Delfield F13WR24 Specifications

Short Form Specifications
Top is constructed of one-piece 16-gauge stainless steel, with integral 2.12" (5.4
cm) square nosing on front and 4" (10.1 cm) high by 2" (5.0 cm) thick back-
splash on rear. Top to be insulated and have raised rim opening(s) provided with
cover. Cover(s) are insulated, folding and removable.
Interior is constructed of 22-gauge stainless steel. Liner is insulated with 2.5"
(6.4 cm) foamed-in-place polyurethane. Unit has a cold wall refrigeration sys-
tem provided with adjustable expansion valve located in the 6" (15.2 cm)
mechanical area at right end. Unit is designed to maintain 0°F (-18°C) to 5°F
(-15°C).
Exterior front has 22-gauge stainless steel front panel(s). Exterior ends are con-
structed of 18-gauge galvanized steel.
Electrical connections are 115 volt, 60 Hertz, single phase.
Unit must be hard wired.
Unit is mounted on 6.13" (15.6 cm) high adjustable stainless steel legs.
Refrigeration system components — HFC-404A.
Optional Accessories and modifications
505B Stainless steel back
906A Stainless steel end
505F Laminate facing
505A Laminate back
906E Laminate end
®
The Delfield Company, P.O. Box 470, Mt Pleasant, MI 48804-0470, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2001 The Delfield Company. All rights reserved. Printed in U.S.A.
PROJECT
ITEM #
QUANTITY
APPROVAL
31.5" (80cm) Deep Remote Low Temp, Ice Cream Cabinets
DATE
F13WR
Model F13WR48
Built to NSF7 standards.
