Altronix Trove T1RAL13F8P8 Installation Manual page 8

Trove1R Enclosure Dimensions (H x W x D):
3.25" x 19.0" x 26.5" (82.6mm x 482.6mm x 673.1mm). Shown with Z Bracket attached.
1.5"
0.1"
38.1mm
2.5mm
11.175" (283.8mm)
1" (25.4mm)
3.62"
2.4"
0.55" (14mm)
92mm
61mm
R 1.27" (32.3mm)
4.57"
116.1mm
26.5"
673.1mm
19" (482.6mm)
3.25"
82.3mm
Altronix is not responsible for any typographical errors.
