposure Time External HD Read Out Signal Exposure Time Video Output 1220H At Full Frame Scan WEN Output 1V min ©2014 CIS Corporation. All rights reserved.

  • Page 17: Trigger Shutter Mode Timing

    μ Read Out Signal Exposure Time Trigger Pulse Width Internal HD or External HD Internal VD Output Video Output Video Active Period 1V = 1252H (At Full Frame Scan) WEN Output 1～2 1220 ©2014 CIS Corporation. All rights reserved.

  • Page 18: Pulse Width Trigger Shutter Mode 2 (Sync Non-Reset)

    Only Trigger Pulse Width μ (min) External HD External VD Input ( Single Pulse ) s ～ 70ms μ Video Output Video Active Period 1V = 1252H (At Full Frame Scan) WEN Output 1220 ©2014 CIS Corporation. All rights reserved.

  • Page 19: Ccd Optical Axis Accuracy

    The center of effective pixels shall θ ≦±0.5° be within Φ0. 6 to the center of lens mount . (＊ ) Dimension from datum plane to the center of lens mount . 910-005-00-00 (Unit: mm) ©2014 CIS Corporation. All rights reserved.

  • Page 20: Dimensions

    VCC-G20U20A Rev.900-618-35-00 9. Dimensions ©2014 CIS Corporation. All rights reserved.

  • Page 21: Cases For Indemnity (Limited Warranty)

    On very rare occasions, however, CCD pixel defects might be noted with time of usage of the products. Cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS is exempted from taking any responsibilities for them.
