- Page 1 FS-52 NNER UTER HIGH SSEMBLY ANUAL Model: FS52A Rev: 030620...
- Page 2 TRUE experience. Innovation across the full product line has made TRUE successful and is a trademark of the TRUE heritage. TRUE’s patented Heart Rate Control technology is just one of the remarkable ways we deliver simple and superior performance every user can enjoy, and most importantly, use to achieve personal health and fitness goals.
-
Page 3: Table Of Contents
ABLE ONTENTS ........................4 AFETY ................ENERAL ARE AND AINTENANCE ................... 8 IMENSIONS AND EIGHT ......................9 REPARATION .................... 10 ARTON ONTENTS .................... 11 ARTON ONTENTS & A NSTALLATION SSEMBLY 1: A ..........12 SSEMBLE THE RAME OMPONENTS 2: A ........... -
Page 4: Safety
9. If the machine appears damaged or inoperable, contact a facility staff member to place an “OUT OF ORDER, DO NOT USE” sign on the machine until it is repaired. Only use TRUE Fitness supplied replacement components to service this machine. - Page 5 3. Install this piece of equipment on a solid level surface that does not deviate more then 1/8” over a 10’ distance (or as defined and required by local building and architectural codes. 4. TRUE Fitness strongly recommends that all equipment be anchored to the floor to prevent movement and increase stability.
- Page 6 • Frames and Lifting Arms: Inspect weekly for integrity and function. Replace any component at first signs of wear. Use only TRUE Fitness supplied components. 4. Replace any warning label at first sign of wear. Labels and the Facility Safety Sign may be obtained from TRUE Fitness free of charge.
- Page 7 Be sure all hardware is tight before using the machine. Retain these instructions for future reference. If you have any questions, do not hesitate to contact your TRUE Fitness dealer or TRUE Fitness at (800) 883-8783 or service@truefitness.com.
-
Page 8: Dimensions And Weight
IMENSIONS AND EIGHT “I ” M ACHINE IMENSIONS 60.5” (154 cm) Maximum user weight: 300 lbs. (136 KG) ACHINE EIGHT AND LOOR OADING EIGHT TACK ONFIGURATION ACHINE WEIGHT PPROXIMATE LOOR OADING 170 lbs. 455 LBS [206 KG] 66 LBS/FT [322 KG/M 250 lbs. -
Page 9: Preparation
REPARATION EQUIRED OOLS Ratchet Wrench and Sockets: 9/16” Wrenches: 9/16”, 3/4”. (or an adjustable crescent wrench). Rubber Mallet and Steel Hammer Allen wrenches: (included with the machine) Hardware Measurement Guide: BHCS - BUTTON HEAD CAP SCREW SHCS - SOCKET HEAD CAP SCREW FHCS - FLAT HEAD CAP SCREW HHCS - HEX HEAD CAP SCREW MEASURE BOLT... -
Page 10: Box 1 Carton Contents
FS-52 C ARTON ONTENTS QTY. ESCRIPTION FS-CAP-000X TOP UPRIGHT CAP FS-GRD-200X GUIDE ROD FS-SHD-250X REAR SHROUD FS52-SHD-200X FRONT SHROUD FS52-UPR-000X UPRIGHT FRAME FS-BKT-000 GUIDE ROD BRACKET FS-WSB-000 WEIGHT STACK BASE FS52-PAD-100X SEAT PAD FS-PAD-000X BACK PAD FS52-PLY-000 FLOATING PULLEY HOUSING... -
Page 11: Box 2 Carton Contents
THIGH PAD PLATES FS52-AXL-000X AXLE, RIGHT ARM FS52-MFR-400X SLEEVE, AXLE SPACER FS52-PLT-400X ARM CONNECT PLATE FS52-CVR-100X COVER, CAM FS52-CVR-200X SMALL COVER, CAM FS52-AXL-100X AXLE, LEFT ARM FS52-HWR-000X FS-52 HARDWARE BOX FS52-ADJ-100X ADJUSTMENT PLATE FS52-ARM-200X PULLEY ARM FS52-CAM-000X CAM, CABLE FS-SBR-000X SELECTOR BAR... - Page 12 1: A SSEMBLE THE RAME OMPONENTS 1. Position the main frame and upright ESCRIPTION frame. Route the cable before assembling C 445 SCREW, 3/8”-16 X 1” the two components as shown. C 450 SCREW, 3/8”-16 X 2-1/2” C 749 LOCKWASHER, 3/8” 2.
- Page 13 1: A SSEMBLE THE RAME OMPONENTS NOTE: MAKE SURE THIGH PAD PLATE IS ORIENTED AS SHOWN BEFORE INSTALLING DETAIL B RETAINING PIN. 8, 6, 7, 5 DETAIL D 8, 2, 7, 5, 10 8, 1, 3, 7, 5 DETAIL F 8, 2, 7, 5, 10 DETAIL A DETAIL C...
- Page 14 2: A SSEMBLE THE DJUSTMENT LATE 1. Assemble the cam to the axle and QTY. ESCRIPTION C 754C FLAT WASHER, 3/8” tighten the hardware. The cam can C 766A LOCK NUT, 3/8”-16 only be assemble to the axle in one orientation.
