Delfield F13WC32 Specifications

Short Form Specifications

Top is constructed of one-piece 16-gauge stainless steel, with integral 2.12"
(5.4 cm) square nosing on front and 4" (10.1 cm) high by 2" (5.0 cm) thick
backsplash on rear. Top to be insulated and have raised rim opening(s) provid-
ed with cover. Cover(s) are insulated, folding and removable.
Interior is constructed of 22-gauge stainless steel. Liner is insulated with
2.5" (6.4 cm) foamed-in-place polyurethane. Unit has cold wall refrigera-
tion system provided with adjustable expansion valve and is designed to
maintain 0°F (-18°C) to 5°F (-15°C).
Exterior front has 22-gauge stainless steel front panel(s). Exterior ends are
constructed of 18-gauge galvanized steel. Unit has condensing unit on right
end of cabinet and is wired with cord and plug. Housing for condensing unit
has a louvered front panel. A low pressure control, with adjustment knob,
regulates temperature in cabinet.
Electrical connections are 115 volt, 60 Hertz, single phase.
Unit is mounted on 6.13" (15.6 cm) high adjustable stainless steel legs.

Optional Accessories and modifications

505B Stainless steel back
906A Stainless steel end
505F Laminate facing
505A Laminate back
906E Laminate end
717M Sink and dipperwell (consult factory)
717N Dipperwell
717O Sink (consult factory)
213 *220V/50 cycle electrical
*Inclusion of this option will alter
electrical specifications.
®
The Delfield Company, P.O. Box 470, Mt Pleasant, MI 48804-0470, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2001 The Delfield Company. All rights reserved. Printed in U.S.A.
31.5" (80cm) Deep Self-Contained Low Temp, Ice Cream Cabinets
PROJECT
ITEM #
QUANTITY DATE
APPROVAL
F13WC
Model F13WC56
Built to NSF7 standards.
