  • Page 1 PX184 LED Driver 3 x 700mA / 48V MANUAL...

  • Page 2: Table Of Contents

    16. Technical data....................Declaration of conformity..................Manufacturer reserves the right to make modifications in order to improve device operation. tel.: +48 12 626 46 92 PXM Marek Żupnik spółka komandytowa fax: +48 12 626 46 94 Podłęże 654 E-mail: info@pxm.pl Rev.3.0...

  • Page 3: General Description

    2. SAFETY CONDITIONS The PX184 LED Driver 3 x 700 mA / 48V is a device powered with safe voltage up to 48V; however, during its installation and use the following rules must be strictly observed: 1.

  • Page 4: Model Description

    NTC 4K7 temperature sensor 4. CONNECTION SCHEME Example connection the PX184 driver to the LED lamp: - the cables should be connected with the correct order of colors, - LEDs should be connected only in series, - controlled LEDs can be connected using two conductors only, i.e. two per channel, - the number of serially connected LEDs depends on the driver and supply voltage.
  • Page 5 PiXiMo 3700 power supply DMX in 12-48 V DC DMX out NTC 4K7 temperature RED - sensor GREEN - BLUE - RED - RED + GREEN - GREEN + GREEN + BLUE + BLUE - BLUE + RED +...

  • Page 6: Dmx Signal Connection

    DMX OUT connector the driving cable must be provided to other DMX receivers. If PX184 is the last device in DMX line, DMX Out terminals must be provided with the terminator – resistor of 120 Ω between pins “+” and “-”...
  • Page 7 scene programme no. 17 shorted thermistor DMX address settings for first channel MASTER mode on / off number of channels being sent in the MASTER mode white colour balance setting red balance green balance blue balance white colour balance on / off program playback speed level of steps change smoothness in the program red colour during scene programming...
  • Page 8 function to limit power value of the limit activation temperature value of the maximum limit temperature current temperature the highest temperature recorded by the sensor the lowest temperature recorded by the sensor temperature limit is switched off and it is not possible to read the following temperatures: maximum, minimum, and current or when a mode which does not use all channels is set, and unused channels will have the address of the channel approval of changes...

  • Page 9: Programming Of Group Parameters

    - Transition smoothing between different values. 7.1. Setting of DMX address Menu of the PX184 driver allows for setting the DMX address of the device depending on the mode of operation in the following range: 1 - 511 : two-byte mode 2b...
  • Page 10 For the selected operating mode the following channels have the following settings: 2b mode – lightness and one of the 256 colours defined by a colour designer; 3b mode – three colours: R (red), G (green), B (blue); 3bd mode – three colours: R (red), G (green), B (blue), and the fourth channel includes the Dimmer function –...

  • Page 11: Response To The Lack Of Dmx Signal

    CHANNEL1 - red colour CHANNEL2 - green colour CHANNEL3 - blue colour CHANNEL4 - operating mode selection CHANNEL5 - speed settings (higher value - quicker changes) CHANNEL6 - fade settings (higher value - smoother transition) CHANNEL7 - lightness settings (higher value - stronger glow) character ("x") - possibility to control a given parameter of a selected mode character ("-")

  • Page 12: Description Of The Programs

    7.4 Description of the programs Tables below show values for particular output channels - R, G, B - in programs from 1 to 18 (P01 - P18). 255 stands for maximal output brightness, 127 for 50% and 0 for channel blackout. step 1 step 2 step 3...

  • Page 13: Master / Slave Function

    7.5 MASTER / SLAVE function The PX184 module has a built-in DMX-512 receiver and it can be controlled from any desktop operating in this standard. Additionally, it comes with a programmable response function to no DMX signal (noS). With 18 built-in factory programmes, it is possible to get effects without an external controller.

  • Page 14: White Balance

    - to turn off the white balance. 7.7 The smoothing function The PX184 device is equipped with a smoothing option. If this option is enabled, it allows for smooth transitions between successive DMX values that are sent to the lamp (changes in lightness and colour) without visible abrupt changes.

  • Page 15: Programming Of Individual Parameters

    8. PROGRAMMING OF INDIVIDUAL PARAMETERS The programming of individual parameters allows for assigning any DMX address to each output channel. The simplest example is to control the lightness of LEDs of the same colour plugged into all output channels of the driver. In this situation, assign the same address (e.g.

  • Page 16: Temperature Limits And Sensor Failure

    Proceed in a similar way to disable this feature but then select oFF. 11. TEMPERATURE LIMITS AND SENSOR FAILURE PX184 has been equipped with a function that limits the output power depending on the temperature value read using the external sensor mounted in the lamp. This allows for programming a temperature value which, if reached, limits the power or disables the lamp supplied by the driver.

  • Page 17: Additional Functions

    The device has been equipped with an option to restore default settings. To use this option you must disconnect PX184 from power supply. Before re-applying the power, press and hold the "previous" button. After turning on, the screen of the device shows a dFl message (during the power-on until the display shows the dFl button the "previous"...
  • Page 18 Err message - memory error The device is equipped with a built-in memory work control function. If there are problems with the memory operation, on the PX184 display the Err message appears Err - memory error. In this situation, select the enter button. The device will reload the default configuration and upload it to the memory.

  • Page 19: Rdm Description Of Available Parameters

    13. RDM DESCRIPTION OF AVAILABLE PARAMETERS The PX184 supports the RDM protocol. DMX protocol allows only of a one-way data transmission, while its extension the RDM protocol can transmit information in two directions. This makes possible to simultaneously send and receive information, and hence the possibility of monitoring activities of the compatible devices.
  • Page 20 Description Parameter name TEMPERATURE_ 0x800F lower temperature value for which the temperature limitation is being activated THRESHOLD_LOW TEMPERATURE_ 0x8010 upper temperature value for which the temperature limitation is active, i.e. the cut-off THRESHOLD_HIGH temperature for exits from the driver BALANS_RED 0x8011 balance modulation value of red channel;...
  • Page 21 Minimum value is 0, maximum value is 255 (maximum lightness). Default value is 255. SCREENSAVER_ON/OFF * 0x8024 settings of screensaver (display backlight in PX184); With the 0 value display blanking is not active, the 1 value means screensaver active. Default value is 0. PROGRAM_SPEED...
  • Page 22 Description Parameter name BALANCE ON/OFF * 0x8027 Turn on or off the balance of output channels; Value 0 is the channel balance off, value 1 is the channel balance on. Default value is 0. PWM_FREQENCY * 0x8028 LEDs refresh frequency; The minimum value is 366, and the maximum is 1500.

  • Page 23: Programming

    14. PROGRAMMING REMARKS: 1. ENTER allows for entering ENTER ENTER a subsequent "submenu" and saving a selected parameter. NEXT 2. ESCAPE allows for returning to the ENTER previous menu without saving changes. NEXT 3. NEXT allows for moving forward within the selected menu.

  • Page 24: Dimensions

    15. DIMENSIONS www.pxm.eu PiXiMo 3700 105 mm 60 mm 16. TECHNICAL SPECIFICATION - DMX channels - power supply 12V DC for 1, 2 or 3 LEDs 24V DC for 4, 5 or 6 LEDs 48V DC for 7, 8, 9, 10, 11 or 12 LEDs...

  • Page 25: Declaration Of Conformity

    30-701 Kraków fax: 12 626 46 94 DECLARATION OF CONFORMITY according to guide line 2004/108/WE Name of producer: PXM Marek Żupnik sp. k. Manufacturer’s address: ul. Przemysłowa 12 30-701 Kraków We declare that our product: Product name: LED Driver 3 x 700mA / 48 V...