- Page 15 3: A SSEMBLE THE 1. Assemble the left arm to the axle. QTY. ESCRIPTION FS52-ARM-000X LEFT ARM 2. Assemble the arm retaining assembly FS52-MFR-300X THIGH PAD PLATES and tighten the hardware. FS52-MFR-200X ARM RETAINING ASSY 3. Install the roll pin using a hammer. Make FS-PIN-100 ROLL PIN, 8mm X 35mm sure the arm is able to be in the position...
-
Page 16: Ads
4: A SSEMBLE THE 1. Assemble the pads and hardware as QTY. ESCRIPTION shown. C 451 SCREW, 3/8”-16 X 2-3/4” HHCS C 446 SCREW, 3/8”-16 X 1-1/4” HHCS 2. Tighten ALL the hardware. C 452 SCREW, 3/8”-16 X 3” HHCS 3. -
Page 17: Tep Ssemble The
5: A SSEMBLE THE ONNECTING LATE 1. Assemble the connection arm and QTY. ESCRIPTION hardware as shown. The arms will FS52-PLT-400X PLATE, ARM CONNECTION have to be positioned so that the C-766A LOCK NUT, 3/8”-16 plate can be attached C 754C WASHER, FLAT, 3/8”... -
Page 18: Weight Stack
6: I NSTALL THE EIGHT TACK ESCRIPTION 1. Place the guide rods in the upright. C 449 SCREW, 3/8”-16 X 2-1/4” HHCS 2. Install the weight stack base, rubber C 766A LOCK NUT, 3/8” bumpers, and washers. C 754C FLAT WASHER, 3/8” FS-GRD-200X ASSY, GUIDE ROD 3. -
Page 19: Cables
7A: I NSTALL THE ABLES 1. Route the cable as shown, installing QTY. ESCRIPTION the associated pulleys and hardware B 900 PULLEY, 4-1/2” DIA. as you go along. C 448 SCREW, 3/8”-16 X 1-3/4” HHCS C 754C FLAT WASHER 2. After assembly, make sure the cable C 766A LOCK NUT, 3/8”-16 and pulleys can move freely. -
Page 20: Cables
7B: I NSTALL THE ABLES 1. Route the cable as shown, installing QTY. ESCRIPTION the associated pulleys and hardware B 900 PULLEY, 4-1/2” DIA. as you go along. C 448 SCREW, 3/8”-16 X 1-3/4” HHCS C 802 SCREW, M4 X 20mm PAN HD. 2. -
Page 21: Cam Cover
8: I NSTALL THE OVER QTY. 1. Place the Cam Cover into place and ESCRIPTION FS52-CVR-100X COVER, CAM loosely assemble the hardware. FS52-CVR-200X SMALL COVER, CAM 2.Place the Small Cam Cover into place C 680A SCREW, BUTTON HD, 1/4”-20 X 1/2” and loosely assemble the hardware. -
Page 22: Tep Nstall The
9: I NSTALL THE RONT HROUD 1. Place the front shroud into position. QTY. ESCRIPTION C 445 SCREW, 3/8”-16 X 1” HHCS 2. Align the holes and assemble the C 749 LOCK WASHER hardware. C 754C FLAT WASHER 3. Tighten all the hardware. FS52-SHD-200X FRONT SHROUD 1, 2, 3... -
Page 23: Step 10: Install The
10: I NSTALL THE HROUD 1. Set the lower screws of the shroud into the QTY. ESCRIPTION lower brackets on the upright frame. C 766A LOCKNUT, 3/8”-16 C 675D SCREW, 1/4”-20 X 1/2” BHCS 2. Then align the holes for the brackets at C 444 SCREW, 3/8”-16 X 3/4”... -
Page 24: Tep Pply The
11: A PPLY THE EIGHT TACK ABEL 1. Select the appropriate weight stack label(s) according to your order. You can install pound labels, kilogram labels, or both. 2. If you ordered a 170 lb. weight stack, use labels: LBL-WSE-01170 (for pounds) LBL-WSM-01170 (for kilograms). -
Page 25: Machine Labels
ACHINE ABELS The following are the Warning labels required for this FS machine. If any of these labels are missing or become damaged, we will replace them free of charge. Note: these labels are not to scale. WARNING WARNING SERIOUS INJURY CAN OCCUR MAXIMUM ON THIS EQUIPMENT IF THE Height Under Nut... -
Page 26: Service
B T A I N E R V I C E For warranty service, contact an Authorized TRUE Fitness Dealer or a TRUE Fitness Customer Service representative at 1-800-883-8783 or by e-mail at service@truefitness.com. Before you call, please have the following information ready. -
Page 27: Floor
(European) safety standards for stability (without floor anchors) when the machine is used for it’s intended purpose as designated by the manufacturer. However, TRUE Fitness strongly recommends that all equipment be anchored to the floor to prevent movement and increase stability. -
Page 28: Bolting The Machine To The Warranty
Hours of operation 8:30am - 5:00 pm CST workmanship for a 10 years. The frame is warranted for labor and freight (for parts shipped from TRUE) for one year from date of purchase. * This limited warranty on structural frame does not include paint or coatings. - Page 29 (if anyone other than a TRUE authorized dealer/ technician initially assembles and installs the Product, this The FS-52 comes with one serial number on the base of the Limited Warranty will be void unless the written authorization machine. Please write down your serial number below and keep of TRUE is first obtained).
- Page 30 If you prefer to mail your warranty card, have the owner of the product complete the information below and return it to TRUE Fitness within 30 days from the date of equipment installation.
