Description of the device
Features
The Showtec LED Tunnel Flower is a light effect with high output and great effects.
• LEDS: 152 RGB high intensity 5mm LEDs (Red 280, Green 63, Blue 126)
• Beam angle: 15°
• 9 DMX channels
• Addressing by dipswitches
• Operation mode: DMX512, Master/Slave, Sound-controlled, Built-in Programs
• music-controlled via built-in microphone
• Fuse F2A / 250V
Overview
1) Mountingbracket + Adjustment screw
Backside
3
4
5
6
7
2) Dipswitches
3) Microphone
4)
Audio sensitivity
5) DMX Output
6) DMX Input
7) IEC Power Connector + Fuse F2A / 250V
2
6
1
Fig. 1
Fig. 2
