True XFW6800 Owner's Manual

Smith machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XFW6800
Smith Machine
OWNER'S
MANUAL
Model # XFW6800
Revision 012319

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XFW6800 and is the answer not in the manual?

Questions and answers

Related Manuals for True XFW6800

Summary of Contents for True XFW6800

  • Page 1 XFW6800 Smith Machine OWNER’S MANUAL Model # XFW6800 Revision 012319...
  • Page 2 Технические характеристики, особенности и программного обеспечения могут быть изменены без предварительного уведомления. Для получения самой последней на сегодняшний день руководство по эксплуатации пожалуйста, посетите www.truefitness.com .Для документов на другие языки, пожалуйста, посетите www.truefitness.com/resources/document-library/ Page # 2 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 3 The proud manufacturing tradition of quality and the culture of innovation at TRUE have given rise to a full line of extraordinary cardio and strength equipment. As a result, people all over the world are benefiting from the TRUE experience.

  • Page 4: Table Of Contents

    CHAPTER 4: CUSTOMER SERVICE ..........................26 • CONTACTING SERVICE: ......................26 • CONTACTING SALES: .......................26 • REPORTING FREIGHT OR PARTS DAMAGE: ..............27 CHAPTER 5: ADDITIONAL INFORMATION: ......................28 Page # 4 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 5: Chapter 1: Safety Instructions

    9. If the machine appears damaged or inoperable, contact a facility staff member to place an “OUT OF ORDER, DO NOT USE” sign on the machine until it is repaired. Only use TRUE supplied replacement components to service this machine.
  • Page 6 3. Install this piece of equipment on a solid level surface that does not deviate more than 1/8” over a 10’ distance (or as defined and required by local building and architectural codes.) 4. TRUE strongly recommends that all equipment be anchored to the floor to prevent movement and increase stability.
  • Page 7 • Frames and Lifting Arms: Inspect weekly for integrity and function. Replace any component at first signs of wear. Use only TRUE supplied components. 4. Replace any warning label at the first sign of wear. Labels and the facility safety sign may be obtained from TRUE.
  • Page 8 Be sure all hardware is tight before using the machine. Retain these instructions for future reference. If you have any questions, do not hesitate to contact your TRUE dealer or TRUE Fitness Technology at (800)883-8783 or service@truefitness.com. Page # 8 of 30...

  • Page 9: Commerical Maintenance Schedule

    CLEAN: Guide rods and lubricate with a teflon lubricant if equipped. CLEAN: Upholstery LUBRICATE: Pivot bearings and linear bearings. REPLACE: Cables if equipped. Page # 9 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 10: Chapter 2: Assembly Guide

    Maximum user weight is 400 lb. (182 kg.) • Maximum free weight per weight horn is 5 x 45 lb. (25 kg.) weight plates. 87" 48” 87” Page # 10 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 11: Required Tools

    7/32”, 5/16” Allen Wrench (supplied) Step Ladder Level COMPLIANCES: This equipment complies with all fitness product standards. For a complete list of compliances, please visit www. TrueFitness.com. Page # 11 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 12: Pre-Assembly Checklist

    10XBK manual. XFW68-WTH- BARBELL WEIGHT HORN ASSEMBLY XFW68-STP-10X SAFETY STOP LEFT SIDE XFW68-ROD-01 GUIDE ROD 63.5mm X 25.5mm X 4mm Page # 12 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 13 WOOD WOOD SPACER manual. XFW68-STP-00X SAFETY STOP RIGHT SIDE XFW68-ROD-01 GUIDE ROD 63.5mm X 25.5mm X 4mm XFW68-BAR-00X LIFT BAR ASSEMBLY Page # 13 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 14: Assembly Steps

    XFW68-CBR-10XBK BACK CROSS BAR ASSEMBLY hardware until after completing C 749 SPRING LOCK WASHER 1/4” Step 4 (Wood Spacer). C1111 Socket Head Cap Screw 3/8”- 16UNC X 6.5” Page # 14 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 15 (PTFE) grease on a weekly basis to C1110 FLAT WASHER 1” I.D x 2.5” the guide rods. TRUE recommends O.D X .165” THICK Magnalube© brand. Page # 15 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 16 Note: Ensure both guide rods are inserted into the upper guide rod main frame holes at the same time. Page # 16 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 17 Note: Confirm the lift bar assembly is level and seated in both catch hooks. Adjust the leveling feet as needed to achieve this. Page # 17 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 18 SCREW #10-24 UNC x 1/2” through the hole on the shaft to secure the cable in place. Page # 18 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 19 Slide the lift bar assembly the full length of the guide rods to ensure it and the counterweights attached to the opposite ends of the cables are traveling smoothly. Page # 19 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 20 ASSEMBLY XFW68-RS-00 RUBBER SLEEVE 78mm X 48mm X 25mm SD0092 AXLE COVER C 658 FLAT HEAD SOCKET SCREW 3/8”-16 X 1” Page # 20 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...
  • Page 21 ASSEMBLY STEPS: Optional Step 6 (Floor Bolting): See the below illustration for the location of the holes for bolting the machine to the floor. Page # 21 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com...

  • Page 22: Chapter 3: Care & Maintenance

    The following items are critical to the safety of users and maintenance staff as well as ensuring the optimum performance of the machines. These inspections should be performed each day before the equipment is subject to use. TRUE Fitness is not responsible for performing or scheduling regular maintenance or inspections.

  • Page 23: Other Scheduled Preventive Maintenance

    CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour or spray liquids on any part of the equipment. Allow the equipment to dry completely before using.

  • Page 24: Cable Inspection & Maintenance

    If any of these conditions are apparent, the machine should immediately be taken out of service and repaired. Be sure to use only cables supplied by TRUE Fitness. DO NOT use cables that have fittings attached with hand- crimp tools.
  • Page 25 Ensure that the snap-link opens and closes easily and is fully engaged when closed. Replace the snap-link as needed. Page # 25 of 30 True Fitness Technology • O’Fallon, MO • Phone: 800-426-6570/636-272-7100 • Truefitness.com Truefitness.com / 800.426.6570 / 636.272.7100...

  • Page 26: Chapter 4: Customer Service

    HOURS OF OPERATION: 8:30 A.M. - 5:00 P.M. CST E-MAIL: service@truefitness.com CONTACTING SALES: Interested in TRUE products? Please contact us with any sales or product inquires so that we may direct you to the appropriate sales representative to answer your questions. TRUE FITNESS HOME OFFICE 865 HOFF ROAD ST.

  • Page 27: Reporting Freight Or Parts Damage

    Obvious damage to external packaging / internal product. Please refuse the shipment and it will be returned to TRUE Fitness by the carrier. Contact the TRUE Fitness customer support team by calling 800.883.8783 or sales support team by calling 800.426.6570 Monday-Friday during normal hours of operation to notify us that the shipment has been refused.

  • Page 28: Chapter 5: Additional Information

    Hours of operation 8:30am - 5:00 pm CST workmanship for a 10 years. The frame is warranted for labor and freight (for parts shipped from TRUE) for one year from date of purchase. * This limited warranty on structural frame does not include paint or coatings.
  • Page 29 Product, this Limited Warranty will be void unless the written authorization The XFW6800 comes with one serial number on the base of the of TRUE is first obtained). machine. Please write down your serial number below and keep 5.
  • Page 30 If you prefer to mail your warranty card, have the owner of the product complete the information below and return it to TRUE Fitness within 30 days from the date of equipment installation.
